Summary of Contents for Olympic T-620
- Page 1 Part Number: T-620 customerservice@olmpic-equipment.com www.olympic-equipment.com...
- Page 2 Automatic tyre changer Installation Operation Maintenance Manual...
-
Page 3: Table Of Contents
Contents 1． ． Introduction-------------------------------------------------3 --------------------------------------3 1.1 Dimension of the machine -----------------------------------------------4 1.2 Warning stickers 1.3 Structure----------------------------------------------------------------------- 2． ． Accessories---------------------------------------------------5 Installation---------------------------------------------------5 3.1 Body installation-------------------------------------------------------------- 3.2 Air installation----------------------------------------------------------------- 3.3 Electronical system installation--------------------------------------------- 3.4 Problems and maintenance--------------------------------------------------- Operation ---------------------------------------------------------------------- 4.1 Demounting tyres-------------------------------------------------------------- 4.2 Mounting tyre------------------------------------------------------------------ 4.3 Inflating------------------------------------------------------------------------- Tyre changer locking system introduction -----------------... -
Page 4: Dimension Of The Machine
Preface Thanks for choosing qualified automatic tyre changer. This manual will guide for correct operation and extending use life of the machine, it is an important part of the machine. Please read it carefully before any operation to ensure correct and safe operation. 2．... -
Page 5: 2． ． Accessories
1. Arm control system Bolt A: Adjusting the vertical slide direction and the distance between head and rim. Locking arm B: Fix the vertical slide Horizontal arm C: Help the movement of vertical slide Vertical slide D：use to control the position of mounting/demounting head. Mounting/demounting head E : Separate the rim and bead. -
Page 6: Problems And Maintenance
3.4 Problems and maintenance Problems reason methods Turntable doesn’t work 1. Haven’t connected the Check out the power and electric power. 2. Incorrectly connect the connect 2-3 plug Power supply correct Turntable Polarity not correct Change the polarity to counterclockwise turning correct direction Rotate speed not enough 1. -
Page 7: Mounting Tyre
Outside clamp Put the tyre on the turntable, step on opening pedal, till theclamp lock the tyre. Inside clamp open the clamp, put tyre on the turntable, steps on closing pedal till the clamp lock the tyre. 4.1.4 Set the vertical slide in the working position, so that the mounting/demounting head is near the rim. -
Page 8: Inflating
Place one side of the tyre on the upside of the tail of the mounting/demounting head, then press the other side of the tyre under the mounting/demounting head, to make the tyre enter the groove of the rim. Loose the clamp then inflating the tyre 4.3 Inflating Loose the tyre from the turntable Connect the inflator with the air valve on the tire... -
Page 9: Circuit Structure
7. Circuit structure Make sure these process deals with professional staff. Keep the voltage in 220V. 8. Problems solving NO. Problems Reasons Methods turntable turn in one direction Conversion switch Change conversion switch. damaged turntable does not work 1. Belt is damaged. 1.Change belt 2.Conversion switch 2.Change...
