- Page 1 . t e r m o d i n a m i k . c o m . t r ELECTRIC INVERTER WATER HEATER USER AND INSTALLATION MANUAL TDI-1923-11 kW TDI-1923-24 kW TD-20230510 www.termodinamik.com.tr...
- Page 2 • Read the warnings and information titled Matters needing attention. The device is out of warranty due to installation and electrical connections made without paying atten- tion to the relevant instructions, warnings and information. / termodinamikisitma / Termodinamik Isıtma Sistemleri...
- Page 3 Small children or elderly people can be affected even by low temperatures. For this reason, it is appropriate to set the domestic water temperature at a level where no one will be disturbed. • Do not place objects or other objects on the device. / termodinamikisitma / Termodinamik Isıtma Sistemleri...
- Page 4 • Do not keep any objects, materials or other devices that may damage the device, or that may be damaged by the installation connections of the device, under, above or next to the location where the device is mounted. / termodinamikisitma / Termodinamik Isıtma Sistemleri...
- Page 5 Maintenance opera- tions must be done by Termodinamik Authorized Sales points. • We recommend using original Termodinamik parts during maintenance or repair work. • Have the necessary electrical installation prepared for the combi, but do not connect electricity in any way.
-
Page 6: Technicial Specifications
* Line length must be taken from the meter. * EITY (Electrical Indoor Installation Regulation) should be taken into consideration when planning the use of single-phase devices in homes. * We reserve the right to make changes in dimensions, prices and appearances. / termodinamikisitma / Termodinamik Isıtma Sistemleri... -
Page 7: Electrical Wiring Diagram
- 07 - www.termodinamik.com.tr Kemalpaşa O.S.B Mah. +90 (850) 222 22 35 iletisim@termodinamik.com.tr 80 Sok. No:10 Kemalpaşa/İZMİR H E A T I N G S Y S T E M S Electrical Wiring Diagram / termodinamikisitma / Termodinamik Isıtma Sistemleri... -
Page 8: Notice For Installation
G. Due to the high power of this heater, user's electric meter,wires and fuses should meet the rated current requirement of the heater (please refer to “technical parameters and installation requirements” for more information). / termodinamikisitma / Termodinamik Isıtma Sistemleri... -
Page 9: Installation Methods
2. Air switch installation: Install qualified air switch on the wall. 3. Circuit connection: Connect heater’s main lead successively with air switch’s live wire, neutral wire (L: live wire (brown), N: neutral wire (blue)) and ground wire. / termodinamikisitma / Termodinamik Isıtma Sistemleri... - Page 10 - 10 - www.termodinamik.com.tr Kemalpaşa O.S.B Mah. +90 (850) 222 22 35 iletisim@termodinamik.com.tr 80 Sok. No:10 Kemalpaşa/İZMİR H E A T I N G S Y S T E M S / termodinamikisitma / Termodinamik Isıtma Sistemleri...
-
Page 11: Product Usage
5.2.1 Adjust the water flow valve or the water inlet valve to increase the water flow. 5.2.2 Check whether the water inlet filter Is blocked, clean it if necessary. 5.2.3 Check whether the electricity-proof device or the shower head is blocked, clean it if necessary. / termodinamikisitma / Termodinamik Isıtma Sistemleri... - Page 12 To solve this problem, please adopt the following solutions: 6.2.1. Adjust the water flow valve or the water inlet valve increase the water flow. 6.2.2. Check whether the water inlet filter is blocked, clean it if necessary. / termodinamikisitma / Termodinamik Isıtma Sistemleri...
-
Page 13: Problems And Solutions
7. Power must be cut off before cleaning the heater. Dip the wet cloth in neutral detergent (not in gasoline or other solution) and wipe the heatar gently, then wipe it again with dry cloth. / termodinamikisitma / Termodinamik Isıtma Sistemleri... - Page 14 . t e r m o d i n a m i k . c o m . t r The brand you trust for years... / Termodinamik Isıtma Sistemleri / termodinamikisitma www.termodinamik.com.tr Kemalpaşa O.S.B Mah. +90 (850) 222 22 35 iletisim@termodinamik.com.tr...
- Page 15 55 B. Signify the circuit board is B. Contact the maintenance Alarm E4 damaged department C. Signify a problem of the C. Contact the maintenance temperature prob of the outlet. department / termodinamikisitma / Termodinamik Isıtma Sistemleri...
-
Page 16: Product Packing List
Did not give back part B of the warranty card or gave back part B without the product code. For conditions above, we can only provide paid services. Customers’ requirements for changing products cannot be realized unless products’ appearance and packing have no impact for future selling. / termodinamikisitma / Termodinamik Isıtma Sistemleri...
