VADI VH30200L Manual

Power Adaptor
VH30200L
Device description
V 30200L Power Adaptor is used to transfer power to heated wire H
in breathing circuit in order to heat the air stream from ventilator to
the airway of patients.
Specification
Length: 0.5m from Connector to the plug of inspiratory limb.
0.9m from Connector to the plug of expiratory limb.
Connector: 4 pins for 80 ° Power adaptor socket.
Plug of Inspiratory Limb: 2 slots
Plug of Expiratory Limb: 2 slots
Use Instruction
Please follow the following ways to install and use Power Adaptor:
1. Plug the onnector into the power adaptor socket on right side of C
VH-3000 Respiratory Humidifier
2. Plug the plug (2 slots) of Inspiratory Limb into power inlet of
heated wire for inspiratory limb.
3. Plug the plug (2 slots) of expiratory Limb into power inlet of
heated wire for expiratory limb.
4. Activate the humidifier and check Power Adaptor is working
appropriately.
2460
.
Storage Temperature: 25~40℃, Humidity RH:15%~95%
without condensation
Transport Temperature: -10~60℃, Humidity RH:15%~95% without
condensation, Pressure: 595 to 1013 hPa
Clean
Please use the damp cloth with clean water
clean it.
Cautions
1 NO MODIFICATION of this device is allowed. .
2. Serious incident in relation to this product must be reported to
VADI, distributor and applicable competent authorities.
Warnings
1. The product is intended for use by qualified medical staff.
2. Please follow waste disposal guideline locally.
VADI Medical Technology Co., Ltd. Yangmei
No. 198, Lane 298, Huandong Road, Zhongshan Village, Yangmei
District, Taoyuan City 32665, Taiwan
TEL: +886- 3-475-9911 E-mail: sales
FAX: +886- 3-475-9922 Website: www.vadimedical.com.tw
MedNet EC-REP IIb GmbH
Borkstrasse 10, 48163 Münster, Germany
MedNet SWISS GmbH
H
Bäderstrasse 18, 5400 Baden, Switzerland
2021.12.23
or
75% ethyl alcohol to
@vadimedical.com.tw
Made In Taiwan
VA-1-VH30200L-EN.MDR_01
