  • Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. FISHER PRICE W6203 Owner's Manual Shop genuine replacement parts for FISHER PRICE W6203 Find Your FISHER PRICE Ride On Parts - Select From 999 Models -------- Manual continues below --------...
  • Page 2 Product features may vary from the picture above. • Please read this manual and save it with your original sales receipt. • Required tools: Phillips Screwdriver (not included); Assembly Tool (included). • Use only with a Power Wheels ® 12 Volt Lead Acid Rechargeable Battery with Built-in Thermal Fuse and Power Wheels ®...
  • Page 3 • Use this vehicle ONLY outdoors. Most interior flooring 1-800-348-0755 para los Estados Unidos. Tenemos can be damaged by riding this vehicle indoors. representantes que hablan español para atender Fisher-Price will not be responsible for damage to ® su llamada.

  • Page 4: Electrical Hazard

    IMPORTANT INFORMATION ELECTRICAL HAZARD WARNING • Battery can fall out and injure a child if vehicle tips over. Always use battery retainer. • PREVENT FIRE - Never modify the electrical system. Alterations could cause a fi re resulting in serious injury and could also ruin the electrical system. - Use of the wrong type battery or charger could cause a fi re or explosion resulting in serious injury.
  • Page 5 PARTS • If you experience a problem with this product, or are missing a part, please call us at 1-800-348-0751, rather than return this product to the store. • Please identify all parts before assembly and save all packaging material until assembly is complete to ensure that no parts are discarded.
  • Page 6 PARTS Steering Column 2 Front Wheels (Left and Right) Steering Wheel 2 Wheel Covers Speaker Box 2 Wings Assembly (Left and Right) 2 Headlights 2 Headlight Covers 2 Door Plates Steering Column Cap (Left and Right) (Left and Right) 2 Taillights Steering Wheel Cap 2 Bushings 2 Hubcaps...
  • Page 7 PARTS 12 Volt Battery 2 Short Seat Belts 12 Volt Charger Long Seat Belt " (1,1 cm) " (1cm)-16 Washer – 2 Lock Nut – 2 " x 1 " Pin – 1 Assembly Tool #8 x " (1,9 cm) Screw – 34 "...

  • Page 8: Parts Picture

    PARTS PICTURE Note: Some parts shown are assembled on both sides of the vehicle. 00989pr-1068...

  • Page 9: Battery Charging

    BATTERY CHARGING • Make sure you charge the battery for at least 18 hours ELECTRICAL HAZARD using the enclosed Power Wheels 12 volt charger ® before operating your vehicle for the first time. WARNING Charge the battery for at least 14 hours after each use of the vehicle.
  • Page 10 ASSEMBLY WARNING Children can be harmed by small parts, sharp edges and sharp points in the vehicle's unassembled state, or by electrical items. Care should be taken in unpacking and assembly of the vehicle. Children should not handle parts, including the battery, or help in assembly of the vehicle.
  • Page 11 ASSEMBLY Front End " (1cm) -16 Lock Nut Vehicle • Fit the front end onto the vehicle. • Insert the tabs on the back edge of the front end into Assembly Tool the slots in the vehicle. • Place a "...
  • Page 12 ASSEMBLY Battery Compartment Bumper " (1,9 cm) screws into the bumper • Insert eight #8 x and tighten. TOP VIEW " (0,6 cm) x 1 " (3,2 cm) screws inside • Insert two of the battery compartment and into the front end of the vehicle.
  • Page 13 ASSEMBLY Headlights Plates • Fit the headlights (left and right) onto the bumper. Hint: Headlights only fit one way. If they do not seem to fit, try the other side. • Fit the large hole on the plates to the door posts. •...
  • Page 14 ASSEMBLY Motor Harness Windshield/ Connector Dash Front Radio FRONT VIEW Connector BACK VIEW • Fit the tabs on the windshield/dash into the slots in the front end of the vehicle. • Separate the radio connector wires from the motor harness connector. •...
  • Page 15 ASSEMBLY IMPORTANT! Turn the vehicle on its side or over to Large Opening complete assembly steps 23-28. Steering Wheel Steering Column Metal Steering Vehicle Bar Hole Column Hole DASH VIEW • Position the steering wheel so that the large opening is UP.
  • Page 16 ASSEMBLY Steering Wheel Cap Assembly Assembly • Insert and "snap" the key assembly into the slot in • Insert and "snap" the steering wheel cap into the center the dash. of the steering wheel. 1,5V x 4 Steering "C" (LR14) Column Cap Loosen This Screw Loosen This Screw...
  • Page 17 ASSEMBLY Battery Safety Information Hood In exceptional circumstances, batteries may leak fluids that can cause a chemical burn injury or ruin your product. To avoid battery leakage: • Do not mix old and new batteries or batteries of different types: alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium).
  • Page 18 ASSEMBLY Seat Taillights Slots • Fit the taillights (left and right) onto the rear of TOP VIEW the vehicle. • Insert the two tabs on the front edge of the seat into the slots in the vehicle. Wings Seat Taillight Tabs BACK VIEW •...
  • Page 19 ASSEMBLY Speaker Box Assembly • Fit the speaker box assembly onto the vehicle. " (1,9 cm) screws into each wing. • Insert two #8 x Tighten the screws. Speaker Connector Speaker Box Assembly " (1,9 cm) screws into the top of •...

  • Page 20: Battery Installation

    BATTERY INSTALLATION IMPORTANT! Use only a Power Wheels 12 volt, Power Wheels ® ® 12 Volt Battery rechargeable battery and built-in thermal fuse. Use of any other battery will damage your vehicle. Make sure that you charge the battery for at least 18 hours using the enclosed Power Wheels 12 volt charger ®...

  • Page 21: Battery Care

    BATTERY CARE VEHICLE CARE If a battery leak develops, avoid contact with the • Check all screws and their protective coverings leaking acid and place the damaged battery in a plastic regularly and tighten as required. Check plastic parts bag. See next section for proper disposal. on a regular basis for cracks or broken pieces.

  • Page 22: Safe Driving Rules

    SAFE DRIVING RULES Before children use this vehicle, an adult should RIDING HAZARD carefully evaluate the driving area as well as the child’s skill level and ability to drive the vehicle safely. Teach WARNING appropriate safety rules to your child before allowing operation of this vehicle.

  • Page 23: Vehicle Operation

    VEHICLE OPERATION • Help your child practice steering to learn how far and STOP how quickly to turn the steering wheel when driving, and automatically knows how to stop. Beginner Use - Low Speed • As assembled, your vehicle is ready to roll in low speed (2 mph, maximum).

  • Page 24: Limited Warranty

    FM RADIO USE LIMITED WARRANTY Bumper-to-Bumper* Limited Warranty *One year limited warranty from the date of purchase on the Power Wheels ® vehicle. Six month limited warranty on the 12 volt battery. Volume Scan Reset For the original purchaser, this one year limited warranty covers the Power Wheels ®...

  • Page 25: Problems And Solutions Guide

    PROBLEMS AND SOLUTIONS GUIDE IMPORTANT! If you experience a problem with your vehicle, first check the Problems and Solutions Guide below. If you still experience a problem, please contact Power Wheels ® Consumer Relations, toll-free at 1-800-348-0751. ® Or, contact your local Power Wheels authorized service center.
  • Page 26 PROBLEMS AND SOLUTIONS GUIDE PROBLEM POSSIBLE CAUSE SOLUTION Vehicle was running Loose wires or loose connectors Check all wires and connectors. Make sure the motor but suddenly stopped harness connector is tightly plugged into the battery, and that there are no loose wires around the motors. Tripped thermal fuse The built-in thermal fuse may "trip"...
  • Page 27 PROBLEMS AND SOLUTIONS GUIDE PROBLEM POSSIBLE CAUSE SOLUTION Vehicle runs in low High speed lock-out not disconnected The vehicle was pre-set to run only in low speed. To speed, but does not allow the vehicle to run in low and high speed, you run in high speed must disconnect the High Speed Lock-Out.
  • Page 28 PROBLEMS AND SOLUTIONS GUIDE PROBLEM POSSIBLE CAUSE SOLUTION Sometimes the vehicle Loose wire or connector Check all wires around the motors and all connectors to doesn’t run, but other make sure they are tight. times it does Motor or electrical switch damage Contact your local Power Wheels ®...
  • Page 29 General Motors Trademarks used under license to Fisher-Price. Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, New York 14052 U.S.A. ©2011 Mattel, Inc. All Rights Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc. unless otherwise indicated.
