AUZA WP CVs Quick Start Manual

MODULE OVERVIEW
A set of LEDs which represent the modulatable parameters on Wave Packets.
The T, D and F parameters are laid out on a grid, corresponding to the
parameter positionings on WP. An additional glide (>>) parameter is available.
Each CV can be mapped to one or multiple parameters.
Each CV input channel includes a LED, attenuverter and jack with a ±�V range.
The LED illuminated shows the currently selected CV. Turning the
VIEW mode will flick through the current CV in view, and plugging in a cable
will switch the current CV in view to the channel the cable went in to.
If a CV input is mapped to an F parameter, the CV input will modulate the
frequency at �V per octave when the attenuverter is turned fully clockwise.
WP CVs is an expander module for Wave Packets that significantly enhances CV control. It provides � CV inputs, which can be assigned to various
WP CVs
parameters using the LED matrix. With a many-to-many mapping approach, each CV can control one or multiple parameters, and each parameter
can receive input from one or multiple CVs. This added CV power unlocks a wealth of new possibilities, such as, applying V/OCT control on individual
target frequencies, enveloping the glide, modulating specific sections of the contour function with an LFO, or externally controlling stage times.
LED MATRIX
4x CV INPUTS
ENCODER
T1 T2 T3 T4
T
D
F
- +
- +
in
- +
- +
WP CVs
ENCODER
In VIEW mode:
- Turning the encoder flicks through the CV
input will display on the LED MATRIX.
- Holding down the encoder while moving a knob or slider on Wave Packets
"quick" assigns or unassigns that parameter to the current CV.
- Tapping on the encoder will put the module in to MANUAL ASSIGN mode for the
current CV.
In MANUAL ASSIGN mode:
- Turning the encoder flicks through the parameters on the
- Pressing the encoder assigns or unassigns the current parameter to the CV.
- Holding the encoder for a few seconds will save the mappings and put the
module back in to VIEW mode.
INPUTS. The mappings for each CV
LED MATRIX.
