ASUSTeK COMPUTER GT302- Pc Case Manual

90DC00I0-B0000C

GT302 LEFT SIDE DOOR BLK/CSC | Left side door

Fully-assembled. (Consists of Left side glass*1, Left upper strip*1, Left lower strip*1, Left upper VHB double-sided tape 1*1, Left upper VHB double-sided tape 2*1, Left lower VHB double-sided tape*1, Left front EVA single-sided adhesive strip*1, Left rear EVA single-sided adhesive strip *1, Sticker*1)

90DC00I0-B0001C

GT302 RIGHT SIDE DOOR BLK/CSC | Right side door

Disassembly method: Pull outward and upward to remove them from the rear groove.
*Please handle with care when disassembling and assembling the glass side panel to avoid collision/drop/heavy pressure.

90DC00I0-B0005C

GT302 FRONT PANEL BLK/CSC | Front panel

Fully-assembled. (Consists of Metal plate*1, Upper decorative part*1, Lower decorative part*1, Solder pins[H6*6*M3]*4, Optical drive screws[PWM3*5*7]*4, Countersunk screws[KM6#*6 D=4.5]*4)

Disassembly method: Open it upwards from the bottom groove.

90DC00I0-B002EC

GT302 FRONT FILTER 140 BLK/CSC | Front filter

Disassembly method: Remove the front panel and pull out the front filter upwards.

90DC00I0-B0004C

GT302 FlO MODULE BLK/CSC | FIO module

Fully-assembled. (Consists of USB front cover*1, USB rear cover*1, Button*1, USB cable*1, Umbrella head screws[TA3*8]*3, Screw[PA3*10]*1, Foot pad screws[TM6#*6]*2)

FAQ: FIO buttons and ports not working

Disassembly method: Remove the front panel and loosen the screws on both sides of the FIO module.

90DC00I0-B000HC

GT302 TOP COVER BLK/CSC | Top cover

Fully-assembled. (Consists of Top cover plate*1, Anti-slip pad*1, Insulation sheets*4)

Disassembly method: Lift it up from the back side of the chassis.

90DC00I0-B000EC

GT302 TOP FILTER BLK/CSC | Top filter

Disassembly method: Remove the top cover and lift the top filter from the bottom of the top cover.

90DC00I0-B001HC

GT302 INNER TOP COVER BLK/CSC | Fan bracket

Disassembly method: Remove the top cover, loosen the two screws on the fan bracket, and lift it upwards.

90DC00I0-B001EC

GT302 BOTTOM FILTER BLK/CSC | Bottom filter

Disassembly method: Pull it out from the bottom of the chassis back side.

90DC00I0-B000JC

GT302 HIDE BLK/CSC | Cable cover

Disassembly method: Loosen the two screws on the right side of the chassis to remove the cable cover.

90DC00I0-B0002C

GT302 ARGB SYSTEM FAN BLK/CSC | Fan

Contents: Fan*1, Fan screws[KB5*10]*4

FAQ: Fan not spinning, Fan noise

Disassembly method: Unscrew the four corner screws to remove it.

90DC00I0-B000DC

GT302 CABLES BLK/CSC | Cables

Contents: PWM signal cable*1, ARGB signal cable*1

90DC00I0-B000LC

GT302 MSIC BLK/CSC | Cable clips

Contents: Iron cable clip*1, Hook-and-loop fastener *1, Plastic cable clip*1

Disassembly method: Loosen the screw on the cable clip.

90DC00I0-B000MC

GT302 FEET BLK/CSC | Feet

Fully-assembled. (Consists of Feet*4, Rubber feet*4, Feet screws[TM6#*6]*4)

Disassembly method: Tear off the rubber feet and loosen the screw in the round hole.

90DC00I0-B0007C

GT302 ACCESSORY BOX BLK/CSC |Accessory box

Contents: PSU screws[HWM6#6 cut thread & no thread at the end D=3.3]*4, Motherboard / 2.5" drive screws[PWM3*5*7]*25, 3.5" drive screws[BM6#*5 round thread]*8, Standoff tool[7.0*9.0]*1, Cable ties*8,

Side panel clips*3, Vertical graphics card mount*1

90DC00J0-B0008C

GT302 CARTON BLK/CSC | Carton

FAQ

1. Fan not spinning - Related components: Fan
   1. Dust and debris can accumulate on the fan blades over time, causing it to stop spinning. Check for any physical obstructions that may be blocking the fan's movement and remove them. Please connect the fan to different fan headers on the motherboard. If the fan still doesn't work, please replace the fan.
   2. Ensure that the cable is securely plugged into the motherboard.
2. Fan noise - Related components: Fan
   1. Over time, dust can accumulate on the fan blades, causing them to become unbalanced and produce noise. Turn off your computer and carefully clean the fan blades using compressed air or a soft brush to remove any dust or debris.
   2. Adjust the fan speed settings in the computer's BIOS or through software provided by the motherboard manufacturer. Lowering the fan speed can help reduce the noise level. However, be cautious not to set the fan speed too low, as it could lead to overheating.
3. FIO buttons and ports not working - Related components: FIO module
   1. Ensure that the cables connecting the FIO buttons and ports to the motherboard are properly connected. Sometimes, these cables can come loose or get disconnected, leading to functionality issues.
   2. Reconnecting the cables can resolve poor connections. Gently disconnect all the cables, wait for a while, and then plug them back into the corresponding headers on the motherboard.
   3. If reconnecting the cables does not solve the issue, please replace the FIO module.
