user's manual
Introduction
Thank you for purchasing the Shot Navi Evolve PRO Touch. This product features the
largest display available in a wristwatch-style GPS navigator, offering excellent visibility and
equipped with a touchscreen. Its operability during play has been significantly improved,
and the buttons are consolidated on one side, giving it a stylish design.
Additionally, this model introduces a new reverse display function, which allows the screen
to rotate 180 degrees, enabling use on either wrist without being restricted by dominant
hand, adapting to the player's style.
Equipped with the Dynamic Green Eye function, which allows you to easily see the
undulations of the green at a glance, this product is packed with advanced features.
We hope you make full use of this product to improve your score and enhance your playing
speed.
Table of Contents
Before Using
Introduction
o
Table of Contents
o
Safety Instructions
o
Usage Precautions
o
Pedometer
o
List of Contents / Part Names
o
Charging
o
Operating Instructions
o
Clock Mode Operations
o
Power On/Off
o
Main Unit Settings
Main Menu
o
Main Unit Settings
o
Golf Navigation

Advertisement

loading
Need help?

Need help?

Do you have a question about the Evolve PRO Touch and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Shot Navi Evolve PRO Touch

  • Page 1 Introduction Thank you for purchasing the Shot Navi Evolve PRO Touch. This product features the largest display available in a wristwatch-style GPS navigator, offering excellent visibility and equipped with a touchscreen. Its operability during play has been significantly improved, and the buttons are consolidated on one side, giving it a stylish design.
  • Page 2 Starting Golf Navigation Navigation Screen & Operation Methods Dynamic Green Eye Function Auto View Change Feature Competition Mode / Auto Golf Course Search / 2-Green Selection Hazard View / Simple View / Green View Putt Simulation / Pin Position Registration Hazard Icon List Auto Measure Function (Automatic Distance Measurement) ...
  • Page 3 reading these instructions, keep them handy for future reference. Do not redistribute this manual without permission. ■ Handle with Care: Do not drop the device or subject it to strong impact. Severe impacts may cause significant damage. ■ Operating Temperature: The operating temperature range of this product is 0°C to 50°C.
  • Page 4 Use the step count as a general reference for daily activity. Contents / Parts Names Evolve PRO Touch Main Unit Warranty Card and Quick Start Guide USB Charging and Data Cable (Type-C) 1.
  • Page 5 move the cursor down. 5. USB Port: Connects to the USB charging and data cable (Type-C). Charging ● Charging Insert the USB Type-C cable into the USB port. Connect the USB terminal of the charger to a PC or USB AC adapter to charge. Note: The AC adapter is sold separately.
  • Page 6 Power Off: Press and hold the power button for about 3 seconds in clock mode to  turn off the power. Reset: If the GPS is not working, the screen freezes, or the power does not turn on,  the device may be frozen. You can reset and reboot the device by pressing and holding both the middle and bottom buttons simultaneously for 10 seconds.
  • Page 7 Select "Device Settings" from the main menu. ● Time Settings: Alarm Settings: You can register up to three alarms. Time Adjustment: Manually set the date and time. (The time is automatically adjusted when GPS is acquired.) Automatic Time Adjustment: The date and time are automatically set when GPS is acquired.
  • Page 8 as height difference. Competition Mode Indicator: When in competition mode, "Competition M" will be displayed on certain navigation screens. Note: Whether the navigation can be used during actual play depends on the tournament's local rules, so please check with the event organizer or competition committee.
  • Page 9 〇 FW modes switching ◎ Location registration 〇 Navi Menu / Return ◎ Scorecard ① Shows remaining distance to green or hazard ② Hole number of current hole ③ Par number of current hole ④ Shows left and right greens when there are two greens L: Yellow R: Light blue ⑤...
  • Page 10 The Simple View displays large, easy-to-read distances to the center, front edge, and back edge of the green. ① Distance to the green: B: Back edge C: Center / P: Pin (when Pin position registration) F: Front edge ② Green Direction: Indicates the direction of the green from your current location. Green View The Green View displays the undulation, shape, width, and depth of the green.
  • Page 11 the Hazard View is displayed. Note: The default driver distance is set to 230 yards. ② Simple view: When the remaining distance is shorter than the driver distance, the Simple View is displayed ③ Layup Distance: When the remaining distance is shorter than the set layup distance, the Green View is displayed.
  • Page 12 ③ Third Shot: Displays the distance from the second shot location to the third shot location. Also, the third shot location is automatically registered. Note: If the interval between shots is too short, the automatic detection may not work. Note: Approach shots and putts with short distances are also not automatically detected.
  • Page 13 The Fairway Navigation (FW) function displays the distance from your current location to the center of the fairway in the direction you wish to hit, as well as the distance from that point to the green. While navigating Briefly press the middle button to switch to Fairway View. This function is useful in situations like dogleg holes or trouble shots where your ball is off the fairway.
  • Page 14 This function guides you to layup distances where you can comfortably reach the green with your next shot. From the navigation settings screen, tap the layup distance item to set your preferred layup distance. The layup distance circle and the intersection point with the fairway center will be displayed, guiding you to leave your preferred distance remaining for the next shot.
  • Page 15 ③ Current Distance Display Type (H: Horizontal Distance Display) ① Reference distance to Green (Yellow Text) ② Height Difference from Current Location to Green Center ③ Elevation Marker on Green (▲: Uphill, ▼: Downhill) ④ Current Distance Display Type (V: Reference distance Display) The reference distance will not be displayed if it exceeds the distance set in the "Driver Distance"...
  • Page 16 ② Driver Distance Circle: Displays a red circle representing your registered driver distance from your current location. Default: 230 yards ③ Layup Circle: Displays an orange circle indicating your preferred layup distance centered on the green. Default: 100 yards ④ Recommended Club Circle:By registering your own club distance, displays a red circle indicating the club you should use based on the remaining distance to the green.
  • Page 17 ① Golf Course Name ② Course Name ③ Hole Number ④ PAR of the Current Hole ⑤ Elapsed Play Time (per half round) ⑥ Steps Taken During Play Press the upper or middle button to check the layout of the hole you are playing and zoom in or out.
  • Page 18 Exit navigation and return to the clock screen. Navigation Settings Select the navigation menu or "Navigation Settings" from main menu. ● Score Support: When enabled, the score input screen will automatically appear after completing each hole. ● Hole Search: Automatically searches for the current hole based on your location. ●...
  • Page 19 Reset Right hand wearing Power OFF Reset Power ON About GPS Reception If "----" appears on the navigation screen, GPS reception is not possible. Move to an open area and receive GPS. If the navigation screen shows 999, the remaining distance is more than 1000 yards. Please make sure that the course and hole are selected correctly.
  • Page 20 Fairway Navigation, Height Difference Display, Green View, and Dynamic Green Eye may not be available for some international courses. The latest overseas golf courses supported by Shot Navi can be found here: https://shotnavi.jp/world Data can also be updated from the app.
  • Page 21 with the following specifications: Output: DC 5V, 500~1000mA. Note: Using a non-standard adapter may result in damage or malfunction. Note: When using the activity tracker, the battery will drain more quicklyeven in clock mode. Note: The battery life may vary depending on usage frequency and duration. Frequently Asked Questions (FAQ) ■...
  • Page 22 remove any accessories before sending the product for repair. 2. We will determine whether to repair or replace the product. For environmental protection reasons, refurbished parts may be used for repairs or replacements. 3. System software may be updated during the repair process. 4.
  • Page 23 E. Replacement of consumable parts (including the battery) and accessories is not covered by the warranty. F. Malfunctions caused by exposure to extreme heat (e.g., car dashboards, direct sunlight) or extreme cold. G. Malfunctions caused by water immersion or liquid entering the device. H.
  • Page 24 Shot Navi Official Website URL: https://shotnavi.jp For the latest information about Shot Navi products, please visit our official website. Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 25 radio communications. Operation of this product in a residential area is likely to cause harmful interference, in which case you will be required to correct the interference at your own expense. FCC Caution (15.19 statement) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
