Mami GiSMo-GA mini Manual

21 Hubert Mathew Road, Illiondale, 1609
Tel +27 11 452 4737
www.mami.co.za
Description:
The GiSMo G mini is a programmable GSM GPRS/SMS communicator with 4 inputs and 4 outputs
equipped with audio to perform the function of an intercom.
Once an input is triggered it will call a number. If the call is not successfully answered the GiSMo
will call the next number associated with the input.
The inputs are positive trigger.
The outputs can be manually controlled via SMS as well as Missed Call.
ENTRY PANEL
B2
B1
11
12
21
5
M000197
Fax +27 11 452 4738
Wiring for 2 button Intercom
POWER
SUPPLY
12V DC
- +
GiSMo-GA mini
GSM 1-to-1 intercom
0V/GND -
+
12/24V input
Input 1 I1
Input 2 I2
Input 3 I3
Input 4 I4
Output 1 NO O1
Output 1 C O1
O2
Output 2 NO
O2
Output 2 C
O3
Output 3 NO
O3
Output 3 C
O4
Output 4 NO
O4
Output 4 C
11
Microphone input
Speaker output 12
GATE MOTOR
positive trigger
(default)
negative trigger
B1
B2
Relay rating:
1A/30VDC
Micro SIM
GiSMo-GA
Antenna
NB: Place Antenna as far
away from GSM Mod
