Logitech MX Ergo Manual

Getting Started

1. Download Logitech Options to get the most Out Of your MX Ergo Multi Device Trackball experience, To download and learn mare about the possibilities, go logitech.com/options.
2. Turn on your MX Ergo trackball.
3. Press arid hold one Of the two Easy-Switch^TM buttons at the top Of the mouse below the scroll wheel for three seconds to ensure your device is in pairing mode,
4. TO connect MX Ergo trackball to your computer. Plug the provided unifying receiver into o USB port, use an existing Unifying receiver, or connect with Bluetooth.
5. Open Logitech Options, select MX Ergo Trackball and discover the MX Ergo trackball can do.

Product Overview

Adjustable metal hinge

With the unique adjustable hinge, you can increase the angle from 0 to a 20-degree tilt that improves the wrist posture and reduces The carefully sculpted shape gives your hand full palm and finger support. While the soft rubber on the top ensures good, comfortable grip for long hours of work. To switch between the two angles, simply press on the side Of the device to tilt it between 0º and 20º.

Features

1. Micro USB charging port

2. Adjustable angle
3. Back forward buttons
4. Precision mode button: Instantly change your cursor speed and accuracy for optimal control With the press Of a button. An LED light illuminates when precision is activated.
5. Precision scroll wheel With tilt: Use the precision scroll wheel with tilt and middle click for convenient controls and quick access to your favorite shortcuts.
6. Easy-Switch and connect button: Two-channel Easy-Switch capabilities let you switch between two computers without repairing.
7. Power LED

Rechargeable battery:
A fast rechargeable battery holds power for up to four months on a full charge. A quick one-minute charge gives you a full day of usage.

Flow-enabled:
Easily copy/paste text, images, and files between computers thanks to Logitech Flow technology.
