Summary of Contents for Euphoria XPERT EXW10CF
- Page 1 EXW10CF EXW12CF Carbon Fiber Ferrite Woofer USER MAN UA L...
-
Page 2: Product Features
Congratulations on your purchase of a Euphoria™ state-of-the-art subwoofer. Your selection of a Euphoria™ Car Audio product indicates a true appreciation of fine musical reproduction. Whether adding to an existing system or including your Euphoria™ Subwoofer in a new system, you are certain to notice immediate performance benefits. -
Page 3: Product Dimensions
RECOMMENDED ENCLOSURE PRODUCT DIMENSIONS Frame Diameter EXW10CF EXW12CF ENCLOSURES Sealed Mounting Depth Woofer Cutout Cutout Diameter Mounting Depth Sealed Box MODEL FRAME DIAMETER MOUNTING DEPTH CUTOUT DIAMETER Vented Box EXW10CF 10.90 in/ 277 mm 6.10 in/ 155 mm 9.37 in/ 238.11 mm Vent Area EXW12CF 12.52 in/ 318 mm... - Page 4 C WIRING CONFIGURATIONS NOTES You can change the wiring configuration of your speakers (Series, Parallel and Series / Parallel) to match the impedance loads that maximizes the power output of you amplifier. Wiring the same woofer or multiple woofers in these three different wiring configurations will result in different impedance loads.
-
Page 5: Limited Warranty
LIMITED WARRANTY DB Drive Euphoria warrants any products purchased in the U.S.A. from an authorized DB Drive Euphoria dealer. All products are warranted to be free from defects in material and workmanship under normal use and service for a period of (2) years.
