perixx PERIDUO-712 - Keyboards Manual

Product illustration

Caps Lock indicator
Low Voltage indicator (the LED indicator will start flash when the battery on Keyboard is under 1.0V output)
Battery Cover
(Keyboard: 1 pcs * AA battery)
(Mouse: 1 pcs* AA battery)
Nano Receiver

Product specification

Color	Black or White
Interface	Wireless 2.4G
Size	Keyboard: 291x138x20mm
Size	Mouse: 98x60x30mm
Weight	Keyboard: 301g
Weight	Mouse: 52g
Material	ABS
OS requirement	Windows XP and above

Power Saving Mode & Battery Consumption

Power Saving mode helps to consume minimum power (when kept on) by turning off signal connection when Keyboard and mouse are in Idle Mode and increases the battery life.

Keyboard

	Working Mode	Idel Mode	Standby Mode
Stop Working Time	-	3 Seconds	After 8 Minutes
Consumption	4 mA	0.2mA	17A

When the keyboard is in power saving mode, press any key on PERIDUO-712 to reconnect. 1 pcs of brand-new AA battery (2580mAh) provides up to 160 days of use when you type about two hours a day (6hours in Idle Mode and 16hours in Standby Mode).

Mouse

	Working Mode	Idel Mode	Sleeping Model	Standby Mode
Stop Working Time	-	1 Min	8 Minute	After 8 Minutes
Consumption	8.7mA	0.22mA	0.12mA	35A

When the mouse is in power saving mode, click on any mouse button to reconnect. 1 pcs of brand-new AA battery (2580mAh) provides up to 160 days of use when you use about two hours a day.

Introduction

PERIDUO-712 can create flexible, convenient and wireless working environment with its ergonomic design. PERIDUO-712 offers a reliable 2.4GHz high frequency penetration, low interference, and Omni-directional signal transmissions with 10 Meters meters receiving distance.

System Requirements

Operating System: Microsoft Windows ME/ 2000/XP/Vista/7/8/10

1 x Free USB Port

If the battery is running low, the low voltage indicator on the keyboard will start to flash. You should immediately replace them with the new batteries.
To avoid permanently damaging the keyboard, you must install the batteries with the positive and negative terminals being on the correct direction. Instructions can be found within the battery compartment.

Installation Process

The following steps initiate a connection process of the PERIDUO-712 to your PC.

Turn ON the pc
Insert Batteries

Plug the USB Receiver into a free USB Port
The device will be automatically detected by the PC,and it should be ready to work
If the device is still not working, please repeat the process from step 1.
