Summary of Contents for Digi-Shot DC-7630
-
Page 2: Table Of Contents
Table of Contents Welcome..................1 Getting Started................. 2~5 -Contents of package..............2 -System Requirements..............3 -Camera Feature..............4 -LCD Screen Display Definition.............5 Powering Up................6 -Battery Installation -Turning Camera ON/OFF -Sleep Mode Taking Pictures.................7 LCD Monitor Indicator...............8 Setup Mode................9-11 -Shooting.......................9 -Self-Timer ....................9 -Flash......................9 -Exposure....................9 -Setup......................9 -Quick View....................10 -White Balance....................10... -
Page 3: Welcome
Welcome Thank you for choosing the Camera to pursue your digital adventures. Whether you are creating memories of your friends and family or exploring the great outdoors to get the utmost satisfaction from your digital camera, please take a moment to read through this manual. -
Page 4: Getting Started
Getting Started Contents of package Digital Camera Video Cable Neck Strap USB Cable Installation CD Carry Bag... -
Page 5: System Requirements
Getting Started System Requirements Personal computer, laptop, desktop, or IBM compatible with Pentium 166 MHz minimum, and with an active USB (universal serial bus) port. Windows 98SE/ ME/ 2000/ XP, CD ROM drive, color monitor, mouse and keyboard. NOTE For transferring still images or for video conferening, your computer must have a modem and communication software for internet connection. -
Page 6: Camera Feature
Getting Started Feature 2.Power 3.Flash Strobe 1.Shutter 4.View Finder 6.SD/MMC slot 5.Lens 7.Menu 8.Display 9. Up 10.Enter 11. Down 12.USB & TV port Menu OSD Menu ON/OFF Display LCD, Status Icons ON/OFF Up / Previous / Zoom in Enter Menu Enter/Playback Down Down / Next / Zoom out... -
Page 7: Lcd Screen Display Definition
Getting Started LCD Screen Display Definition... -
Page 8: Powering Up
Power Up Battery Installation Battery Installation 1. Open the battery chamber cover. 2. Insert batteries in correct polarity(+ and -)as shown on the inside of the battery chamber. 3. Close the battery chamber cover. 4. Power turns ON after pressing the power button. 5. -
Page 9: Taking Pictures
Taking Pictures Taking a Snapshot 1. Aim the camera and compose your image by looking through the viewfinder. 2. Press the shutter button down. A buzz sound will be heard indicating that a picture has been taken. 3. The LCD screen will show the number of pictures taken. NOTE The camera stores all pictures in the built-in memory , Secure Digital Memory Card or Multi Media Card. -
Page 10: Lcd Monitor Indicator
LCD Monitor Indicator Record Mode Flash State No.of Pictures Can be Taken Force Off Photography Force On Burst Automatic Card Indicator Self-Timer Digital Zoom State Bar Battery Indicator Full Battery Medium Battery Low Battery Battery Exhausted Digital Zoom In/Out 1.Press up/down button to change Zoom in/out. 2.Digital zoom state bar will display currant zoom status NOTE 1.The picture taken by doing Zoom In/Out will be blurred... -
Page 11: Setup Mode
SETUP MODE Shooting MODE (default : PHOTOGRAPHY) PHOTOGRAPHY Use this mode to take a single image each time the shutter button is pressed. Use this mode to record video clips at a resolution of 320x240 pixels. BURST Use this mode to take up to five images when the shutter button is pressed. PC CAMERA Use this mode to open the WebCam mode. -
Page 12: Quick View
SETUP MODE QUICK VIEW (default : ON) Display image on the LCD after taking a picture WHITE BALANCE(default : AUTOMATIC) Automatic White Balance The automatic white balance compensates for the color temperature of scene. When the built-in flash is used, the white balance is set for the color temperature of the flash. -
Page 13: Image Quality
SETUP MODE IMAGE QUALITY (default : HIGH) SUPER HIGH Less compression , High quality, Big file size. HIGH Normal compression, Normal quality, Normal file size. NORMAL High compression, Poor quality, Small file size. RESOLUTION(default : 2048x1536) 2976x2232 2560x1920 2048x1536 1280x1024 VIDEO FORMAT (default : NTSC) Set the video output format for displaying recorded pictures/video clips on a television. -
Page 14: Playback Mode
PLAYBACK MODE THUMBNAIL This function allows you to view nine images on the LCD monitor simultaneously so that you may search for a particular image. DELETE CURRENT To delete one image at a time. To delete all images at a time. REFORMAT The formatting function is used to erase all data on a memory card. -
Page 15: Install Arcsoft Programs And Camera Drivers
INSTALL CAMERA DRIVERS 1.Insert CD-Disc & Select"MEGA PIXEL DSC Driver" 2.Click "Next" 3.Click "Next" 4.Click "Install" 5.Click " Finsh". -
Page 16: Arcsoft Photo Impression 4.0
INSTALL ARCSOFT PROGRAMS Arcsoft Photo Impression 4.0 1.Turn computer ON. 2.Insert installation CD into your PC's CD-ROM drive. 3.Introduction screen will appear automatically. 4.Click "Arcsoft Photo Impression 4.0 " . 5.Follow on-screen instruction to install camera drivers. 6.Re-starting your computer is recommended. NOTE To find out more about PhotoImpression 4.0 or how to use it, consult online help by clicking"?"... -
Page 17: Arcsoft Photo Base 3.0
INSTALL ARCSOFT PROGRAMS Arcsoft Photo Base 3.0 1.Turn computer ON. 2.Insert installation CD into your PC's CD-ROM drive. 3.Introduction screen will appear automatically. 4.Click "Arcsoft PhotoBase 3.0 " . 5.Follow on-screen instruction to install camera drivers. 6.Re-starting your computer is recommended. NOTE To find out more about Photo Base 3.0 or how to use it, consult online help by clicking"?"... -
Page 18: Arcsoft Video Impression 1.6
INSTALL ARCSOFT PROGRAMS Arcsoft Video Impression 1.6 1.Turn computer ON. 2.Insert installation CD into your PC's CD-ROM drive. 3.Introduction screen will appear automatically. 4.Click "Arcsoft VideoImpression 1.6 " . 5.Follow on-screen instruction to install camera drivers. 6.Re-starting your computer is recommended. NOTE To find out more about Video Impression 1.6 or how to use it, consult online help by clicking"?"... -
Page 19: Quicktime Player 6
INSTALL PROGRAMS QuickTime Player 6 1.Turn computer ON. 2.Insert installation CD into your PC's CD-ROM drive. 3.Introduction screen will appear automatically. 4.Click "QuickTime Player " . 5.Follow on-screen instruction to install camera drivers. Finish 6.Re-starting your computer is recommended. NOTE To find out more about QuickTime Player 6 or how to use it, consult online help by clicking"?"... -
Page 20: Uninstall Application Programs
Uninstall Application Programs Uninstall Arcsoft Photo Impression 4.0 1.Search through Start > Programs > AcroSoft> Photo Impression 4.0 >Uninstall. 2.Follow on-screen instruction to uninstall software. Uninstall Arcsoft Photo Base 3.0 1.Search through Start > Programs > AcroSoft> Photo Base 3.0 >Uninstall. -
Page 21: Downloading Record Photo/Video Via "Removable Disk
DOWNLOAD PHOTOS Transferring Recorded/Video Clips to Your Computer Step 1: Installing the Driver (Please refer to page 13.) Step 2: Connecting the Camera to Your Computer (1)Connect the USB cable to an available USB port on your computer. (2)Turn the camera on. (3)Connect the other USB cable to the USB connector on the camera. -
Page 22: Downloading Photos Using Photoimpression 4.0
DOWNLOAD PHOTOS PhotoImpression 4.0 As a USB Mass Storage Device, with the camera connected, its memory will simply appear as a disk drive to the host computer. Any files can be copied to and from the camera's memory, just like any other file on any other disk drive. For Windows 98SE user, please go to Microsoft www.microsoft.com to update Windows for Mass Storage Function Support. -
Page 23: Photo And Sharing Management Using Photobase 3.0
DOWNLOAD PHOTOS PhotoBase 3.0 1. Click "PhotoBase 3.0" icon on desktop, 2. PhotoBase 3.0 introduction screen will appear. 3. Open Album menu bar. 4. Select "Create New"and enter file name. 5. Open Album menu bar and select " Add Image". 6. -
Page 24: Video Playback Using Videoimpression 1.6
VIDEO PLAYBACK VideoImpression 1.6 (Please change camera to PC Camera Mode)MENU \ Mode\ PC Camera 1. Click "Videoimpression 1.6" icon on desktop, 2. VideoImpression 1.6 introduction screen will appear. 3. Click "New" button. 4. Click"Capture". 5. Video will begin playing. -
Page 25: Playing Movie Clips Using Quicktime Player 6
VIDEO PLAYBACK QuickTime Player 6 (Turn on the camera and connect with USB cable ,the camera will set at " Mass Storage" Mode.) 1. Click "QuickTime Player" icon on desktop, 2. "QuickTime Player" introduction screen will appear. 3. Open "File" menu bar and Select "Open Movie in New Player". -
Page 26: Troubleshooting
APPENDIX Troubleshooting Symptom Cause Solution No memory space is available for Delete images stored on a MEMORY FULL taking any image card or insert a new card Unlock the memory card using SD CARD LOCKED Memory card is locked the write-protect swith NO PICTURES No files in the camera FILE ERROR... -
Page 27: Specifications
APPENDIX Specifications Image Sensor CMOS 2048x1536 pixels Lens Specification F2.8, Sensor area 1/2". F=8.45mm, view angle 53.2 Microsoft Windows 98SE/2000/ME/XP White Balance Auto/Manual(day light/cloudy/tungsten/fluorescent) Auto Exposure Control QVGA 320x240 pixels 25-30 fps Frame Rate-Video Mode 2976x2232 pixels 2560x1920pixels Resolution 2048x1536 pixels 1280x960 pixels PC Interface 1m~infinity...
