Bayco LBC-600 Series, LBC-1600 Series, LBC-2600 Series - Light Changer Manual

LIGHT BULB CHANGER INSTRUCTIONS

Models LBC-600, LBC-1600, LBC-2600 series

ELECTRICAL SHOCK HAZARD: never use the light bulb changer around open wiring. Wear safety glasses when changing bulbs.

Use the correct attachment for the type of bulb to be changed.

Fits These Bulbs

INSTRUCTIONS FOR USE

1. Always turn off electrical power to the bulb you are changing. Allow time for bulb to cool.
2. Select the appropriate attachment and screw onto the threaded end of the extension pole. Hand-tighten the thumb-screw in the base of the attachment. DO NOT OVER-TIGHTEN THE THUMB SCREW.
3. Extend the pole and tighten each section as shown on the diagram on the pole. It is important to fully tighten each section so the pole doesn't loosen when being turned.

SPRING-CAGE ATTACHMENTS FOR FLOODLIGHT – STANDARD- CFL BULBS

• Follow steps 2 & 3 above.
• Slide the attachment onto floodlight bulbs by pushing it over the bulb from the side. For standard bulbs push directly on the bulb. Turn the pole counterclockwise to loosen and remove the bulb. Place new bulb in the attachment and insert into socket. Turn the pole clockwise to tighten. Pull the cage away from bulb.
• Bulbs which have been too tightly installed may require initial removal by hand. Using this light bulb changer after replacement will ensure easy removal in the future.

SUCTION-CUP ATTACHMENT FOR RECESSED FLOODLIGHTS

• Follow steps 2 & 3 above.
• Thread a long string through the eye on the base of the suction cup then tie the string to the ear on the suction cup. String should be several feet longer than the pole when fully extended. Gently, but firmly, push the cup onto the center of bulb to form suction. (NOTE: Suction can be increased with a slight application of moisture.) Turn pole counterclockwise to loosen bulb and carefully remove. Press new bulb into suction cup. Carefully lift and screw bulb into socket. Pull string to release suction.

BROKEN BULB REMOVAL – FITS REGULAR AND CANDELABRA BULBS

Turn off electricity at the source before removing bulb. Wear hand and eye protection when handling broken glass and bulbs.

• Attach extractor adaptor to extension pole, tighten thumbscrew; do not over tighten. Choose suitable size extractor (regular or candelabra) to fit base of broken bulb.
• Position the tip of extractor over the glass filament of broken bulb. Gently push upward and twist counter clockwise. Increase upward pressure if base binds.
• Unscrew the broken bulb from the socket


WARRANTY CLAIMS - USA
Return the product to the place where purchased with a dated proof of purchase. Or contact Bayco for USA warranty claims. Call 800-233-2155 and Bayco Customer Service will provide a Return Goods Authorization (RGA) to facilitate rapid warranty action. After receiving the RGA, send the product (shipping prepaid) to BAYCO PRODUCTS, INC • 640 S. SANDEN BLVD • WYLIE, TEXAS • 75098.

WARRANTY CLAIMS - CANADA
Return the product to the place where purchased with a dated proof of purchase and a brief description of the defect with your name, address and phone number.

Your product will either be replaced or purchase price refunded.

REQUEST FOR WARRANTY ACTION
If you have any questions about this warranty or any other Bayco product inquiries contact BAYCO PRODUCTS, INC • 640 S. SANDEN BLVD • WYLIE, TEXAS • 75098 or call 800-233-2155

Bayco Products, Inc. • 640 South Sanden Blvd. • Wylie, TX 75098 • 1-800-233-2155 • www.baycoproducts.com
