Network Video Recorder

User Manual

Model:

PNVR-804

Ver.1.0.0

Table of Contents

Need help?

Do you have a question about the PNVR-804 and is the answer not in the manual?

Questions and answers

Summary of Contents for ENVIO PNVR-804

Page 1 Network Video Recorder User Manual Model: PNVR-804 Ver.1.0.0...
Page 2: Introduction
PNVR-804 Introduction General This quick guide (hereinafter called "manual") introduces you to the functions and use of the NVR device (hereinafter called "NVR"). Safety instructions The following danger indicators may appear within the manual, the meaning of which is defined below.
Page 3 PNVR-804 Graphics and software are subject to change without notice. Product updates may cause differences • between the actual product and the information in the manual. Please contact customer service for updated documentation regarding the program or other aspects. There may also be differences in technical data, descriptions of functions and operations, or printing •...
Page 4: Safety Rules And Important Warnings
PNVR-804 Safety rules and important warnings The following describes how to use the NVR correctly. Read the manual carefully before use to avoid danger or loss of property. Follow the manual strictly during application and keep it after reading. Operational requirements Install PoE cameras indoors.
Page 5: Table Of Contents
PNVR-804 Index Introduction..................................2 Safety rules and important warnings..........................4 1. How to install ENVIO PoE NVR systems......................... 6 2. Initial Settings................................8 3. Access to the system..............................8 3.1 Password setting............................8 4. Setting the time................................11 5.
Page 6: How To Install Envio Poe Nvr Systems
PNVR-804 1. How to install ENVIO PoE NVR systems Turn on the NVR with the 48V /52V power adapter. Connect the NVR to the router. Connect the NVR to the router.. www.enviosecurity.com...
Page 7 PNVR-804 Connect PoE cameras to the NVR with PoE Ethernet cables . Turn on the monitor If your monitor does not have a speaker, you can connect a speaker to the "AUDIO OUT" 3.5mm port, to get audio from the recorded video.
Page 8: Initial Settings
PNVR-804 2. Initial Settings When you first access the system, the device will start to automatically search for all the cameras connected to the POE inputs. The automatic search occurs every time a new camera is connected to the system. The NVR creates a subnetwork of the 172.25.6.xx type, and automatically sets the new IP address on the cameras...
Page 9 PNVR-804 By pressing the “Confirm” button you access the page where you can set the personalized password, as shown in the figure. Once the creation of the personalized password has been completed, it is good practice to also follow the steps described below relating to the creation of the security questions and answers and the choice of the method of receiving the unlock code, in case you forget both the access that security responses.
Page 10 PNVR-804 You will access the user and password modification screen. Subsequently, it will be proposed to set security questions and answers, and the method of receiving the unlock code in case the user forgets the access credentials to the device. See figures below...
Page 11: Setting The Time
PNVR-804 4. Setting the time Please adjust the time and date to match your local time. 5. Net On this page you may see network information about your system. Click "Next" to continue www.enviosecurity.com...
Page 12: Install The Xmeye App
PNVR-804 6. Install the XMeye app Scan the App QR code to download the app. After downloading the app, create your account. Scan the NVR serial number QR code to add it to the app. Make sure the NVR is online before watching its videos on the app.
Page 13: Screen
PNVR-804 8. Screen Adjust your monitor's image display settings 9. General Settings In the General Settings, you can change the language, the action when the memory is full and the automatic disconnection intervals if you want to get better protection of your NVR.
Page 14: Recording Configuration
PNVR-804 10. Recording configuration In the recording setup, you can set the recording mode for each channel to save HDD space and only record important videos. Channel: The channel for which you want to make record configuration settings. Length: The standard length of each video segment.
Page 15: Alarm Settings
PNVR-804 11. Alarm Settings 11.1 Smart alert Al smart security camera system supports intelligent alerts, such as person detection and face detection. To adjust related settings, access "Smart Alert" in the menu "Alarm". Channel: Choose the camera you want to set alerts for.
Page 16: Advanced Human Detection Settings
PNVR-804 11.2 Advanced human detection settings Period: The time period of the detection. • MD Interval: The interval between 2 human motion alerts. • PostRec: to adjust the length of the video after the camera detects anomalous movements. • Tour: Full screen and a cyclic tour are enabled, if set in the screen options. See chapter 8 •...
Page 17: Advanced Face Detection Settings
PNVR-804 11.3 Advanced Face Detection settings Period: The time period of the detection. • MD Interval: The interval between 2 human motion alerts. • PostRec: to adjust the length of the video after the camera detects anomalous movements. • Tour: Full screen and a cyclic tour are enabled, if set in the screen options. See chapter 8 •...
Page 18: How To Set Up Your Email To Receive Alert Notifications
PNVR-804 11.4 How to set up your email to receive alert notifications Follow the paths below to set the email you want to receive alerts about from the system. Right click > Main Menu > Network > Network Service > EMAIL (double click "EMAIL" to enter the setting interface) www.enviosecurity.com...
Page 19 PNVR-804 Enter the required information of your emails in "Username" "Sender" and "Recipient". If you want to receive alert notifications with an email other than the sender's email address, you can enter an email- different email in the "Recipient" section.
Page 20 PNVR-804 Gmail SMTP: smtp-relay.gmail.com Port: 25, 465 or 587 • Encryption: SSL or TLS • Hotmail SMTP: smtp.live.com Port: 25 or 465 • Encryption: SSL or TLS • Outlook SMTP: smtp.of exif ce365.com Port: 587 • Encryption: TLS • Yahoo SMTP: smtp.mail.yahoo.com Port: 465 •...
Page 21 PNVR-804 Enter "App Password". Select the app and device you want to generate app password for, or you can name your app and device, then click "GENERATE". You will receive a 16 digit password, this is the password you need to use later to set up your email notification in the NVR system.
Page 22: Rule - Safe Zone And Line Crossing Alarm
PNVR-804 You are unable to review your password after clicking "DONE", so write it down or leave this page open. 11.5 Rule - Safe zone and line crossing alarm We can set a safe zone for our camera. The camera will only detect or sound an alarm when abnormal activities occur in the safe zone. Click the "Set"...
Page 23 PNVR-804 Choose the shape of the safe zone you want to use. In this user manual, we use the rectangle as an example. Choose the shape of the safe zone you want to use. In this user manual, we use the rectangle as an example.
Page 24: System Anomaly
PNVR-804 When we choose "Tripwire" instead of "Intrusion", there will be a line on the screen, and the camera will only detect or sound an alarm when people cross this line. 11.6 System anomaly www.enviosecurity.com...
Page 25 PNVR-804 In this part, we can set alarm for other events. In the "Event Type", there are several options: No memory: The NVR cannot detect the HDD. • Storage Device Error: The NVR detects that the HDD is not working properly.
Page 26: Traditional Alarm
PNVR-804 11.7 Traditional alarm In this part, we can set alarm for other events. In this part, we can adjust settings for other alarm types. Video Blind: the camera is covered and blinded. • Video Loss: The camera loses connection with the NVR.
Page 27: Video Blind
PNVR-804 11.8 Video Blind Channel: Choose the correct channel whose settings you want to change. • Enable: The main video blind alarm switch. • Sensitivity: Change the sensitivity level of the video blind alarm. • Period: Set the period of time during which you want the video blind alarm to operate.
Page 28: Video Loss
PNVR-804 11.9 Video Loss • Channel: Choose the correct channel whose settings you want to change. • Enable: The main video blind alarm switch. • Sensitivity: Change the sensitivity level of the video blind alarm. • Period: Set the period of time during which you want the video blind alarm to operate.
Page 29: Alarm Input (Devices With I/O Alarms Only)
PNVR-804 11.10 Alarm input (Devices with I/O alarms only) Type: Select the IPC camera if it has an alarm input • Alarm ln: the source of the input alarm. • Enable: The main switch of the alarm input warning. •...
Page 30: Instant Photo Setup
PNVR-804 12. Configurazione foto istantanea In "Configurazione snapshot", possiamo impostare le tue telecamere per scattare istantanee. 12.1 Ciclo di acquisizione Quando scegliamo "Cycle Capture", la fotocamera scatterà periodicamente delle istantanee. Ad esempio, il periodo di istantanea predefinito è 64 secondi, significa che la fotocamera scatterà automaticamente un'istantanea ogni 64 secondi.
Page 31: Timed Acquisition
PNVR-804 12.2 Timed acquisition When we choose "Timing Capture", the camera will take snapshots at the set time. MAIL: When this option is active, the NVR will send the snapshots captured by the cameras to your email address. FTP: Check this option, you have an FTP server. If necessary, configure the server parameters in the network services settings.
Page 32 PNVR-804 There are 6 different playback modes: Common playback: You can review all video records. Example: On May 1st you only have your channel 1 recording video; On May 2, you have your channel 1 and your channel 2 recording video;...
Page 33 PNVR-804 Smart search: you can review the video playback of the selected alarm type within the selected time period. Face Search: you can review the video playback of human faces detected in the selected time period. www.enviosecurity.com...
Page 34: Backup
PNVR-804 13. Backup When your HDD is full and you want to keep your video recordings, you can back up your videos using a USB disk. First of all, insert your USB disk into the USB port of the NVR.
Page 35: Add Cameras
PNVR-804 After choosing video record type, channel and time, click "add", then you will see all eligible video records. Choose the videos you want to back up, then click "Start". All the selected videos will be copied to your USB disk 14.
Page 36: Forgot Password
PNVR-804 Click "Search". Your camera will be shown in the top graph. Click "Add", then the camera will be paired with the NVR. 15. Forgot password If the user forgets their login credentials, they can reset their password using the "Forgot password"...
Page 37: Advanced Settings Of The Xmeye App
PNVR-804 The Security Responses screen will be displayed. Once the answers have been entered, it will be possible to create a new password, as shown in the figure on the page. If the user does not remember the security answers, he can select the "I forgot the security answers"...
Page 38: Device
PNVR-804 Register an account, then log in to the app. Register an account, then log in to the app. 16.1 Device Tap the device and choose active channels to enter the live streaming video interface. www.enviosecurity.com...
Page 39: Menu
PNVR-804 16.2 Menu In the settings menu, we can adjust the camera settings directly via our smartphone. Smart Alarm:activates or deactivates various alarms. www.enviosecurity.com...
Page 40 PNVR-804 User Management: change your password and set security questions. Video Management: Set the video parameters of the cameras. www.enviosecurity.com...
Page 41 PNVR-804 Remote Play:Review your video records stored in the DVR remotely. Video downloads:download videos stored in the NVR to your smartphone. Advanced settings:Check and adjust HDD and network settings. www.enviosecurity.com...
Page 42: Smartphone Storage
PNVR-804 Information on:More product information. 16.3 Smartphone storage In this part we can review the videos and images saved in our smartphone. www.enviosecurity.com...
Page 43: My Account
PNVR-804 17. My account In this part we can change the general settings of the App, send feedback on the App and other additional information. 18.Information on user manuals To manage the device on a PC using software, the software and manuals for the correct operation of the entire system are available on the Enviosecurity website.
Page 44: Cyber Security Recommendations
PNVR-804 Cyber security recommendations Cyber security is not just a buzzword: it is something that has to do with all devices connected to the Internet. IP video surveillance is not immune to cyber risks, but adopting simple measures to protect and strengthen networks and network devices makes them less susceptible to attacks.
Page 45 PNVR-804 Enable the HTTPS protocol It is advisable to activate the HTTPS protocol, so as to be able to access the web service via a secure communication channel. Activate the whitelist It is advisable to activate the whitelist to allow access to the system only from specified IP addresses.
