Introduction
What's in the box
SUPPORT
For the latest information on all of our products, please visit: www.dualav.com
- Call us toll-free at 1-866-382-5476
- E-mail us at cs@dualav.com
Getting Started
FIRST TIME USE
- The AMBTS34 Li-ion battery should be charged for minimum of 24 hours for the first time use
![FIRST TIME USE - Step 1]( "Dual - AMBTS34 - FIRST TIME USE - Step 1")
- Charging port is located on the bottom of the unit
![FIRST TIME USE - Step 2]( "Dual - AMBTS34 - FIRST TIME USE - Step 2")
- POWER ON/OFF - LONG PRESS 3 SECONDS
- VOL -
- VOL +
- PREVIOUS TRACK
- PLAY/PAUSE
- NEXT TRACK
- EQ - 4 PRESETS
- BLUETOOTH PAIR / STATUS
- TRUE WIRELESS PAIR / STATUS
- BATTERY LEVEL STATUS - (GREEN=FULL/RED=CHARGING)
- USB BATTERY BANK PORT (1A CHARGING ONLY)
Wireless Operation
Tips
To clear all previously paired BT Devices - LONG PRESS
for 10 seconds
- BLUETOOTH PAIRING
- Turn ON the unit - PRESS
![]()
2 seconds - LONG PRESS
![]()
3 seconds - Turn on your Devices Bluetooth in your SETTINGS MENU
- Look and tap on DUAL BT
- Once paired, a confirmation tone will be heard
- Streaming is now ready
2 seconds
3 seconds - AUTOMATIC TRUE WIRELESS PAIRING
- Turn ON each speaker within 15 seconds
- Once TWS is bonded, a confirmation tone will be heard
Manually reconnect TWS
- LONG PRESS
![]()
3 seconds each speaker
3 seconds each speaker Tips
You can only BT pair to one speaker while using TWS mode
Streaming Music
- VOL -
- VOL +
- PREVIOUS TRACK
- PLAY/PAUSE (WHILE RINGING - ANSWER INCOMING CALL)
- NEXT TRACK
- EQ - ROCK - POP - VOCAL - FLAT > ROCK...
Speaker Placement
| Speaker Placement | Your AMBTS34 speakers are fully portable, but can also be placed in many convenient locations in your home or patio area. |
| Wall Mounting | If hanging your speakers is desired, hang both speakers on a wall hook (not included) facing the listening area, this will provide the best audio results. Do NOT mount speakers on wall surfaces that can get wet, or that have hazards concealed behind them, such as electrical wires or plumbing. Always mount speaker on surfaces that are sturdy enough to support the speakers' weight, and make sure they cannot fall or cause injury. |
| Experiment for Better Sound | You should experiment with various placements. Room acoustics can produce large apparent differences in the sound when small changes in the placement are employed. For example, although the speaker may be located at any height above the floor, directing the tweeter toward ear level or angling the entire speaker toward the listening position often provides the most realistic imaging experience. The amount of bass perceived increases as you move a speaker closer to solid intersecting room surfaces (walls, ceiling, floor). |
TROUBLE SHOOTING
| TROUBLE | CAUSE | SOLUTION |
| Unit will not turn on | The battery is not charged | Charge 24 hours for best results |
| Plug charging adaptor into wall | Turn to on position | |
| No sound is heard | Speaker volume level is too low or muted | Turn the AMBTS34 volume level up |
| Device is paused or muted | Check your Devices playing / volume status | |
| The audio quality is poor | Device volume level is too low or muted | Raise the Device volume to a higher level |
| The audio quality is poor after connection with a Bluetooth enabled device | The Bluetooth reception is poor | Move the device closer to the audio system or remove any obstacle between the device |
SPECIFICATIONS
BLUETOOTH
- BT: 4.2
- BT Range: 33Ft / 10M (Class 2)
- BT Profiles: A2DP / AVRCP / GATT / HFP
GENERAL
- AC Adaptor Power Source: 120VAC / 15VDC-2A
- Li-ion Battery: 11.1VDC / 2600mA (18650 type)
- Amplifier Type: Class D
- Frequency Response: 45Hz-22kHz
- Storage Temperature: 5o F to 113o F / -15o C to 45o C
- Operation Temperature: 14o F to 104o F / -10o C to 40o C
- Weight: 4.5lbs / 2.10Kg
- Dimensions Inches WxHxD: 10.98 x 7.00 x 7.55
- Color: Black/Grey
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
Safety Information
IMPORTANT SAFETY INFORMATION TO THE USER
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of un-isolated, dangerous voltage within the inside of the device that may be of sufficient magnitude to constitute a risk of electric shock to persons
To reduce the risk of electric shock, do not remove cover or back plate as there are no userserviceable parts inside. Refer servicing to qualified personnel
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and servicing instructions in the literature accompanying the device
IMPORTANT SAFETY PRECAUTIONS
- The AMBTS34 has a weather resistant design, it should not be submerged in or underwater under any circumstances
- Set your volume control at a low setting, then slowly increase the sound until you can hear it comfortably without distortion, or ear discomfort.
Never leave this product in direct sunlight, overheating can cause permanent battery damage
- Wash with a mild soap or detergent and lukewarm water using a clean sponge or a soft cloth. Rinse well with clean water.
"Don'ts" - Very Important
- DON'T clean in hot sun or on very hot days.
- DON'T use abrasive or highly alkaline cleaners on the main body
- DON'T ever use acetone or carbon tetrachloride
ADJUSTMENT OR ALTERATIONS OF THIS DEVICE MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
SUPPORT
- Call us toll-free at 1-866-382-5476
- E-mail us at cs@dualav.com
