- Page 1 RT10 Series Accessories User Guide...
- Page 2 Disclaimer Honeywell International Inc. (“HII”) reserves the right to make changes in specifications and other information contained in this document without prior notice, and the reader should in all cases consult HII to determine whether any such changes have been made. HII makes no representation or warranties regarding the information provided in this publication.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Customer Support ..........................v Technical Assistance .......................v Product Service and Repair ....................v Limited Warranty ........................v Chapter 1 - Introduction .................. 1 Chapter 2 - RT10 2-Bay Battery Charger ............ 3 Out of the Box ..........................3 Connect Power ..........................4 Charge the Battery Pack...................... - Page 4 Back ............................13 Bottom ............................13 Connect Power..........................14 Power Adapter ..........................15 Direct Connection .........................15 Insert Tablet into the Dock .......................16 Remove Tablet from the Dock....................18 Chapter 5 - Mounting Solutions..............21 VESA Mount ...........................22 Out of the Box .........................22 Features ............................22 Installing the VESA Plate ....................23 RAM Mounting Kit ........................23 Out of the Box .........................23 Installing the RAM Kit......................24...
-
Page 5: Customer Support
Technical Support portal. For our latest contact information, see honeywell.com/PSSlocations. Product Service and Repair Honeywell International Inc. provides service for all of its products through service and select Support to find centers throughout the world. Go to sps.honeywell.com... - Page 6 RT10 Accessories User Guide...
-
Page 7: Chapter 1 - Introduction
CHAPTER INTRODUCTION Honeywell offers a full range of accessories for the RT10 Rugged Tablet, including a multi-bay charger, desk docks for office use, vehicles docks, and mounting kits for a variety of workflows. The accessories included in this guide are compatible with both RT10A and RT10W rugged tablets. - Page 8 RT10 Accessories User Guide...
-
Page 9: Chapter 2 - Rt10 2-Bay Battery Charger
Be sure to keep the original packaging in case you need to return the battery charger for service. Caution: We recommend the use of Honeywell accessories and power adapters. Use of any non-Honeywell accessories or power adapters may cause damage not covered by the warranty. -
Page 10: Connect Power
Connect Power Use only a UL Listed power supply which has been qualified by Honeywell with an output rated at 19 VDC and 3.42 A. The power supply input rating is 100~240 VAC, 50/60Hz. The operating temperature is -20°C to 60° C (-4°F to 140°F). -
Page 11: About The Status Leds
• Insert one to two battery packs into the charger. About the Status LEDs Each charging bay has dedicated Battery LEDs located at the front of the bay that indicate charging progress. When all three LEDs for a bay are lit, the battery is fully charged. - Page 12 RT10 Accessories User Guide...
-
Page 13: Chapter 3 - Rt10 Desktop Docks
CHAPTER RT10 DESKTOP DOCKS Honeywell offers two docks that allow you to use your RT10 tablet like a desktop computer by connecting it to an external monitor and keyboard (sold separately): • RT10-CD Communications Dock • RT10-DD Desk Dock Feature... -
Page 14: Features
Mise en garde: Il est recommandé d'utiliser les périphériques, les cordons d’alimentation et les adaptateurs secteur conçus par Honeywell. L’utilisation de tout périphérique, cordon d’alimentation ou adaptateur secteur d'une autre marque est susceptible de provoquer des dommages non couverts par la garantie. -
Page 15: Connect Power
Connect Power Use only a UL Listed power supply which has been qualified by Honeywell with an output rated at 19 VDC and 3.42A. The operating temperature is -20°C to 60°C (-4°F to 140°F). 1. Plug a power cord into the power supply. - Page 16 RT10 Accessories User Guide...
-
Page 17: Chapter 4 - Rt10 Vehicle Docks
CHAPTER RT10 VEHICLE DOCKS Honeywell offers four vehicle docks to securely fasten RT10 Rugged Tablets in moving vehicles: • Power-only RT10-VC Vehicle Cradle • RT10-VD Vehicle Dock with multiple I/O ports • RT10-EVC Enhanced Vehicle Cradle with USB • RT10-EVD Enhanced Vehicle Dock with multiple I/O ports... -
Page 18: Features
Be sure to keep the original packaging in case you need to return the dock for service. Caution: We recommend the use of Honeywell accessories and power adapters. Use of any non-Honeywell accessories or power adapters may cause damage not covered by the warranty. -
Page 19: Back
Back Latch VESA 75x75mm VESA 75x75mm mounting holes mounting holes Bottom RT10-VC DC In (Terminal Block) RT10-VD Ethernet RS232 DC In SMA connector (Female) for (Terminal external GPS antenna Block) USB 2.0 RT10 Accessories User Guide... -
Page 20: Connect Power
RT10-EVC Honeywell 6-pin DC connector RT10-EVD Ethernet RS232 Honeywell 6-pin DC connector D9 USB 2.0 Connect Power Vehicle power input for the RT10-VC and RT10-VD is 9V to 36V DC. For the RT10-EVC and RT10-EVD, power input is 10V to 60V. The operating temperature is -20°C to 60°... -
Page 21: Power Adapter
Power Adapter Caution: Do not install the tablet in the dock before connecting power. Ensure the ignition or power supply is off before connecting the power cable. Caution: Ensure power input is correct: Model Power Input RT10-VC, RT10-VD 9~36V DC-in RT10-EVC, RT10-EVD 10~60V DC-in RT10-VC and RT10-VD... -
Page 22: Insert Tablet Into The Dock
Insert Tablet into the Dock 1. Insert the tablet into the dock. Ensure the tablet is fully seated in the dock. Note: The slot on the back of the tablet (A) must align with the tab on the front of the dock (B). - Page 23 2. Grip the back of the dock with your fingers and push the top clip down with force until you hear the latch click. Caution: If you do not use enough downward pressure, the tablet could dislodge. 3. Pull on the clip to ensure it has fully engaged. RT10 Accessories User Guide...
-
Page 24: Remove Tablet From The Dock
4. Insert the key into the dock, turn it all the way, then attempt to remove it. The key can only be removed if the clip is fully engaged. Remove Tablet from the Dock 1. Pull the standard latch on the rear of the dock to release the clip. RT10 Accessories User Guide... - Page 25 If the RT10-DOCK-RELEASE is installed , push the latch to release (see page 24) the clip. 2. Lift the tablet out of the dock. RT10 Accessories User Guide...
- Page 26 RT10 Accessories User Guide...
-
Page 27: Chapter 5 - Mounting Solutions
CHAPTER MOUNTING SOLUTIONS Honeywell offers multiple mounting solutions for the RT10 Rugged Tablet: • A VESA® adapter plate that installs directly onto the tablet (RT10-MNT-VS) • A RAM® kit to mount a vehicle dock (RT10-MNT-RAM) • A push-release latch for mounted vehicle docks (RT10-DOCK-RELEASE) -
Page 28: Vesa Mount
VESA Mount The RT10-MNT-VS is a VESA adapter plate that is installed directly onto the tablet. Use the VESA plate to secure the tablet to a stand or wall mount. Out of the Box Make sure that your shipping box contains these items: •... -
Page 29: Installing The Vesa Plate
Installing the VESA Plate RAM Mounting Kit Honeywell offers a RAM mount adapter kit for RT10 vehicle docks that provides a ball plate that can be used with RAM mount systems. The RT10-MNT-RAM kit allows you to mount a vehicle dock while retaining the flexibility to remove the tablet from the dock. -
Page 30: Installing The Ram Kit
Installing the RAM Kit To secure a vehicle dock to a RAM mount system (sold separately): 1. Attach the RT10-MNT-RAM kit to the vehicle dock. Bolt (4) Lock Washer (4) Washer (4) Plastic Spacer (4) RT10-MNT-RAM Mounting Kit Vehicle Dock (RT10-VC, RT10-VD, RT10-EVC, or RT10-EVD) 2. -
Page 31: Install The Push-Release Latch
Install the Push-Release Latch 1. Remove the two screws from the upper right of the back of the dock. 2. Attach the latch support using the M3 x 12 screws. M3 x 12 round head screw M3 x 12 flat head screw 3. - Page 32 4. Align the slot on the push release latch with the latch support, then attach the push release latch using the M2.5 x 5 round head screws. M2.5 x 5 round head screws RT10 Accessories User Guide...
- Page 34 Honeywell 855 S. Mint Street Charlotte, NC 28202 sps.honeywell.com ™ RT10-ACC-EN-UG-01 Rev G 2/23...
