138cm (4.5ft) Trampoline
READ PRIOR TO ASSEMBLING AND USING THE TRAMPOLINE
WARNING: To ensure everyone's safety, please do not attempt to assemble this
trampoline without reading this instruction manual carefully. Failure to comply with this
warning may result in injury and/or property damage.
• Prior to assembly, this trampoline includes small parts/accessories that are not suitable
for children under 3 years of age as they may cause a choking hazard.
• This trampoline should be assembled by 2 adults.
• Only use this trampoline on a soft, flat level surface.
• This trampoline has a maximum user weight of 34kg.
• This trampoline is suitable for users aged 3 to 6 years of age.
• Do not allow more than 1 person on the trampoline at any time.
• This trampoline is designed for domestic use only, it is not intended for gymnastics or
high level acrobatic stunts.
For parts and service enquiries, please contact Action Spares on 1800 465 070 or e-mail
service@actionspares.com.au
ATTENTION!
SAFETY INFORMATION, INSTALLATION, CARE
AND MAINTENANCE INSTRUCTIONS.
S002393
Advertisement
Table of Contents
Related Manuals for Action Sports S002393
Summary of Contents for Action Sports S002393
- Page 1 138cm (4.5ft) Trampoline S002393 ATTENTION! SAFETY INFORMATION, INSTALLATION, CARE AND MAINTENANCE INSTRUCTIONS. READ PRIOR TO ASSEMBLING AND USING THE TRAMPOLINE WARNING: To ensure everyone’s safety, please do not attempt to assemble this trampoline without reading this instruction manual carefully. Failure to comply with this warning may result in injury and/or property damage.
-
Page 2: Table Of Contents
Contents Warnings Installation Instructions Care and Maintenance Instructions Safety Information Parts List Assembly Instructions Warranty Information S002393 Action 138cm (4.5ft) Trampoline... -
Page 3: Warnings
16. Users should be barefooted or only wearing socks when using the trampoline, footwear must not be worn. 17. Do not use foreign objects with the trampoline, use of any foreign objects will void the warranty. S002393 Action 138cm (4.5ft) Trampoline... - Page 4 25. Do not bounce on the trampoline immediately after a meal. 26. Jewellery should be removed before using the trampoline as this may cause an injury to the user and/or damage the trampoline. 27. Users should only use the trampoline under adult supervision. S002393 Action 138cm (4.5ft) Trampoline...
-
Page 5: Installation Instructions
Keep the area surrounding the trampoline clear. Place the trampoline away from walls, structures, fences and other play areas. Place the trampoline in a well-lit area. Tr ampoline Tr ampoline 1. 5 m width 1. 5 m S002393 Action 138cm (4.5ft) Trampoline... -
Page 6: Care And Maintenance Instructions
Damaged or degraded padding Deterioration in the stitching or fabric of the barrier Sagging of the barrier Bent or broken barrier supports Sharp protrusions on the barrier support structure Broken or damaged enclosure entry system S002393 Action 138cm (4.5ft) Trampoline... -
Page 7: Safety Information
Over-confidence can lead to injury. • Learn fundamental bounces first before trying more complex manoeuvres. • Inappropriate clothing can cause injury. • Clothing should allow plenty of body movement without flapping loosely and becoming a distraction to the jumper. S002393 Action 138cm (4.5ft) Trampoline... - Page 8 It is dangerous practice to jump or bounce from the trampoline when dismounting. Never use springs or suspension elements as ‘hand grips’ when getting on and off the trampoline. S002393 Action 138cm (4.5ft) Trampoline...
- Page 9 Learn this skill before you attempt any others. • Avoid bouncing too high. Stay low until you can control your bounce and repeatedly land in the centre of the trampoline. • Do not bounce immediately after a meal. S002393 Action 138cm (4.5ft) Trampoline...
-
Page 10: Parts List
Parts List Part No. Description Top Rail T-Joint Leg Tube Frame Pad Skirting Upper Enclosure Pole Lower Enclosure Pole Elastic Toggle Loop Screw (Ø4*16mm) Screwdriver NOTE: Some parts may be supplied pre-assembled. S002393 Action 138cm (4.5ft) Trampoline... -
Page 11: Assembly Instructions
To complete assembly of the Legs. Join the Leg Tube (C) to the Top Rail and leave the hole without screw at this stage. The screw will be used in later step when the skirting is connected as well. Once completed, the frame of the Trampoline should look like Figure 4. S002393 Action 138cm (4.5ft) Trampoline... - Page 12 Thread the Elastic Toggle (J) through the Mat (D) one by one, when it is finished, it should look like Figures 6 & 7. Secure the Elastic Toggle (H) to the Top Rails as shown in Figures 8 – 12 S002393 Action 138cm (4.5ft) Trampoline...
- Page 13 Attach the skirting (G) to the bottom of the trampoline and secure with Screw (K). See Figures 17 & 18. When the screws have been properly screwed in the trampoline should look like Figure 19. S002393 Action 138cm (4.5ft) Trampoline...
- Page 14 Fig 21 Fig 22 Raise the net and attach the Net to the top of each Enclosure Pole, align the hole and fasten with the Screw (K). See Figures 23 & 24. Fig 24 Fig 23 S002393 Action 138cm (4.5ft) Trampoline...
- Page 15 There is a plastic warning placard enclosed with the enclosure package. Permanently affix this warning placard to an enclosure pole next to the entrance of the trampoline so that it is clearly visible. Fig 25 Fig 26 S002393 Action 138cm (4.5ft) Trampoline...
-
Page 16: Warranty Information
Photos of the product, and scans of receipts, may be requested to assist with your claim. S002393 Action 138cm (4.5ft) Trampoline... - Page 17 9:00am – 4:30pm Monday to Friday (excluding Public Holidays) 9:00am – 3:00pm Saturday This product is warranted and distributed by: Action Sports of 48B Egerton St, Silverwater NSW, 2128 Phone: (02) 8799 3500 © 2020 Action Sports Equipment Pty Ltd.
