- Page 1 USER MANUAL Coffee Grinder: Ethos...
- Page 2 User Manual User Manual Ethos...
-
Page 3: Table Of Contents
User Manual Content 1 Preface ......................- 4 - 2 Product Configuration ..................- 5 - 3 Product parameter ..................- 6 - 4. Placement & wiring ..................- 7 - 5. Installation & Setup ..................- 8 - 5.1 Machine installation ................... - 8 - 5.2 Control Panel .................. -
Page 4: Preface
User Manual 1 Preface Please read this manual carefully before using the appliance, because the manual contains important instructions for the safety, operation and maintenance of the appliance. Please keep this manual properly. The manufacturer reserves the right to make and change the product and manual. When opening the package, please check carefully to make sure that the appliance does not show any signs of damage. -
Page 5: Product Configuration
User Manual 2 Product Configuration Hopper Cover Bean Hopper Slide Baffle Hopper Base Control Panel Housing Powder Outlet Power Button (at the backside) Portafilter Holder Micro Sensor Built-in scale Supports Hopper cover 1 PC Bean Hopper 1PC Main body 1 PC Powder tray 1 PC Power Line 1PC User manual 1PC... -
Page 6: Product Parameter
User Manual 3 Product parameter Hopper Model Ethos 850-1000g capacity Voltage 220V-240V Frequency 50/60/70HZ Power 400-800W DC motor Rotate Speed 1800-2400 rpm Blades Titanium coating Size of blades 83mm flat burr Material Machine Size 200*300*355mm Meas. 29x38x70cm (W*D*H) G.W. 13.5 KGS N.W. -
Page 7: Placement & Wiring
User Manual 4. Placement & wiring The appliance must be installed by professional and technical personnel. Incorrect installation may cause personal injury or product damage, for which the manufacturer will not bear any responsibility. Clean the device carefully after installation, please follow the cleaning and maintenance instructions. -
Page 8: Installation & Setup
User Manual 5. Installation & Setup 5.1 Machine installation 5.2 Control Panel 5.2.1 Homepage(Time) Dynamic Time: tap to revise process display Temperature Date: tap to revise Single dose button and time Manual button Double dose Grinding Mode button and Click to swift time 4 modes. -
Page 9: Homepage(Weight)
User Manual 5.2.2 Homepage(Weight) Dynamic Time: tap to revise process display Temperature Date: tap to revise Single dose button and weight Calibration button: long press to enter Double dose into scale button and calibration weight Grinding time or weight: Tap to swift 5.2.3 Left Menu- User parameters Languages Temperature... -
Page 10: Right Menu- Device Parameters
User Manual 5.2.4 Right Menu- Device parameters ① Single Time: tap the number to revise single dose grinding time in seconds. ② Double Time: tap the number to revise double dose grinding time in seconds. ③ Temperature: protection temperature. ④ Single Cup: counter of single dose. Tap the number to clear. ⑤... -
Page 11: Setup Grinding Time
User Manual 5.3 Setup Grinding Time 2. Tap the number of "single time" or "double time" to enter into pop-up digital menu; 3. Enter new time such as "3.5", 4. Swipe the screen from left to and then press "Enter" to confirm right to return to the homepage. -
Page 12: Grinding Modes
User Manual 5.5 Grinding Modes Make sure the homepage is based on “Time(s)” not “Weight(g)”, tap the left corner to swift 4 grinding modes on homepage to activate different grinding methods. Standard Mode: Automatic Mode: 1. press single or double dose 1. -
Page 13: Weight Calibration
User Manual 5.6 Weight Calibration When the grinding by weight not in correct scale, you need to calibrate by a standard 20g balance weights. 1. Make sure the homepage is 2. Put an empty portafilter into based on Weight(g), if on Time(s), the holder. -
Page 14: Weight Compensation
User Manual 5.7 Weight Compensation When the grinding by weight over or lower the setting weight, you could correct the grinding weight back to setting data. E.g.: The grinding weight is set on 20g, the real grinding weight is 20.3g or 19.7g, to set the compensation data, the system will correct the grinding back to 20g. -
Page 15: Cleaning & Maintenance
User Manual 6. Cleaning & Maintenance - Before cleaning, please pull out the power plug to disconnect the electrical power. - Do not use water spray to clean the appliance. - Do not install electrical appliances in rooms where water sprays are used for cleaning. -
Page 16: Safety
User Manual 7. Safety Thermal overload protection -When the electric motor of the electric appliance prevents overheating and tripping caused by overcurrent through the thermal overload protection device, the power supply of the motor can be cut off. -If the protection device trips due to abnormal operation (such as a stuck grinding blade), you must use a switch to turn off the appliance, then disconnect the power supply of the appliance, and contact a professional technician. -
Page 17: Precautions
User Manual 8. Precautions The use of this appliance must comply with the relevant laws and regulations for safe operation. . When operating electrical appliances, pay attention to the movable mechanical parts of the grinding blade and the coffee powder outlet. Disconnect the power supply before removing the stocker from the grinding system. - Page 18 User Manual . Do not pull the power cord to pull out the power plug of the appliance. . Do not touch the appliance with wet hands or feet. . Do not go barefoot when using electrical appliances. . The user must regularly check the working condition of the power cord and plug. .
- Page 19 User Manual...
- Page 20 User Manual Marketed globally by: TRUFROST AND BUTLER PRIVATE LIMITED 1215, 12th Floor, Tower B, Emaar Digital Greens, Golf Course Extn. Road, Sector 61, Gurugram – 122011 (India) T. +91-7303166766 info@trufrost.com www.trufrost.com...
