ARM Electronics SDKBD2
Speed Dome Camera Controller
A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
• C r i t i c a l a n d e x p e d i t e d s e r v i c e s
• I n s t o c k / R e a d y - t o - s h i p
Artisan Scientific Corporation dba Artisan Technology Group is not an affiliate, representative, or authorized distributor for any manufacturer listed herein.
In Stock
Used and in Excellent Condition
Open Web Page
https://www.artisantg.com/90997-1
• We b u y y o u r e x c e s s , u n d e r u t i l i z e d , a n d i d l e e q u i p me n t
• F u l l - s e r v i c e , i n d e p e n d e n t r e p a i r c e n t e r
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Arm Electronics SDKBD2
Summary of Contents for Arm Electronics SDKBD2
- Page 1 ARM Electronics SDKBD2 Speed Dome Camera Controller In Stock Used and in Excellent Condition Open Web Page https://www.artisantg.com/90997-1 A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
- Page 2 Speed Dome Camera Controller Operation Manual VER: 1.1 Please read this operation manual before using this device and use the device properly. Also, please keep this manual with care to ensure easy access at any time.
-
Page 3: Safety Precautions
SAFETY PRECAUTIONS CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN! CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO DOT OPEN COVERS. NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL The lighting flash with a arrowhead symbol, in an equilateral triangle, is intended to alert the user. -
Page 4: Table Of Contents
INDEX --------------------------------------------------------------------- Summary ----------------------------------------------------- Introduction of Functions -------------------------------------------- III. Introduction of the Keyboard Panel The Sketch of the Front Panel and Description of Buttons---------------------------------1 Rear Panel-------------------------------------------------------------------------------------------3 IV. Setting of the Keyboard --------------------------------------------------------3 4.1 Setup of the Protocol and the Default Baud Rate -------------------------------------3 4.2 Setup of the Baud Rate of Communication---------------------------------------------- ---------------------------------------------------- Operation of the Keyboard... -
Page 5: Summary
I. Summary The keyboard controller is used for terminal receivers such as the intelligent speed dome and the decoder etc. Taking the EIA/RS-485 electrical interface between the keyboard and the receiver, one keyboard can control as much as 32 speed dome and decoders without driving the bus and the maximum communication distance between the keyboard and the receiver is up to 1.2 km. - Page 6 CALL PRESET SHOT C urrentC am I D : 001 LIVE TAPE SEQ PTZ/MULX FUNC WIDE TELE NEAR CAM/ID AUTO OPEN CLOSE E nt er C l ear PTZ & Multiplexer (Figure 1) Func（1 cam） ：Set special function of the system together with other buttons. Zoom（Full screen）...
-
Page 7: Rear Panel
2. Rear Panel (Figure 2) (Figure 2) A. Power input connector: input DC12V power. B. ID-Code switch: Used to set the protocol in use and the baud rate of communications. C. Communication connector RS485: The controller is connected to adapter box by specific cable. IV. -
Page 8: Operation Of The Keyboard
COP-2/9600Bps 1 2 3 4 5 6 7 8 PELCO-D/2400Bps 1 2 3 4 5 6 7 8 PELCO-P/4800Bps 1 2 3 4 5 6 7 8 PELCO-P/9600Bps 1 2 3 4 5 6 7 8 Switching control between speed dome and multiplexer： The controller can be operated in two modes: Speed Dome and Multiplexer. - Page 9 track is 4 seconds Speed Range：1 to 8 from the fastest to the lowest. Any speed outside the range will be referred as the 1st class; the range of the dwelling time is：1 to 255. When the No. N preset point is set as No. 0, then all preset points before the No. N preset point in the track will be valid however all numbers of preset points afterward and their speed and dwelling time shall be set as 0 automatically.
-
Page 10: Installation And Connection
Back Light Compensation Zero Illumination Display Digital Zoom Back Light of Keyboard Screen Focus Automatic Manual Iris Automatic Manual Automatic Manual White Balance Mode（WB） Indoor Mode Outdoor Mode ATW Mode One Push WB Black & White/Color Switching Color Black & White <... - Page 11 Figure6 Figure5 Figure 7...
-
Page 12: Technical Specifications
Figure 8 VII. Technical Specifications： Communication between Speed Dome Camera and Controller：Port to multi-port and half duplex function. Communication connector: RS-485. Baud Rate of Communication：Four baud rates i.e. 2400bps, 4800bps, 9600bps and 19200bps. Distance of Communication：1200m in maximum Power Supply：DC12V/1A Size：315 ×... - Page 13 In case the keyboard controls the multiplexer, select the camera (1-16): N + Enter N: channel Number (1--16). When the keyboard controls the multiplexer, please refer to concerned operation manual of the multiplexer. ZOOM CAMERA CONTROL OPERATION FOR 15-CZ45 & 15-CZ55 一.
