GIO USB
USER GUIDE
OVERVIEW
Gio USB is a surface-mount USB-to-Dante endpoint, enabling 2x2 channels of USB audio to be
transported over a standard Ethernet network. With a slim profile and PoE-powered, Gio USB is easily
and discreetly mounted under tables, within lecterns or behind a display.
Gio USB is often used for connecting room PCs, UC appliances or BYOM devices such as laptops to
room audio systems over a single category cable where having a digital signal processor for direct
connection in the same location is not feasible. Optimized for UC-conferencing, Gio USB features
volume and mute-sync with Microsoft Teams over HID, as well as volume sync for PC and Mac
computers.
WHAT'S IN THE BOX
Gio USB Unit
Mounting Screws with wall anchors
Setup Guide
MOUNTING
Please refer to the included Setup Guide for instructions on installing the unit.
PAGE 1 OF 7
GIO SERIES | USER GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GIO Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Xilica Audio Design GIO Series

  • Page 1 GIO SERIES | USER GUIDE GIO USB USER GUIDE OVERVIEW Gio USB is a surface-mount USB-to-Dante endpoint, enabling 2x2 channels of USB audio to be transported over a standard Ethernet network. With a slim profile and PoE-powered, Gio USB is easily and discreetly mounted under tables, within lecterns or behind a display.
  • Page 2 GIO SERIES | USER GUIDE CONFIGURING Gio USB settings are configured using Xilica Designer software, offered in Mac and PC versions and can be downloaded at: https://www.xilica.com/support/ Once Gio USB is installed on the network, open Xilica Designer to locate the discovered Gio USB in...

  • Page 3: General Settings

    GIO SERIES | USER GUIDE GENERAL SETTINGS Under the General Settings Tab, the Device Name shown in the Device Tile can be updated by selecting the Modify button next to the Device Name field. General settings also include details on Serial Number, MAC address, model and Firmware Version.

  • Page 4: Usb Configuration

    GIO SERIES | USER GUIDE USB CONFIGURATION The USB Name of Gio USB may be configured to allow clear identification when selecting a USB device from the host computer. A best practice is to set the USB name to the name of the room (i.e. 'Room 201') to simplify the experience for the room user in selecting the room audio system in their PC or UC application.

  • Page 5: Operation

    GIO SERIES | USER GUIDE OPERATION F1: 10/100 BaseT PoE Port - Used for networked audio and power. F2: USB-Type B - Host device connection for Room OC, UC Appliance or Laptop F3: Device Status Indicator: provides visual indication of the status of the device.
  • Page 6 GIO SERIES | USER GUIDE During operation, the following Gio USB parameters are available in Xilica Designer Project view when in Online Control mode, or buy selecting the Open Device Configuration button on the Network View device tile: 1. USB Device Name: displays the configured Gio USB Device Name that will show up on the host device when connected.

  • Page 7: Frequently Asked Questions

    GIO SERIES | USER GUIDE FREQUENTLY ASKED QUESTIONS 1. What is USB HID? 1. USB HID stands for USB Human Interface Device class and is a communication standard over USB for computer peripherals such as keyboards and mice. USB HID is also used by certain UC applications, PCs and Mac computers for synchronization of volume and mute status.
