Meze Audio 99 NEO - Headphone Manual

PACKAGE CONTENTS

1. 99 NEOheadphone
2. EVAcarry case
3. Accessoriespouch
4. 1.5m OFC cable with mic&remote
5. 6.3mm jack adapter
6. Airplane adapter

MICROPHONE AND REMOTE CONTROL UNIT

1x:
2x:
3x:

Compatible with both Android and Apple devices + all deviceswith audiojack output.

When connected to a high-quality music player, notebook, tablet or smartphone, the 99 NEO will develop its full potential

The 99 NEO headphones are symmetrical

So Left and Right is determined by the L or R marked cable that you are using.

Also: the L (left) cable jack has a small tactile ridge to help you identify the left sideof cable / headphones without looking.

REPLACINC THE EARPADS

To remove the earpads, gently pull them away from the enclosure, until you seethe black rubber lip surrounding the PU leather earpad peel off the sideof the earcup. To fit the earpad back on, place the before mentioned rubebr lip of the earpad into the ridge between the wood earcup and the driver-plate. Start from one side, and slowly make your way all around, by carefully pulling the earpad outwards.

SELF-ADJUSTING HEAD BAND

The 99 NEO doesnt require manual adjustment for the sizeof the headband. The elastic mechanism inside the PU leather headband can stretch to fit any head size without any user input.

SPECIFICATIONS

Earcups: ABS Plastic Enclosure

TransducerType: Dynamic Neodymium / Mylar

Transducer Size: 40mm

FrequencyResponse: 15 Hz 25 Khz

Sensitivity: 103 dB Ikhz/lmw

Impedance: 26 Ohm R

ated Input Power: 30mw

Maximum Input Power: 50mw

Weight: 260g

SAFETY INSTRUCTIONS

• Keep the product, accessories and packaging parts out of reach of children and pets to prevent accidents and choking hazards.
• With wired headphones you should avoid sharp movements, which could cause the headphones to fall off your head. You could be seriously injured especially if you are wearing pierced earrings, spectacles etc.
• Do not use the product in situations which require special attention (e.g. in traffic or when performing skilled jobs).
• Always keep the product dry and do not expose it to extreme temperatures (hairdryer, heater, extended exposure to sunlight, etc.) to avoid corrosion or deformation.
• As with any equipment which will be used in close proximity to sensitive areasof the body, it is essential that the ear pad sand headban dare kept clean. Use a dry cloth for cleaning. Should it become necessary to replace the ear pads, refer to graphic on the other side.
• When connecting to your music source, make sure that the volume is turend down before plugging in the headphones. Due to their low impedance, the 99 NEO can be driven to high volumes by most devices with a 3.5mm audio jack. Do not set the volume too high, as you could pemanently damage your hearing.

You tend to crank up the volume to compensate for the noise around you. But our earpads offer a good passive isolation which should allow you to listen to your headphones comfortably even in louder environments such as inside an airplane or subway.
This way we hope to contribute to the preservation of your hearing.

FOR YOUR SAFETY: Maximum Recommended Sound Level / Day:

Please visit www.mezeaudio.com / www.mezeaudio.eu for more information
