Please read installation manual carefully before beginning installation!
RAC GmbH & Co. KG - P.O. Box 12 25 - 74899 Bad Rappenau - Germany
Installation Manual for
Telephone +49-7066 / 9006 0 - Telefax +49-7066 / 9006 50
http://www.rainbow-audio.de
2-Way Component System
2-Way Component System
2-Way Component System
2-Way Component System
3-Way Component System
3-Way Component System
150 Watt
Part-No. 231496
180 Watt
Part-No. 231497
180 Watt
Part-No. 231111
180 Watt
Part-No. 231489
180 Watt
Part-No. 231498
180 Watt
Part-No. 231490
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Rainbow CS 230 Profi
-
Page 1: Figure
Installation Manual for Profi Line Component System CS 230 Profi 2-Way Component System 150 Watt Part-No. 231496 CS 265 Profi 2-Way Component System 180 Watt Part-No. 231497 CS 265 Profi Phase Plug 2-Way Component System 180 Watt Part-No. 231111 CS 265 Profi Kick... -
Page 2: Table Of Contents
Figure 7 Dear valued customer, We congratulate you on your purchase of our superior product and thank you for placing your trust in Rainbow®. We have put together this installation manual with great consideration of different mechanical and acoustical auto features. -
Page 3: Important Operational Information
Attention: Important Operational Information. Please Read Before Installation. • The loudspeaker may be operated only with the system-synchronized crossover and under observance of the specified rated output power. • Interchanging the woofer and tweeter connections will lead to immediate destruction of the tweeter. •... -
Page 4: Contents And Detail Of Parts (Cs 2Xx)
Contents and Detail of Parts CS 230 / CS 265 Fastening for Woofer: grill 130 / 165 mm ∅ metal, black with rainbow logo 2 pieces woofer 130 / 165 mm ∅ (screw terminal) 2 pieces installation ring 130 / 165 mm ∅... -
Page 5: Technical Data (Cs 2Xx)
Technical Data System CS 230 Profi CS 265 Profi Peak power handling 150 W 180 W Power rating 100 W 120 W Sensitivity 90 dB 1W/1m 90 dB 1W/1m Frequency response 48 - 25.000 Hz 39 - 25.000 Hz 4 Ω... -
Page 6: Contents And Detail Of Parts (Cs 3Xx)
Contents and Detail of Parts CS 365 Fastening for Midrange and Woofer: grill 165 mm ∅ metal, black with rainbow logo 2 pieces woofer 165 mm ∅ (screw terminal) 2 pieces installation ring 165 mm ∅ 2 pieces grill 100 mm ∅ metall, black with rainbow logo 2 pieces midrange 100 mm ∅... -
Page 7: Technical Data (Cs 3Xx)
Technical Data System CS 365 Profi CS 365 Profi Kick Peak power handling 180 W 180 W Power rating 120 W 120 W Sensitivity 90 dB 1W/1m 90 dB 1W/1m Frequency response 39 - 25.000 Hz 80 - 25.000 Hz 4 Ω... -
Page 8: Profi Line Capabilities
Positioning the Loudspeaker Rainbow loudspeakers may be installed in your vehicle in a variety of places. In determining the installation location the following information should be considered: Woofers require a large area for optimum sound reproduction. Car doors with a large air cushion between the door lining and external metal or the rear windshield deck of an auto with a large trunk are ideal locations. - Page 9 Important: Rear and front windshields strongly reflect the tweeter signal and can make the sound seem shrill and overpowering. Windshields can, for the purpose of support, be used if desired, however, normally installation in the windshield proximity should be avoided. Upholstery absorbs high frequency sounds, making sound reproduction seem flat and dull.
- Page 10 Rear Windshield Deck: The woofer should be arranged in direct proximity to the windshield. This installation position prevents interior-specific difficulties in high-range sound reproduction. The tweeter and midrange should be positioned as near as possible to the woofer. Additionally, attention should be paid that the tweeter is the appropriate distance from the rear window and head rests.
-
Page 11: Installing And Attaching The Woofer
Installing and Attaching the Woofer CS 230 / CS 265 / CS 365 Note: Do not attach via or puncture the membrane. Do not damage the membrane with a screwdriver or other sharp tool. • After selecting the installation location, attach the installation ring (C) at the designated location, e.g. with double-sided tape, and mark the necessary drill holes and the space for the woofer (inner circle of the installation ring). -
Page 12: Installing And Attaching The Midrange
Installing and Attaching the Midrange CS 365 In selecting the installation location, the position of the midrange in relation to the tweeter should be considered. The loudspeakers should be placed as closely as possible to one another to achieve a complete sound effect. Note: Do not attach via or puncture the membrane. -
Page 13: Installing And Attaching The Tweeter
Installing and Attaching the Tweeter CS 230 / CS 265 / CS 365 Installation Location: Door Installation (front/rear), rear installation, side view mirror area installation, instrument panel installation, and rear windshield deck installation • Fix the installation template of the tweeters at the selected location with tape and, along the indicated line, carefully cut and smooth edges. -
Page 14: Cable Preparation
Cable Preparation Shorten tweeter cable (at least 1 mm²) to the appropriate length and strip both ends. Insert the red conduit cover (+) over the appropriately marked conductor and the black cover (-) over the remaining conductor. Solder one end of the stripped conductor with the u-shaped metal jacket. -
Page 15: Connecting The Crossover (Cs 2Xx)
Connecting the Crossover CS 230 / CS 265 The crossovers (X) and the loudspeakers (B) are provided with screw connections and different plug connections as well as with polarity markings. Through this control system are the appropriate steps in connecting the loudspeakers with the crossovers ensured. - Page 16 Figure 5: Diagram of Connections and Cable Preparation of 2-Way Systems.
-
Page 17: Connecting The Crossover (Cs 3Xx)
Connecting the Crossover CS 365 The crossovers for the high/low range (X) as well as the middle range (Y) and the loudspeaker (B+E) are provided with screw connections and different plug connections as well as with polarity markings. Through this control system the appropriate steps in connecting the loudspeakers with the crossovers are ensured. - Page 18 Position „+0dB / B“ (3), Gradient Frequency Response from 4 to 8 dB: For this, attach the positive terminal (+) of the midranges to the screw connection „+0dB“ (3) of the crossover. Additionally, carefully remove the crossover cover and place the wire jumper on pin „B“.
- Page 19 Figure 6: Diagram of Connection of the 3-Way System and Cable Preparation.
-
Page 20: Philosophy Of The Crossover
This document is protected by copyright. All duplications, and/or reproductions, in full or part, as well as all renditions of the illustrations, with or without alterations, are permitted only with written agreement from RAC GmbH & Co. KG. Copyright © 2004 by RAC GmbH & Co. KG. Rainbow® is a registered trademark.
