Operating Instructions
4K Integrated Camera
  AW‑UR100
Model No.
Before operating this product, please read the instructions carefully and save this manual for future use.
Please carefully read the "Read this first!" (pages 2 to 3) of this Manual before use.
ENGLISH
GJ
DVQP3033YA
W0823RA1034 -FJ

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AW-UR100 and is the answer not in the manual?

Questions and answers

Related Manuals for Panasonic AW-UR100

Summary of Contents for Panasonic AW-UR100

  • Page 1 Operating Instructions 4K Integrated Camera   AW‑UR100 Model No. Before operating this product, please read the instructions carefully and save this manual for future use. Please carefully read the “Read this first!” (pages 2 to 3) of this Manual before use. ENGLISH DVQP3033YA W0823RA1034 -FJ...

  • Page 2: Read This First

    FCC NOTICE (USA) Supplier’s Declaration of Conformity Model Number: AW-UR100 Trade Name: Panasonic Responsible Party: Panasonic Corporation of North America Two Riverfront Plaza, Newark, NJ 07102 Support contact: 1-800-524-1448 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 3 Hagenauer Strasse 43, 65203 Wiesbaden, Germany Authorized Representative in EU: Panasonic Connect Europe GmbH Panasonic Testing Centre Winsbergring 15, 22525 Hamburg, Germany Importer for UK: Panasonic Connect UK, a branch of Panasonic Connect Europe GmbH, Maxis 2, Western Road, Bracknell, Berkshire, RG12 1RT...

  • Page 4: Note On Grounding

    Read this first! (continued) Інформація для покупця Виробник: Панасонік Коннект Ко., Лтд. Panasonic Connect Co., Ltd. Адреса виробника: Фукуока Японія Fukuoka, Japan Країна походження: Китай China Імпортер: ТОВ "ПАНАСОНІК УКРАЇНА ЛТД" вул. Васильківська, буд. 30, м. Київ Адреса імпортера: 03022, Україна...

  • Page 5: Table Of Contents

    Contents Read this first! ..................2 Output 2/3 screen ................50 Note on grounding ................4 Output 3/3 screen ................50 UHD Crop 1/2 screen................. 53 Before use ....................6 UHD Crop 2/2 screen................. 53 Overview ....................6 Pan/Tilt 1/2 screen ................55 Computer requirements ...............

  • Page 6: Before Use

    SDI, so the unit can be used flexibly in a wide range of situations as a 4K-compatible remote camera. Safari For Android: • Connection with a Panasonic camera controller is also possible via Android OS Panasonic's proprietary serial communication format. Google Chrome •...

  • Page 7: Disclaimer Of Warranty

    Before use (continued) Disclaimer of warranty Network security IN NO EVENT SHALL Panasonic Connect Co., Ltd. BE LIABLE TO As the unit intended to be used while connected to a network, the ANY PARTY OR ANY PERSON, EXCEPT FOR REPLACEMENT following security risks exist.

  • Page 8: Features

    The unit can also be used together with the cameras and pan-tilt manual. head unit systems currently available from Panasonic Connect For details on PoE++ power supply devices for which operation Co., Ltd. so that an existing system can be used to advantage to has been verified, consult your local dealer.

  • Page 9: Accessories

    Accessories Check that the following accessories are present and accounted for. • After removing the product from its container, dispose of the packing materials in an appropriate manner. Washer nozzle mount bracket Hexagonal bolt Cable cover (1) Drop-prevention wire (1) M8 ×...

  • Page 10: Operating Precautions

    Operating precautions „ „ Shoot under the proper lighting conditions. Color bars To produce pictures with eye-pleasing colors, shoot under the Color bars are used to adjust the color phase, and the widths and proper lighting conditions. positions of these bars may differ from other models. The pictures may not appear with their proper colors when shooting „...
  • Page 11 This product includes MIT Licensed software. This product includes BSD Licensed software. For details on obtaining the source codes, visit the following website. https://pro-av.panasonic.net/en/ However, do not contact Panasonic for questions regarding obtained source codes.

  • Page 12: Parts And Their Functions

    Parts and their functions <NOTE> Camera unit • Do not connect PoE cable to the RS-422 port. Hole used to secure cable cover Use screws to secure the cable cover. DC IN connector <12V IN> (XLR connector) Input 10.8 V (12 V–10%) to 24 V (21.8 V+10%) DC. <NOTE>...
  • Page 13 Parts and their functions (continued) LAN connector for IP control <LAN LINK/ACT> Initialization 2 • The unit is reset to the state it was in at the time of purchase. (All This LAN connector (RJ-45) is connected when exercising IP control camera menu setting values and network setting values are reset.) over the unit from an external device.
  • Page 14 Parts and their functions (continued) „ Output conditions for each video format 3G SDI OUT Frequency System Format 12G SDI OUT/SFP 2160/59.94p 1080/59.94p 2160/59.94p 2160/59.94p 1080/59.94p 1080/59.94i 2160/29.97p 2160/29.97p 1080/29.97p 2160/29.97p 1080/29.97p 1080/59.94p 1080/59.94p 1080/59.94p 1080/59.94p 1080/59.94i 59.94Hz 1080/59.94i 1080/59.94i 1080/59.94i 1080/59.94p 1080/29.97p...
  • Page 15 Parts and their functions (continued) „ IP video transmission output (multi-channel display) • When “Streaming mode” is set to “H.265” H.264(1) H.264(2) H.264(3) H.264(4) JPEG(3) Settings H.265(1) H.265(2) JPEG(1) JPEG(2) 1920×1080 1920×1080 1920×1080 1280×720 1280×720 1280×720 Resolution — — — —...
  • Page 16 Parts and their functions (continued) • When “Streaming mode” is set to “H.264” H.264(1) H.264(2) H.264(3) H.264(4) JPEG(3) Settings H.265(1) H.265(2) JPEG(1) JPEG(2) 1920×1080 1920×1080 1920×1080 1280×720 1280×720 1280×720 1280×720 1280×720 Resolution — — 640×360 640×360 640×360 640×360 640×360 640×360 320×180 320×180 320×180...
  • Page 17 Parts and their functions (continued) • When “Streaming mode” is set to “JPEG (UHD)” H.264(1) H.264(2) H.264(3) H.264(4) JPEG(3) Settings H.265(1) H.265(2) JPEG(1) JPEG(2) 3840×2160 1920×1080 1920×1080 Resolution — — 1280×720 1280×720 1280×720 1280×720 — — 640×360 640×360 640×360 320×180 320×180 320×180 60fps...
  • Page 18 Parts and their functions (continued) • When “Streaming mode” is set to “RTMP(UHD)” H.264(1) H.264(2) H.264(3) H.264(4) JPEG(3) Settings H.265(1) H.265(2) JPEG(1) JPEG(2) 3840×2160 1920×1080 Resolution — — — — — 1280×720 640×360 640×360 640×360 320×180 320×180 320×180 60fps 30fps 30fps 30fps 30fps...
  • Page 19 Parts and their functions (continued) • When “Streaming mode” is set to “SRT(H.265 UHD)” H.264(1) H.264(2) H.264(3) H.264(4) JPEG(3) Settings H.265(1) H.265(2) JPEG(1) JPEG(2) 3840×2160 1920×1080 Resolution — — — — — 1280×720 640×360 640×360 640×360 320×180 320×180 320×180 30fps 30fps 30fps 30fps...
  • Page 20 Parts and their functions (continued) • When “Streaming mode” is set to “SRT(H.264 UHD)” H.264(1) H.264(2) H.264(3) H.264(4) JPEG(3) Settings H.265(1) H.265(2) JPEG(1) JPEG(2) 3840×2160 1920×1080 Resolution — — — — — 1280×720 640×360 640×360 640×360 320×180 320×180 320×180 60fps 30fps 30fps 30fps...
  • Page 21 Parts and their functions (continued) • When “Streaming mode” is set to “High bandwidth NDI” H.264(1) H.264(2) H.264(3) H.264(4) JPEG(3) Settings H.265(1) H.265(2) JPEG(1) JPEG(2) 1920×1080 1280×720 Resolution — — — — — — — — 640×360 320×180 30fps System 15fps frequency —...

  • Page 22: Network Settings

    Easy IP Setup Software. You can obtain Easy IP Setup Software (EasyIPSetup.exe) by downloading it from the following website. https://pro-av.panasonic.net/en/ To establish the settings for a multiple number of units, the settings must be selected for each camera involved. If the settings cannot be established using the Easy IP Setup Software, select the settings separately for the unit and personal computer on the Network setup screen [Network] of the setting menu.

  • Page 23: Setting The Initial Account

    Network settings (continued) Completing registration of the initial account Setting the initial account After completing registration of the initial account, the following Set the initial account. registration completed screen is displayed. In the initial state, the initial account setting screen is displayed when The live screen [Live] is automatically displayed after about the web screen is displayed.

  • Page 24: Installing The Plug-In Viewer Software

    Network settings (continued) Installing the plug-in viewer software To view IP images from the unit on Microsoft Edge (IE mode), the "Network Camera View 4S" plug-in viewer software (ActiveX ® ) must be installed. The plug-in viewer software can be installed directly from the unit. <NOTE>...

  • Page 25: Basic Shooting Operations

    Basic shooting operations Set the subject brightness to the appropriate level. Turn on the power of all the units and devices in the system. Select the unit to be operated. Even when using only one unit, it must still be selected from the controller.

  • Page 26: How To Turn The Power On And Off

    How to turn the power on and off Selecting the units Select the unit (or units) to be operated from the controller. Turning the power on Even when using only one unit, it must still be selected. When using an AW-RP150 or AW-RP60 For details, refer to the operating instructions for the controller.

  • Page 27: Selecting The Shooting Modes (Scene Files)

    Selecting the shooting modes (scene files) Shooting „ Changing the camera’s direction Types of shooting modes Moving the camera toward the left or right (panning): One of four shooting modes (Full Auto, Scene1, Scene2 or Scene3) — Tilt the <PAN/TILT> lever toward L or R. whichever one will best suit the shooting conditions —...

  • Page 28: What To Do When Encountering Problems In The Basic Shooting Operations

    What to do when encountering problems in the basic shooting operations If the trouble is not resolved by taking the action suggested below, refer to “Troubleshooting” (→ page 137). The unit does not move. • Select the unit to be operated by following the procedure below. When using an AW-RP150 or AW-RP60 For details, refer to the operating instructions for the controller.

  • Page 29: More Advanced Operations

    More advanced operations Manual shooting (→ page 30) • Manually adjusting the focus • Manually adjusting the iris • Manually adjusting the shutter speed • Manually adjusting the gain Preset memories (→ page 30) • Up to 100 settings for the camera direction (panning and tilting), zoom, focus, iris, gain up and white balance can be registered in the preset memories, and called.

  • Page 30: Manual Shooting

    Manual shooting Preset memories This unit enables up to 100 settings for the camera direction (panning Manually adjusting the focus and tilting), zoom, focus, iris, gain and white balance to be registered in The lens focus can be adjusted manually. its preset memories, and called.

  • Page 31: White Balance Adjustment

    White balance adjustment Adjust the ratio between the three primary colors (RGB) to reproduce Automatic adjustment (AWB: AWB A or AWB B) white accurately. If the white balance is out of adjustment, not only will When using an AW-RP150 or AW-RP60 white be reproduced poorly, but the color tones of the screen as a whole For details, refer to the operating instructions for the controller.

  • Page 32: Black Balance Adjustment

    Black balance adjustment Black level (master pedestal) adjustment Adjust the zero levels of the three primary colors (RGB) to reproduce The black level can be adjusted when using a multiple number of black accurately. If the black balance is out of adjustment, not only will cameras including the unit.

  • Page 33: Genlock Adjustment

    Genlock adjustment Basic setup operations The genlock adjustment is performed to achieve phase alignment by Camera menus are displayed on the monitor when the unit’s settings are applying external synchronization (genlock) when a multiple number of to be selected. cameras will be used or when the unit will be used in combination with The monitor is connected to the video signal output connector.

  • Page 34: Camera Menu Items

    Camera menu items Setting the camera menu items Camera screen Camera menus are displayed on the monitor when the unit’s settings are This menu is used for the camera image settings. to be selected. C a me ra The basic camera menu operations involve displaying sub-menus from the Top Menu items, and selecting settings on the sub-menus.

  • Page 35: Brightness 1/2 Screen

    Camera menu items (continued) Shutter Mode [Off, Step, Synchro, ELC] Brightness 1/2 screen Select for camera shutter mode. This menu item is selected to set the brightness of the pictures. The shutter is set to OFF. B r i g h t n es s 1/ 2 Step The step shutter is set (the steps can be changed).

  • Page 36: Brightness 2/2 Screen

    Camera menu items (continued) ND Filter [Through, 1/4, 1/16, 1/64, Auto] Brightness 2/2 screen Set the transmittance of the lens' built-in ND (neutral density) filter. The filter switches when the setting is fixed. B r i g h t n es s 2/ 2 Through Do not set ND filter.

  • Page 37: Picture 1/6 Screen

    Camera menu items (continued) ATW Speed [Normal, Slow, Fast] Picture 1/6 screen Set the control speed of the ATW function. Normal Tracks at normal speed. Pi ct u re 1/6 Slow Tracks at a speed slower than [Normal]. Fast Tracks at a speed faster than [Normal]. Whi te Ba l an ce M ode AT W Co lor T e mp erat ure...

  • Page 38: Color Temp. Setting Screen

    Camera menu items (continued) Color TEMP. Setting screen Picture 2/6 screen C o l o r T EM P. P ic tu r e 2/ 6 W h i t e B a l an c e Mod e A TW Ch ro m a Le v el C o l o r T e mp e ra tur e 320 0K...

  • Page 39: Picture 3/6 Screen

    Camera menu items (continued) Picture 3/6 screen Picture 4/6 screen P i c t u r e 3 /6 P ic tu r e 4/ 6 D e t a i l Sk in De ta i l O f f M a s t e r D e t ai l S ki n D et a il E ff e ct D e t a i l C o r in g...

  • Page 40: Picture 5/6 Screen

    Camera menu items (continued) Picture 5/6 screen Picture 6/6 screen P i c t u re 5/ 6 P ic tu r e 6/ 6 G a m m a M o d e N orm al Kn ee Mo de Au t o G a m m a 0.

  • Page 41: Matrix 1/5 Screen

    Normal Standard preset matrix setting. Adjust the saturation and hue. Professional Preset matrix setting equivalent to Panasonic Saturation [–63 to +63] broadcasting devices. Adjust the saturation for each color. User On the [Matrix 2/5] screen, the [Linear Matrix] value can be adjusted by the user.

  • Page 42: Matrix 4/5 Screen

    Camera menu items (continued) Matrix 4/5 screen Matrix 5/5 screen M a t r ix 4/5 M a t r i x 5 / 5 [Col or Cor rectio n 2/3] [ C o l o r C o r r e c t i o n 3 / 3 ] S atur ation Phase S a t u r a t i o n...

  • Page 43: Lens Screen

    Camera menu items (continued) Digital Extender [Off, ×1.4, ×2.0] Lens screen Make settings for the digital extender function. Turn the digital extender function off. L e n s ×1.4 The digital zoom will be fixed at 1.4×. F o c u s M o d e Au to ×2.0 The digital zoom will be fixed at 2.0×.

  • Page 44: System 1/3 Screen

    Camera menu items (continued) System 1/3 screen <NOTE> • When [UHD Crop] is changed, IP video transmission is temporarily stopped. S y s t e m 1 /3 • When [UHD Crop] is changed from [Off] to [Crop(1080)], the [Format] of [Output] for each of the 12G SDI OUT, 3G SDI OUT F r e q u e n c y 5 9.94Hz connectors changes to FHD (1920×1080).

  • Page 45: System 2/3 Screen

    Camera menu items (continued) IP [Off, On] System 2/3 screen Sets the UDP output function On/Off to output tracking data, such as Pan/Tilt/Zoom or other information from the IP output, synchronized S y s t e m 2 /3 with the Genlock signal. (→ page 48) <NOTE>...

  • Page 46: System 3/3 Screen

    Camera menu items (continued) „ System 3/3 screen Changing the frequency When the currently selected frequency is changed in the [System 1/3] screen, the pre-frequency-change confirmation screen appears. S y s t e m 3 / 3 Pre-frequency-change confirmation screen H o u s i n g F a n 1 F re qu e nc y...
  • Page 47 Camera menu items (continued) „ „ Changing the format Tracking data output When the currently selected format is changed in the [System 1/3] When [Serial] or [IP] of [Tracking Data Output] on the [System 2/3] screen, the pre-format-change confirmation screen appears. screen is set to [On], outputs the tracking data for Pan/Tilt/Zoom or other information to link with a virtual studio system or elsewhere via serial (RS-422) or IP output.
  • Page 48 Camera menu items (continued) z IP output Camera Focus Stores the value of focus position of this unit between 000555h • When [IP] of [Tracking Data Output] on the [System 2/3] screen is (NEAR) and 000FFFh (FAR). set to [On], the tracking data for Pan/Tilt/Zoom or other information is synchronized with the Genlock signal and outputs UDP packets via IP.

  • Page 49: Output 1/3 Screen

    Camera menu items (continued) 3G SDI Out [LevelA, LevelB] Output 1/3 screen When [Format] (12G SDI) is [1080/59.94p] or [1080/50p], select the format for outputting 3G SDI signals. O u t p u t 1 /3 LevelA Level A format LevelB Level B format 1 2 G S D I / O P T IC AL...

  • Page 50: Output 2/3 Screen

    Camera menu items (continued) Output 2/3 screen Output 3/3 screen O u t p u t 2 / 3 O u tp ut 3/ 3 B a r C ame ra OS D M ix /C r op M ar k er C o l o r B a r T yp e Typ e2 12 G S DI / OP TI CA L...
  • Page 51 Camera menu items (continued) Timecode Overwrap [Off, UR, BR, BL, UL] Select the area on the OSD to display the timecode (time and date information). Do not display the timecode on the OSD. Display the timecode in the top right area. Display the timecode in the bottom right area.
  • Page 52 Camera menu items (continued) • When [3G SDI Out], [NDI Out], or [IP Out1], and [IP Out2] on the „ Exclusive conditions for [OSD Mix/Crop [UHD Crop 1/2] screen are set to [Crop] Marker] [OSD Mix/Crop Marker] of the relevant connector is constantly set The following exclusive conditions exist for Off/On setting of each output to Off and displayed as “---”...

  • Page 53: Uhd Crop 1/2 Screen

    Camera menu items (continued) UHD Crop 1/2 screen UHD Crop 2/2 screen U H D C r o p 1 /2 U H D Cr o p 2/ 2 3 G S D I O u t Cr op Cr op Ou t N D I O u t Cr op Cr op Ad ju s t...
  • Page 54 Camera menu items (continued) Crop Zoom Ratio [120.00% to 500.00%] „ The CROP function Specifies the size of the crop frame when [Crop Zoom] is [On]. When [UHD Crop] is set to [Crop(1080)] or [Crop(720)], it is possible The crop zoom ratio can be specified between the range of 120.00% to output images cropped from UHD signals from the 3G SDI OUT and to 500.00%, and the grain-size can be set in units of 10.00% from the LAN connectors.

  • Page 55: Pan/Tilt 1/2 Screen

    Camera menu items (continued) Focus Adjust With PTZ. [Off, On] Pan/Tilt 1/2 screen Off/On is set here for the function which compensates for out-of- focusing when it occurs during panning, tilting or zooming operations. P a n / T i lt 1/ 2 When [Off] is set, adjust the focus as required after zooming or set [Focus Mode] to [Auto].

  • Page 56: P/T Acceleration Screen

    Camera menu items (continued) Fall S-Curve [0 to 30] P/T Acceleration screen Sets the S-curve for pan/tilt deceleration operation in 31 steps. (The S becomes stronger, the greater the number) P / T A cc e le rat ion When it is necessary to reduce the speed to the specified speed using manual control of pan/tilt by lever operation etc.

  • Page 57: Preset 1/2 Screen

    Camera menu items (continued) Preset Crop [Off, On] Preset 1/2 screen When the preset memory is played back, set whether the reproduction of content set in the various [UHD Crop] menus is Off/ P r e s e t 1 /2 When set to [On], the content set in the various [UHD Crop] menus is P r e s e t S p e e d Un it S pee d Tab le...

  • Page 58: Preset 2/2 Screen

    Camera menu items (continued) Preset 2/2 screen P r e s e t 2 / 2 P r e s e t I r is O ff P r e s e t Z o om Mo de M ode A P r e s e t S h ut t er F r e e z e D u ri n g Pre set O ff...

  • Page 59: Preset Acceleration Screen

    Camera menu items (continued) Fall Acceleration [1 to 255] Preset Acceleration screen Sets the deceleration speed for pan/tilt deceleration operation in 255 steps. (The deceleration speed increases as the number increases) P r e s e t A cc ele rat ion During the deceleration operation for operating at the specified speed or time during pan/tilt operations by preset playback, the deceleration P r e s e t A c ce l er ati on...
  • Page 60 Camera menu items (continued) The relationships between the various setting values when [Preset Acceleration] is set to [Manual] „ during preset playback z When [Preset Speed Unit] is [Speed Table] It is possible to specify the responsiveness (maximum speed, acceleration rate, S-curve steps) for operation. <NOTE>...

  • Page 61: Maintenance Screen

    Camera menu items (continued) Maintenance screen Firmware Version 2/2 screen M a i n t e n a nc e F ir mw a re V er s io n 2 /2 F i r m w a r e V e rs io n EE PR O M I P N e t w o r k M ai n /N et w or k...

  • Page 62: Initialize Screen

    Camera menu items (continued) Concerning initialization „ Initialize screen When any one of [All/Scene All/Full Auto/Scene1/Scene2/Scene3] is selected on the [Initialize] screen, the Initialize confirmation screen is I n i t i al i ze displayed. A l l Initialize confirmation screen S c e n e A l l F u l l A u t o In it i al iz e...

  • Page 63: Hour Meter Screen

    Camera menu items (continued) Fan1 [No Error, Error] Hour Meter screen This displays the error status of the fan 1. No Error The fan is operating normally. H o u r M e te r Error A fan error has occurred. O p e r a t i o n 0 00 000 00 F a n 1...

  • Page 64: Camera Menu Item Table

    Camera menu item table Camera menu Item Factory setting Selection items Top Menu Camera Scene Scene Full Auto Full Auto, Scene1, Scene2, Scene3 (The factory settings differ for each Scene In [Full Auto] [Scene1] [Scene2] [Scene3] mode) mode mode mode mode Brightness Brightness Picture Level...
  • Page 65 Camera menu item table (continued) Camera menu Item Factory setting Selection items Top Menu Camera Scene (The factory settings differ for each Scene In [Full Auto] [Scene1] [Scene2] [Scene3] mode) mode mode mode mode Picture Picture 1/6 White Balance Mode AWB A ATW, AWB A, AWB B, 3200K, 5600K, Color Temperature...
  • Page 66 Camera menu item table (continued) Camera menu Item Factory setting Selection items Top Menu Camera Scene (The factory settings differ for each Scene In [Full Auto] [Scene1] [Scene2] [Scene3] mode) mode mode mode mode Matrix Matrix 3/5 B_Mg Saturation –63 to +63 B_Mg Phase –63 to +63 Mg Saturation...
  • Page 67 Camera menu item table (continued) Camera menu Item Factory setting Selection items Top Menu Output Output 1/3 12G SDI/OPTICAL [System Format] [12G SDI] Format 2160/59.94p or 2160/50p 2160/59.94p 2160/59.94p 1080/59.94p 2160/29.97p 2160/29.97p 1080/29.97p 1080/59.94p 1080/59.94p 1080/59.94i 1080/59.94i 1080/29.97p 1080/29.97p 1080/29.97PsF 1080/29.97PsF  ...
  • Page 68 Camera menu item table (continued) Camera menu Item Factory setting Selection items Top Menu Output Output 3/3 OSD Mix/Crop Marker 12G SDI/OPTICAL Off, On 3G SDI Off, On Off, On IP/NDI|HX Off, On OSD Off With R-Tally Off, On OSD Status Off, On Timecode Overwrap Off, UR, BR, BL, UL...
  • Page 69 Camera menu item table (continued) Camera menu Item Factory setting Selection items Top Menu Maintenance Firmware Version Firmware System Version Version at shipping - - - CPU Software Version Main/Network Version at shipping - - - Camera Version at shipping - - - Lens Version at shipping...

  • Page 70: Displaying The Web Screen

    Displaying the web screen With a personal computer connected to the unit, it is possible to view the Displaying the web screen using a personal camera’s IP videos or select various settings from the web browser. computer The LAN crossover cable is used when connecting a personal computer The procedure is explained here using Windows screens (Microsoft directly to the unit’s LAN connector for IP control, and the LAN straight Edge (IE mode)).
  • Page 71 Displaying the web screen (continued) Display the live screen [Live]. Set the initial account. In the initial state, the initial account setting screen is displayed when The web screen appears. The live screen [Live] (→ page 73) is displayed initially. You the web screen is displayed.

  • Page 72: Switching Between The Live Screen [Live] And Web Setup Screen [Setup]

    Displaying the web screen (continued) Switching between the Live screen [Live] and Logging into the Web screen Web setup screen [Setup] When user authentication is enabled When displaying the live screen [Live] When the live screen [Live] You need to enter account information for a user with Camera control displayed, click the [Setup] button at the top of the or Administrator privileges.

  • Page 73: Web Screen Operations

    Web screen operations Live screen [Live] You can display images from the camera on a personal computer and perform camera operations, such as pan, tilt, zoom, and focus control. The items displayed on the screen will differ depending on whether the [H.264] or [JPEG] button is selected under [Compression]. When [H.264] is selected Operation screen display buttons (for touch Expansion panel display button...
  • Page 74 Web screen operations (continued) Menu switching [Stream Menu]/[Other Menu] OSD Menu Operation [OSD Menu] Switch between menu displays. Use this to select whether the camera’s on- Clicking [Other Menu] when the Stream menu is displayed displays screen displays are to be shown. [ON] [OFF] the Other menu.
  • Page 75 Web screen operations (continued) Operation lock button [Lock] <NOTE> • AW-UR100 does not have tally lamps, but control by commands is This prevents erroneous operation by locking possible. The effects are reflected only in Web UI and in the status operations such as pan/tilt, zoom, focus, iris, gain, of peripheral equipment.
  • Page 76 Web screen operations (continued) Focus [Focus] Preset [Preset] When a preset thumbnail is clicked, the camera [Far]: Use this to adjust the focus in the “Far” moves to face towards a preset position that was direction. It does not work during automatic registered beforehand.
  • Page 77 Web screen operations (continued) Snapshot button Button for switching the personal computer screen Display the screen for mobile terminals. Capture a snapshot (single still image), and display it in a For details, refer to “Displaying the web screen using a separate window.

  • Page 78: Web Screen Configurations

    Web screen configurations Web setup screen [Setup] The settings for the unit are selected on this screen. <NOTE> • The setting menu operations can be performed only by users whose access level is “1.Administrator”. For the procedure used to set the access level, refer to page 113. •...

  • Page 79: Setting Status Screen [Setting Status]

    Web screen configurations (continued) Collaboration capability [Linkage] Setting status screen [Setting status] Tracking data output setting button [Tracking Data Output] The tracking data output setting screen [Tracking Data Output] is displayed when the button is clicked. → “Tracking data output settings screen [Tracking Data Output]” (→...

  • Page 80: Basic Screen [Basic]

    Web screen configurations (continued) z Frequency Basic screen [Basic] „ System screen [System] z System status Frequency [59.94Hz, 50Hz, 24Hz, 23.98Hz] This item is selected to switch the frame frequency. The setting is confirmed with the [Set] button. Factory settings: 59.94Hz or 50Hz <NOTE>...
  • Page 81 Web screen configurations (continued) z Housing z Output Fan1/Fan2 [Auto, On] Set the operation of the cooling fan. Auto Enable automatic control of the cooling fan. Make the cooling fan operate. Factory settings: Auto <NOTE> • The cooling fan may be forcibly stopped at low temperatures even if this is set to [On].
  • Page 82 Web screen configurations (continued) 3G SDI 12G SDI/OPTICAL Make the settings for output from the 12G SDI OUT connector. Make the settings for output from the 3G SDI OUT connector. Format Format Set the output format. Set the output format. The following format settings are possible depending on the [Format] The following format settings are possible depending on the [Format] setting in the [System] screen.
  • Page 83 When the red tally signal releases, the camera menu display will return. Factory settings: Off <NOTE> • AW-UR100 does not have tally lamps, but control by commands is possible. The effects are reflected only in Web UI and in the status of peripheral equipment. OSD Status [Off, On] Turn the status display during AWB and ABB Off/On, or error display when an error occurs.
  • Page 84 Web screen configurations (continued) z Pan/Tilt Install Position [Desktop, Hanging] The setting is confirmed with the [Set] button. [Desktop] or [Hanging] is selected here as the method used to install the unit. Desktop Stand-alone installation Hanging Suspended installation Factory settings: Desktop <NOTE>...
  • Page 85 Web screen configurations (continued) Fall Acceleration [1 to 255] P/T Speed Mode [Normal(60deg/s), Fast1(90deg/s), Fast2(180deg/s)] Sets the deceleration speed for pan/tilt deceleration operation in 255 steps. (The deceleration speed increases as the number increases) Set the speed of pan/tilt operation. When it is necessary to reduce the speed to the specified speed Normal(60deg/s) Pan/tilt operates at normal speed (maximum about...
  • Page 86 Web screen configurations (continued) Live page screen [Live page] „ „ Date & time screen [Date&Time] Make clock settings. You can set using one of three types [PC Synchronization], [NTP], or [Manual]. Auto Camera title PC Synchronization Input the name of the camera here. If you click the [Execute] button, the settings are configured by When the [Set] button is clicked, the input name appears in the synchronizing the unit to the date and time of the connected personal...

  • Page 87: Image Screen [Image/Audio]

    Web screen configurations (continued) z Streaming mode Image screen [Image/Audio] It is possible to perform IP transmission operations suited to the IP video settings screen [Video over IP] „ application by switching the [Streaming mode] on this unit. The setting is confirmed with the [Set] button. The JPEG image and H.264 image settings as well as the settings related to image quality are selected on this screen.
  • Page 88 Web screen configurations (continued) z Initial display setting z JPEG Set initial display settings for the Live screen [Live]. Set JPEG image settings. The setting is confirmed with the [Set] button. The setting is confirmed with the [Set] button. There are a total of 3 channels available for JPEG image setting. Stream [H.264(1), H.264(2), H.264(3), H.264(4), JPEG(1), JPEG(2), JPEG(3)] Select the type of images to display in the Live screen [Live].
  • Page 89 Web screen configurations (continued) Refresh interval [1fps, 4fps, 5fps, 12fps, 12.5fps, 15fps, <NOTE> 24fps, 25fps, 30fps] • On browsers other than Microsoft Edge (IE mode), only JPEG images can be displayed. Select the frame rate for JPEG images. • Only [H.264(1)] can be set when the [Streaming mode] is 59.94Hz 1fps/5fps/15fps/30fps [H.264(UHD)].
  • Page 90 Web screen configurations (continued) Image capture size [3840×2160, 1920×1080, 1280×720, Max bit rate(per client) 640×360, 320×180] [512kbps, 768kbps, 1024kbps, 1536kbps, 2048kbps, 3072kbps, 4096kbps, 6144kbps, 8192kbps, 10240kbps, Select the resolution for H.264 images. 12288kbps, 12800kbps, 14336kbps, 16384kbps, 20480kbps, Selectable options will vary depending on the selected resolution setting.
  • Page 91 Web screen configurations (continued) Unicast port(Image) [1024 to 50000] z H.265 Enter the unicast port number (used when sending images from the Set H.265 image settings. unit). The setting is confirmed with the [Set] button. Only even numbers can be specified. The port number cannot be set to 10670.
  • Page 92 Web screen configurations (continued) Frame rate [24fps, 25fps, 30fps, 50fps, 60fps] z RTMP Set the frame rate for H.265 images. Make RTMP/RTMPS transmission settings. 59.94Hz 30fps, 60fps Server setup 50Hz 25fps, 50fps The setting is confirmed with the [Set] button. 24/23.98Hz 24fps Factory settings:...
  • Page 93 Web screen configurations (continued) Streaming format Make settings for H.264 images for use in RTMP/RTMPS transmission. The setting is confirmed with the [Set] button. Refer to the explanation for H.264 (→ page 89) for information about Image capture size, Frame rate and Max bit rate(per client). <NOTE>...
  • Page 94 Web screen configurations (continued) z SRT Destination IP address(IPv4) When [Client(Caller)] is set in [Mode], enter the IP address. Make SRT transmission settings. Images and audio will be sent to the specified IP address. <NOTE> Factory settings: 192.168.0.3 • When starting SRT transmissions in the [Listener] mode, set the <NOTE>...
  • Page 95 Web screen configurations (continued) Multicast address(IPv4) Streaming format Sets the Multicast address used for MPEG2-TS over UDP Makes settings for H.264 or H.265 images for use in SRT transmission. transmission. Specify this IP address on the receiving application or service. The setting is confirmed with the [Set] button.
  • Page 96 Web screen configurations (continued) Subnet(IPv4) z NDI|HX V2 Enter the subnet mask. Make NDI|HX V2 transmission settings. Factory settings: 244.0.0.0 The setting is confirmed with the [Set] button. <NOTE> • [Address (IPv4)] and [Subnet (IPv4)] clarify the multicast address NDI|HX V2 ranges randomly set during multicast transmissions.
  • Page 97 Web screen configurations (continued) Subnet(IPv4) z High bandwidth NDI Enter the subnet mask. Make NDI transmission settings. Factory settings: 224.0.0.0 The setting is confirmed with the [Set] button. <NOTE> High bandwidth NDI • Address(IPv4) and Subnet(IPv4) clarify the multicast address ranges randomly selected during multicast transmissions.
  • Page 98 Web screen configurations (continued) Audio bit rate [64kbps, 96kbps, 128kbps] z Audio The setting is confirmed with the [Set] button. Set the bit rate for transmitting audio. Factory settings: 128kbps Image adjust screen [Image adjust] „ Adjust the image quality. The settings in this screen (with the exception of [Scene] and [Matrix]) are applied immediately.
  • Page 99 Web screen configurations (continued) Auto Iris Speed [Slow, Normal, Fast] z Brightness Set the control speed of the auto iris function. Slow Control the iris at a slow speed. Normal Control the iris at a normal speed. Fast Control the iris at a fast speed. Factory settings: Normal Auto Iris Window [Normal1, Normal2, Center] Select the detection window for the auto iris.
  • Page 100 Web screen configurations (continued) ND Filter [Through, 1/4, 1/16, 1/64, Auto] ELC Limit [1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000] Set the maximum shutter level when ELC is operating. Set the transmittance of the lens' built-in ND (neutral density) filter. Factory settings: Refer to the “Camera menu item table”. The filter switches when the setting is fixed.
  • Page 101 Web screen configurations (continued) z Picture White Balance Mode [ATW, AWB A, AWB B, 3200K, 5600K, VAR] Set the white balance mode. Select the mode when the coloring is not natural because of the nature of the light source or other factors. If the white color serving as the reference can be recognized, subjects can be shot with natural coloring.
  • Page 102 Web screen configurations (continued) Detail [Off, On] AWB Gain Offset [Off, On] When auto white balance is performed by setting [White Balance Turn on/off the contour (sharpness of images) adjustment of images. Mode] to [AWB A] or [AWB B], set the values for Rch gain and Bch Factory settings: On gain.
  • Page 103 Web screen configurations (continued) Gamma Mode [HD, FILMLIKE1, FILMLIKE2, FILMLIKE3] White Clip [Off, On] Select the type of gamma curve. Turn the white clip function off/on. Factory settings: On HD (High Definition) video gamma characteristic. FILMLIKE1 Characteristic capable of reproducing better gradation in White Clip Level [90% to 109%] highlights than HD gamma.
  • Page 104 Select the type of color matrix. The setting is confirmed with the [Set] button. Normal Standard preset matrix setting. Professional Preset matrix setting equivalent to Panasonic broadcasting devices. User On the [Matrix 2/5] screen, the [Linear Matrix] value can be adjusted by the user.
  • Page 105 Web screen configurations (continued) „ Lens setting screen [Lens] Max Digital Zoom [×2, ×3, ×4, ×5, ×6, ×7, ×8, ×9, ×10] The setting is confirmed with the [Set] button. Set the maximum digital zoom magnification. This is only enabled when [Zoom Mode] is set to [D.Zoom]. Factory settings: ×10 <NOTE>...
  • Page 106 Web screen configurations (continued) UHD crop setting screen [UHD Crop] „ <NOTE> • When [Crop Mode] is changed, IP video transmission is temporarily stopped. • When [Crop Mode] is changed from [Off] to [Crop(1080)], the [Format] of [Output] for each of the 12G SDI OUT, 3G SDI OUT connectors changes to FHD (1920×1080).
  • Page 107 Web screen configurations (continued) 3G SDI Out [Crop, FULL] Crop Output Select [Yellow, Green, Magenta] Make the settings for Crop/FULL for images output to the 3G SDI Make the settings for the crop frame for images output to the 3G SDI OUT connector.
  • Page 108 Web screen configurations (continued) Preset position screen [Preset position] „ z Preset The setting is confirmed with the [SET] button. When a preset thumbnail is clicked, the camera moves to face towards a preset position that was registered beforehand. You can select Home and Preset001 to Preset100. Preset numbers are displayed in green when they have had a preset position registered in them.
  • Page 109 Web screen configurations (continued) Rise S-Curve [0 to 30] z Pan/Tilt Lens Control Sets the S-curve for pan/tilt acceleration operation in 31 steps. (The S This is used for camera control. The same operations are possible becomes stronger, the greater the number) as with the camera controller operated in the live screen [Live].
  • Page 110 Web screen configurations (continued) Fall Ramp Time [0.1s to 10.0s] <NOTE> Sets the deceleration time for time specified operations during preset • When the IP for [OSD Mix/Crop Marker] is [On], the menu screen is playback. (Sets between 0.1s to 10.0s in 0.1s increments) included in the thumbnails.

  • Page 111: Collaboration Capability [Linkage]

    Web screen configurations (continued) - After switching [Matrix Type] Collaboration capability [Linkage] - After switching [Focus Mode] „ - After switching [Zoom Mode] Tracking data output settings screen [Tracking - After switching [Max Digital Zoom] Data Output] - After switching [Digital Extender] Select the output mode of the tracking data and the communication - After switching [Fan] destination in the IP mode.
  • Page 112 Web screen configurations (continued) z IP out Port Sets the destination port number to forward the tracking data such as Pan/Tilt/Zoom or other information via UDP. The setting is confirmed with the [Set] button. The following port numbers are used by the unit so they cannot be used.

  • Page 113: User Management Screen [User Mng.]

    Wait time mode [Mode1, Mode2] Set the wait time mode for re-entry of user authentication after authentication fails when operating the unit from a personal computer or a Panasonic controller. Mode1 The wait time for re-entry is longer compared to Mode2.

  • Page 114: Delete Host

    Web screen configurations (continued) Host authentication screen [Host auth.] „ z Add host Click the [Host auth.] of User management screen [User mng.]. Configure the host authentication settings that restrict the personal computers (IP addresses) that can access the unit. z Setting status IP address The IP address of the personal computer from which access to the...

  • Page 115: Network Setup Screen [Network]

    Web screen configurations (continued) z IPv4 network Network setup screen [Network] DHCP [On, Off] Configure network settings in the Network setup screen. The Network setup screen [Network] consists of [Network] and Select the method in which the IP address is configured. [Advanced].
  • Page 116 Web screen configurations (continued) z Common (to IPv6/IPv4) z IPv6 network Manual [On, Off] HTTP port [1 to 65535] Enable or disable manual configuration of the IPv6 address. Port numbers are allocated separately. The following port numbers are used by the unit so they cannot be Enter the IPv6 address manually.
  • Page 117 Web screen configurations (continued) Easy IP Setup accommodate period Recommended network setting for internet [20min, Unlimited] Perform the recommended settings to connect the camera to the Internet. Select [20min] or [Unlimited] as the time for enabling the operation of When the [Execute] button is clicked, a dialog box will be displayed. the network settings from the Easy IP Setup Software.
  • Page 118 Web screen configurations (continued) „ When “Streaming mode” is set to “JPEG(UHD)” Advanced network setting screen [Advanced] JPEG(1) Click the [Advanced] in the network setup screen [Network]. Refresh interval: 1fps Settings relating to the NTP, UPnP and HTTPS functions are performed Image quality: Normal here.
  • Page 119 Web screen configurations (continued) z NTP z UPnP Settings relating to the NTP server address and port No. are performed This unit supports UPnP (Universal Plug and Play). Using the UPnP here. function allows the following to be set automatically. The setting is confirmed with the [Set] button.
  • Page 120 Web screen configurations (continued) z HTTPS CA Certificate - Information Using the HTTPS function enables access to the camera to be This displays information relating to the server certificate (security encrypted and communication safety to be improved. certificate). The setting is confirmed with the [Set] button. When the [Confirm] button is clicked, the registered content of the See page 123 for details on the HTTPS setup method.
  • Page 121 Web screen configurations (continued) z RTSP z SNMP This performs settings related to the RTSP function. The RTSP function Make SNMP functionality related settings. You can check the status of sets the RTSP transmission port and RTSP request URL used during IP the unit by using the SNMP manager to connect.
  • Page 122 Characters that can Alphanumeric characters, symbols : - Enter the email address or phone number of the administrator. be entered Maximum number Factory settings: panasonic-ptz 0 to 255 characters of characters <NOTE> Characters that • Proper operation cannot be guaranteed if there is another camera with...
  • Page 123 Web screen configurations (continued) HTTPS settings [HTTPS] „ This encrypts access to the camera and sets HTTPS to improve communication safety. Setting HTTPS is performed by following the procedures below. The setting is confirmed with the [Set] button. 1. Generating a CRT key (SSL encryption key) (→...
  • Page 124 Web screen configurations (continued) „ „ Generating a CRT key (SSL encryption key) Generating a self-signed certificate (security [CRT key generate] certificate) [Self-signed Certificate - Generate] <NOTE> • A CRT key cannot be generated when self-signed certificates and <NOTE> server certificates are enabled. •...
  • Page 125 Web screen configurations (continued) Click the [OK] button after inputting the address. Click the [Execute] button in [CA Certificate - Generate Certificate Signing Request]. A self-signed certificate is generated. <NOTE> The [CA Certificate - Generate Certificate Signing Request] dialog is •...
  • Page 126 Web screen configurations (continued) „ „ Installing a Server Certificate Setting the Connection Method [CA Certificate - CA Certificate install] [Connection] <NOTE> Set the method to access the camera in [Connection]. • A server certificate (security certificate) cannot be installed if a Certificate Signing Request (CSR) has not been generated.

  • Page 127: Install The Security Certificate

    Web screen configurations (continued) Click [Certificate error] in the URL and then click [View z Install the security certificate certificates]. When using HTTPS to access the camera, the security warning screen will be displayed if the security certificate of the said camera has not been installed in your personal computer.
  • Page 128 Web screen configurations (continued) Select [Place all certificates in the following store] and Click [Finish]. click [Browse...]. Click [Yes]. Select [Trusted Root Certification Authorities] and click [OK]. Click [Next]. When importing is finished, the “The import was successful.” screen is displayed. Click [OK].

  • Page 129: Maintenance Screen [Maintenance]

    Web screen configurations (continued) [Error log1, Error log2] Maintenance screen [Maintenance] On this screen, you can check the system logs, check the version of the Displays the log sequence numbers. software, initialize the unit, etc. “1” indicates the latest information, and up to 100 logs can be saved. The Maintenance screen consists of four settings: [System log], [Product info.], [Default reset] and [Backup].
  • Page 130 • Before using the version upgrading software, be absolutely sure to check the precautions to be observed, and follow the instructions. • Use the following files specified by Panasonic Connect Co., Ltd. as the software used for version upgrading. UPDATE.HDC •...
  • Page 131 Web screen configurations (continued) „ Back up screen [Backup] Upload Config data type On this screen, the unit’s settings can be saved to a personal computer [Camera(ALL), Camera (SCENE1) to Camera (SCENE3), Camera or settings saved in a personal computer can be loaded into the unit for (SCENE Full Auto), Camera (SYSTEM), Camera (PRESET), use.

  • Page 132: Displaying The Web Screen Using A Personal Computer Equipped With A Touch Panel

    Displaying the web screen using a personal computer equipped with a touch panel „ PTZ operation screen for touch panels Button for displaying the PTZ operation screen for touch Button for restoring the screen from the touch panel panels operation screen The screen switches to the one for PTZ operations for touch panels Press this button to return to the usual live screen.
  • Page 133 Displaying the web screen using a personal computer equipped with a touch panel (continued) „ „ Preset operation screen for touch panels Image adjust operation screen for touch panels Preset operation area for touch panels Image adjust operation area for touch panels This is the area where buttons for preset operations are located that This is the area where buttons for iris, gain, balance adjustments, are suitable for use with touch panels.

  • Page 134: Displaying The Web Screen Using A Mobile Terminal

    Displaying the web screen using a mobile terminal It is possible to perform operations using a design suited to mobile terminals in the live screen in a web browser. Access the unit from the mobile terminal. As when accessing the unit from a personal computer, enter [http://IP address/] in the address bar of the web browser on the mobile terminal. The screen for mobile terminals is displayed automatically.
  • Page 135 Displaying the web screen using a mobile terminal (continued) Button for displaying the operation menu for the live Home button Move to the preset home position. screen Use this to display the operation menu for the live screen. Preset thumbnail operation area When a preset thumbnail is clicked, the camera moves to face towards a preset position that was registered beforehand.

  • Page 136: Limiters

    Limiters Safe mode (The status display lamp lights red) This unit comes with settings (referred to as “limiters”) that restrict the Concerning the safe mode panning and tilting movement ranges. The unit goes into the safe mode when the pan-tilt head is forcibly moved by an external force or when something impedes its rotation.

  • Page 137: Troubleshooting

    – – – → For details on upgrading, visit the support page on the following website. https://pro-av.panasonic.net/en/ • Has the stand-alone (Desktop) installation setting been selected correctly? page 55, page 84 The unit turns in the •...
  • Page 138 Troubleshooting (continued) Symptom Cause and solution Reference pages • Has a LAN cable of category 5e or above been connected to the LAN connector for IP Installation Instructions → “Connections” control <LAN LINK/ACT>? • Is the [LINK] LED of the LAN connector for IP control lit? →...
  • Page 139 Troubleshooting (continued) Symptom Cause and solution Reference pages For Windows: • Press the [F5] key on the keyboard of the personal computer to request that the settings be acquired. – – – For Mac: • Press the [Command] + [R] key on the personal computer's keyboard to request that the settings be acquired.
  • Page 140 Troubleshooting (continued) „ Video Symptom Cause and solution Reference pages Installation Instructions → “Connections” • Has the unit been connected properly to the other connected devices? • If the system is configured in such a way that the picture is also switched page 26 No pictures are when the unit to be operated is selected, has the correct unit been selected?
  • Page 141 Troubleshooting (continued) Symptom Cause and solution Reference pages The brightness • These phenomena (flicker) may occur under the illumination produced by changes cyclically or fluorescent lighting, mercury bulbs or other types of discharge tubes. In such the colors change, cases, we recommend setting the electronic shutter speed to 1/100 in regions –...
  • Page 142 Troubleshooting (continued) „ IP images Symptom Cause and solution Reference pages For Windows: Images are not displayed • Is the plug-in viewer software installed? page 24 → Install the plug-in viewer software. • Is the focus properly adjusted? The images are blurry –...
  • Page 143 Troubleshooting (continued) Symptom Cause and solution Reference pages For Windows: • This may occur depending on the combination of the personal computer's display adaptor and the driver. → If this occurs, update the first display adaptor to the latest version. If this does not resolve the problem, adjust the hardware accelerator When multiple web browsers function as follows.
  • Page 144 "This website wants to run the • Select [Allow]. – – – following add-on: 'WebVideo Module' from 'Panasonic System Networks Co., Ltd.'." The following message appears in the information bar. "This website wants to • Select [Install]. When the security warning window appears, click the –...

  • Page 145: Specifications

    Specifications Electronic shutter speed: Power requirements: • 59.94p/59.94i mode 12 V to 21.8 V DC (10.8 V to 24.0 V) 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 42 V to 57 V DC (PoE++ power supply) 1/4000, 1/8000, 1/10000 Current consumption: •...
  • Page 146 Specifications (continued) „ „ Input connector Pan-tilt head unit DC IN 12 V Installation method: G/L IN: BBS (Black Burst Sync), tri-level sync supported Stand-alone (Desktop) or suspended (Hanging) „ Pan/tilt operation speed: Output connector Speed range: 0.08°/s to 60°/s (Normal mode) 3 speed modes installed SFP+: Conforms with SFP+ (Single Fiber)

  • Page 147: Index

    Index Numerics ×1.0 button ..................CA Certificate 3G SDI ..............CA Certificate install ............3G SDI Out ..............Generate Certificate Signing Request ......3G SDI OUT connector ............... Information ................12G SDI/OPTICAL ..........Camera ................12G SDI OUT connector ..............Camera Control .................
  • Page 148 Index (continued) DNS ....................Horizontal phase adjustment ............... Download ................... Host auth................... Drop-prevention wire attachment hole ..........Host IP address ................. DRS .................... Hour Meter ..................Housing ................. HTTP max segment size (MSS) ............HTTP port ..................Easy IP Setup accommodate period ..........HTTP Port number ................
  • Page 149 Index (continued) Linkage ....................Picture ............Live ....................Picture Level ................. Live page ..................... Plain text usage ................. Location ..................... Plugin Power ..................Lock ..................... Plug-in viewer software ............... Logic ................... Port ....................Power ....................Power ON .................... Power On Position ................ MAC address ..................
  • Page 150 Index (continued) Self-signed Certificate Upload ....................Generate ................UPnP ....................Information ................URL ..................... Serial ..................URL type ....................Use discovery server ..............Serial no.................... User auth................... Server address(IPv4) ..............Server setup ..................User ID ....................Server URL ..................User mng.
  • Page 151 MEMO...
  • Page 152 Panasonic Connect Co., Ltd. Web Site: https://pro-av.panasonic.net/en/ © Panasonic Connect Co., Ltd. 2023...

This manual is also suitable for:

Aw-ur100gj

Table of Contents
