FTE-7100
Optical Time Domain Reflectometer
User's Guide
This guide is written for use with the FTE-7100 OTDR series.
Revision A
1/2019
Information contained in this manual is believed to be accurate and reliable, however, no responsibility is
assumed by Terahertz Technologies Inc. for its use nor for any infringements of patents or other rights of third
parties that may result from its use. No license is granted by implication or otherwise under any patent rights of
Terahertz Technologies Inc.
The information contained in the publications is subject to change without notice.
Copyright 2019
Advertisement
Table of Contents
Summary of Contents for Terahertz Technologies FTE-7100
- Page 1 Information contained in this manual is believed to be accurate and reliable, however, no responsibility is assumed by Terahertz Technologies Inc. for its use nor for any infringements of patents or other rights of third parties that may result from its use. No license is granted by implication or otherwise under any patent rights of Terahertz Technologies Inc.
-
Page 2: Table Of Contents
Table of Contents Using This Manual…..…………........……............….…………………1 Safety....…...........…….………......…………………...…………2 FTE-7100 OTDR Quick Start Guide..................……..……..…..4 Introduction …………..……....................…….……..……..5 OTDR Inspection and Identification..................…………...…...……6 Inspection 5.2 Identification and Configuration FTE-7100 OTDR Description…….………................……..……..….7 6.1 OTDR Physical Description Instrument Enclosure Front View Top View 6.2 Home Screen Display 6.3 Power Requirements 6.4 Battery Replacement Fault Locator............……..................10 Fault Locator Operation Set Wavelength... - Page 3 Table of Contents (Continued) 8.6 Manual Expert Mode Set IOR Set Wavelength Set Range Set Pulse Width Set Averaging Time Scan Construction Mode Create or Open a Project Set Base File Name Set Wavelengths Start Testing Exit Construction Mode Trace Analysis Unit of Measure Zoom Cursor Movement Loss Measurements 2 Point Loss dB/km Optical Return Loss Basic Splice Loss Least Square Approximation (LSA)
- Page 4 Table of Contents (Continued) 9.2 Project Management Operation Create a New Project Open an Existing Project Delete a Project Upload a Project to CertSoft Rename a Project Modify Properties Temporary Modification of Parameters Exit Project Management File Management..............................35 10.1 File Management Description File Management Screen File Management Menu File Management File Tab File Management Edit Tab File Management View/Help Tabs 10.2 File Management Operation Saving a Trace Open/View a Trace Dual Trace Mode Delete a File...
- Page 5 Table of Contents (Continued) 11.6 Pass/Fail Criteria Tables Fiber End Face Criteria Table for Angled PC Polished Connectors Fiber End Face Criteria Table for Ultra PC Polished Connectors Fiber End Face Criteria Table for PC Polished Connectors Loss Test Set........…...........…........…....43 12.1 Entering Loss Test Set Function 12.2 LTS File/Help Icon Menu Home Quick Save Project Management File Management Help 12.3 Light Source Operation Selecting Light Source Wavelength Selecting Source Modulation 12.4 Power Meter Operation Set Power Meter Wavelength Set Reference Set Measurement Units...
-
Page 6: Using This Manual
Chapter 1 Using This Manual This manual contains operation information for the Terahertz Technologies Inc., FTE-7100 OTDR Optical Time Domain Reflectometer. The touchscreen is a resistive style screen and only proper stylus devices should be used while operating this product. Precautions Optical time domain reflectometers are optical instruments that emit laser radiation and though this level of radiation is not considered a danger, there are safety considerations and certain practices that should be followed. -
Page 7: Safety
Do not incinerate batteries. All batteries should be disposed of in a proper manner. Failure to follow these caution statements could cause unsafe conditions for the operator and equipment and may void the warranty. FTE-7100 OTDR User's Guide Rev A 1/2019... - Page 8 If a live fiber is connected to the OTDR and a scan is attempted, a warning dialog will be displayed as in fig. 2.1. Immediately remove the live fiber from the OTDR and press select to clear the message. Fig 2.1 FTE-7100 OTDR User's Guide Rev A 1/2019...
-
Page 9: Chapter 3 Quick Start Guide
The Event tab displays the trace with numbered events and an interactive event table, while the Schematic tab displays the trace with numbered events and the interactive Fib-R-Map schematic view of the data. FTE-7100 OTDR User's Guide Rev A 1/2019... -
Page 10: Introduction
Chapter 4 Introduction Dear Valued Customer, Thank you for choosing Terahertz Technologies Inc. for your fiber optic testing requirements. Our professional staff is available to answer questions and provide any assistance that you may require. At Terahertz Technologies Inc., we strive to provide premier customer care and technical support through timely responsiveness and training. We are proud of our quality and high standards and aim to produce the most user-friendly and affordable fiber optic solutions to meet individual needs. FTE-7100 OTDR User's Guide Rev A 1/2019... -
Page 11: Inspection
Manual and CertSoft software on CD. SC OTDR adapter ST, FC, SC, 1.25 universal and 2.5 universal Power Meter adapters 5.2 Identification and Configuration The instrument’s Model/Part Number, Serial Number and Date of Manufacture are indicated on a label located on the back of the unit. The instrument’s history is filed at the factory by model/part number and serial number. The unit's serial number is also located on the top plate just above the USB Port. Fig 5.1 FTE-7100 OTDR User's Guide Rev A 1/2019... -
Page 12: Otdr Physical Description
6.1 OTDR Physical Description Instrument Enclosure The TTI FTE-7100 OTDR is packaged in a rugged housing which is further protected with a rubber- ized boot. Although the front panel is weather resistant, care must be taken to avoid liquids and con- taminants around the fragile optical and electrical connectors, and the glass display. Use a mild clean- ing agent and soft damp cloth to clean up the panels and the outside case. -
Page 13: Home Screen Display
VFL (VisualFault Locator) Touch this icon to display the (This will be greyed out if not available) availabe options, ports and version Fig 6.3 number for a unit 6.3 Power Requirements The FTE-7100 OTDR is equipped with a 3500mAh Li-ion battery. The FTE-7100 OTDR is supplied with a 100-240V USB power adapter with 5VDC, 2.1A output. A fully charged Li-ion battery will typically enable approximately 6 hrs. of use and require approximately 4 hours of recharging. FTE-7100 OTDR User's Guide Rev A 1/2019... -
Page 14: Battery Replacement
Do not incinerate batteries. All batteries should be disposed of in a proper manner. Failure to follow these caution statements could cause unsafe conditions for the operator and equipment and may void the warranty. FTE-7100 OTDR User's Guide Rev A 1/2019... -
Page 15: Set Wavelength
To select the wavelength to be tested, touch the wavelength indicator as shown in Fig. 7.1 above, this will display a list of the available wavelengths, touch the deisred value. Start Scan To start a scan, touch in the bottom right corner of the display. The message "Please Wait, Scanning" will be displayed. The scan will take about 15 seconds. FTE-7100 OTDR User's Guide Rev A 1/2019... -
Page 16: Chapter 7 Fault Locate Operation
7.2 Fault Locator Screen The fault locator screen includes the event table, Fib-R-Map (Schematic View) and event map view of highlighted event. Event Table Trace Parameters Fib-R-Map (Schematic View) Event Map with adjustable splice zones Fig 7.2 FTE-7100 OTDR User's Guide Rev A 1/2019... -
Page 17: Event Table
Event Table Loss Between dB Per/Km, Kf or Mi Previous and Event Loss in Between Events Event Location Current Events Event Type or Pass/Fail Reflectance Value Event Number EOF Event Information System ORL Link Information Link dB Per/ Link Loss Km, Kf or Mi Fig 7.4 FTE-7100 OTDR User's Guide Rev A 1/2019... - Page 18 "E", there is not value displayed, it simply shows "End" and in the "L" row, the Optical Return Loss for the link is displayed (System ORL).. 7.3 Exit Fault Locator Touch the home icon in the top menu. FTE-7100 OTDR User's Guide Rev A 1/2019...
-
Page 19: Chapter 8 Otdr Operation
Chapter 8 OTDR Operation 8.1 Entering OTDR Function ress the power button the to turn on the FTE-7100 OTDR. Touch the OTDR icon to enter the OTDR function. 8.2 Menu and Menu Icon Definitions To open the menu, touch the top of the display and the menu will drop down to be viewed. B elow is the list of icons and their meaning. -
Page 20: Main Otdr Screen
Touch of available settings and long touch anywhere in this area to cycle anywhere in the area to start or stop in this area to open the Parameter through the loss methods. a scan. Settings Page. Fig 8.2 FTE-7100 OTDR User's Guide Rev A 1/2019... -
Page 21: Otdr Parameter Settings Screen
Settings icon. Trace Parameter Settings Event Table/Fib-R-Map Sensitivity Settings Pass/Fail Thresholds Settings End of Fiber Pass/Fail Date and Time Threshold Setting Return Save Entries and Returns User to Previous Screen Fig 8.4 FTE-7100 OTDR User's Guide Rev A 1/2019... -
Page 22: Date/Time Settings
Touch the arrows on either side of the month to set the month then touch the correct date. Touch the up and down arrows for each digit to set the time. Once the correct time is entered, press select. Exit Parameter Setting Screen Touch Return to exit the parameter screen. FTE-7100 OTDR User's Guide Rev A 1/2019... -
Page 23: Start Auto Test
Short touch the Range icon and the top selections in the available ranges will be Auto. Touch auto and the unit will be set for Auto Test. Touch Scan to start the test. The OTDR will conduct a test at the selected wavelength with a 60 Sec. average time, unit selected pulse width and range parameters appropriate for the fiber under test. FTE-7100 OTDR User's Guide Rev A 1/2019... -
Page 24: Manual/Expert Mode
Touch the (Lambda) icon on the display to open the wavelength list and choose the desired wavelength for the test. Note: Dual wavelength indicators, such as 850/1300 or 1310/1550 are used for construction mode operation. FTE-7100 OTDR User's Guide Rev A 1/2019... -
Page 25: Set Range
Touch the Averaging Time indicator on the display to open the list of averaging setting and choose the desired time for the test. Scan Once all the proper settings have been entered, touch Scan to take the trace. To stop the trace touch Scan again. FTE-7100 OTDR User's Guide Rev A 1/2019... -
Page 26: Construction Mode
Close at the bottom of the dialog to go back to the projects screen With the project enter and in the highlighted position, touch it to open the file management screen. Set Base File Name Once the project folder has been created and or opened, the files folder for that project will be displayed. A base file name for the test should be established. Pull the file management menu down, touch file and then save. Use the on-screen keyboard to enter a base file name. When testing in construction mode, files will be save in numeric order with the first two digits of the wavelength added to the end of the file name. For example, if the base file name of SAMPLE is entered, the first test in construction mode (If the test were at 1310/1550nm) would be a test at 1310nm with a name of SAMPLE.1.13 and the second test would be the same fiber at 1550nm with a name of SAMPLE.1.15. The next tests would be SAMPLE.2.13 and SAMPLE.2.15, etc. If a fiber number other than one was to be tested, the base file name should have a .X added. For example, if the test was to start at fiber 15, the base file name should be SAMPLE.14. When the construction mode test is completed, the files saved will be SAMPLE.15.13 and SAMPLE.15.15. Once the base file name is set, exit the file manager by pulling down the file menu, touch the file tab, and touching exit. FTE-7100 OTDR User's Guide Rev A 1/2019... - Page 27 OTDR screen or open the event analysis screen through the icon menu. For information about marobend analysis, please refer to section 8.11 of this guide. Exiting Construction Mode To exit construction mode, set the wavelength to a single wavelength. FTE-7100 OTDR User's Guide Rev A 1/2019...
-
Page 28: Loss Measurements
The active cursor will snap to the position touched on the screen or fine adjustments may be made using the left or right triple chevron indicators in the scale bar just below the trace. Loss Measurements 2 Point loss 2 Point loss measurements take into account the difference in vertical height between where the A and B cursors cross the fiber trace. This information is located on the main OTDR screen in the A-B section of the trace information as shown in Fig. 8.2. This is a quick method of checking the loss between any two points on a fiber optic link. dB/km The dB/Km (dB/Kft or dB/Mi) loss method takes the 2 Point loss in dB and divides by the distance between the cursors in Km (Kilometers), Kf (Kilofeet) or Mi (Miles). For accurate dB/..loss measurements, the two cursors must be on level backscatter points at least 100m apart. (NA will show for distances that are not sufficient for measurement). Optical Return Loss This Optical Return Loss (ORL) is separate from the event ORL (Reflectance) that is displayed in the event analysis under the TYPE header for an individual event. The measurement displayed in the loss measurement area of the main OTDR screen and in the L (Link) row in the TYPE column is an optical return loss based on the entire link. It is the total accumulated light reflected back to the source along the fiber optic link. FTE-7100 OTDR User's Guide Rev A 1/2019... -
Page 29: Basic Splice Loss
There will be four vertical dashed lines on the display. To set point number one, touch and hold the stylus on the first splice loss point. Drag point number one to the desired location. Continue with the remaining splice loss points. See Fig. 8.6 for proper positioning of splice loss points. To close the splice loss adjustment screen, touch in an open area of the display well away from the cursors. Note It is necessary to set these areas in clear backscatter to acquire the most accurate measurements; they must not include other events. FTE-7100 OTDR User's Guide Rev A 1/2019... - Page 30 The vertical green line is used to show which point of the LSA measurement areas is the focus of the left and right buttons. To move to the next point, press the Select button. FTE-7100 OTDR User's Guide Rev A 1/2019...
-
Page 31: Lsa Examples
Fig 8.8 Proper LSA Setting: The LSA area and cursor are set properly. The green LSA indica- tor line is over laying the back scatter of the trace properly. Fig 8.9 FTE-7100 OTDR User's Guide Rev A 1/2019... -
Page 32: Enter Event Analysis
If a 1.00dB splice/event loss is acceptable, set the threshold to 1.00. If a splice loss of 1.00 is the fail point, set the threshold to 0.99 ORL: If a system ORL of -35.dB reflectance is acceptable, set the threshold to 35. If -35dB is the fail point, set the threshold to 35.1. Refl: If a -45dB, event reflection is acceptable, set the threshold to 45. If -45db link loss is the fail point, set the threshold to 45.1. Link: If a 20dB, link loss is acceptable, set the threshold to 20. If 20db link loss is the fail point, set the threshold to 19.5. EOF: If an event loss of 3dB, should trigger the end of fiber, set this to 3.0 if the end of fiber should be anything greater than 3 dB loss, set it to 3.1. FTE-7100 OTDR User's Guide Rev A 1/2019... -
Page 33: Sensitivity Settings
Macro. To exit dual trace and macro bend analysis, start a new scan. Event Analysis Screen Event Table Fib-R-Map (Schematic View) Event Map with Trace Parameters adjustable splice zones Fig 8.10 FTE-7100 OTDR User's Guide Rev A 1/2019... - Page 34 Event Table Loss Between Previous and dB Per/Km, Kf or Mi Event Location Event Loss in dB Current Events Between Events Event Type or Pass/Fail Reflectance Value Event Number EOF Event Information System ORL Link Information Link dB Per/Km, Link Loss Kf or Mi Fig 8.12 FTE-7100 OTDR User's Guide Rev A 1/2019...
- Page 35 The value in the "L" line of the table for this column is the link loss. The loss from the beginning of the trace to the event determined to be the EOF. This is the value used to determine if the fiber link passes or fails it's link threshold. dB/Km or Kf or Mi: dB per Kilometer if in KM and DB/KF if in Kilo-Feet and DB/MI if in mile unit of measure. This is the calculated loss per Km, Kf or Mi from the end of the dead zone of the previous event to the beginning of the current event. The value in the "L" line of the table for this column is the dB Per/KM, Kf or Mi for the total link. TYPE: Event Type lists Splc for non-reflective events and displays a reflectance value for reflective events. The "E" end event is marked End and the "L" event displays the System ORL. FTE-7100 OTDR User's Guide Rev A 1/2019...
-
Page 36: Project Management
It is necessary to create the project prior to taking a trace as the file will not be available to save after going through the project creation sequence. Project Management Screen Project Folder List Project Details/Properties Fig 9.1 Project Management Menu To open project management, pull the menu down from the top of the display, move the Folder icon into the highlighted area and touch it to open. Pulling down from the top of the project management screen will open the file management menu. There are four tabs available, File, Edit, View and Help. Fig 9.2 FTE-7100 OTDR User's Guide Rev A 1/2019... - Page 37 Project Management Edit Tab Upload is used to transfer files to the CertSoft software. Rename allows the highlighted folder name to be modified while maintaining all settings and associated files. Properties allows the user to edit the details/ properties displayed at the bottom of the project window. Fig 9.4 Project Management View and Help Tabs View offers the user the opportunity to move to the file manager from the projects page. For onboard help pages, highlight the help tab and press select. Fig 9.5 FTE-7100 OTDR User's Guide Rev A 1/2019...
-
Page 38: Project Management Operation
Upload a Project to CertSoft To upload a folder and all it's associated files from the OTDR to the computer, open the CertSoft software and ensure the OTDR is connected to the computer with the USB cable. NOTE: On the computer screen, the two plugs in the top right corner of the CertSoft screen should show as connected and green. With the project to be uploaded in the highlighted position, pull down the file manager menu, touch Edit and then Upload. The folder with all files will be uploaded to the target folder selected on the computer. NOTE: With CertSoft 2 the files can be pulled from the equipment to the computer using the CertSoft 2's file management feature. FTE-7100 OTDR User's Guide Rev A 1/2019... -
Page 39: Modify Properties
OTDR screen or open the parameter settings screen, set the new parameter and save. All subsequent test will use the new settings until the original settings are returned or the folder is closed and reopened resetting the project parameters. To make temporary changes to event sensitivity or thresholds, open the parameters settings page. Exit Project Management To exit the project management, pull down the file menu, touch File and Exit. FTE-7100 OTDR User's Guide Rev A 1/2019... -
Page 40: File Management
(VIS) images. It operates in conjunction with the projects manager in that, whichever project folder is open/ active, all files saved and listed in the file manager are associated with that project. When the OTDR is first turned on, the default folder is [Default], therefore, any files save without opening a project will be save to the [Default] folder. Any files saved with the LTS or Video Inspection functions will also be associated with the open folder. The active project when the unit is turned off is remembered and will be the active/open project upon startup File Management Screen Project Folder Being Viewed OTDR Traces Files List Trace Details/Properties Fig 10.1 File Management File Menu To open file management, pull the menu down from the top of the display, move the File (Disc) icon into the highlighted area and touch it to open. Pulling down from the top of the file management screen will open the file management menu. The available tabs for file management are File, Edit, View and Help. Fig 10.2 FTE-7100 OTDR User's Guide Rev A 1/2019... -
Page 41: File Management Operation
Quick Save icon while in the highlighted area. To save the trace with a new name, pull the menu down from the top of the screen, position the File icon in the highlighted area and touch it to open file management. Pull the file management tabs down from the top of the display, touch File and Save. This will open file naming window with the on screen keyboard. Name the trace as desired and touch save. The file names are limited to 16 characters. This method should be used to set the base file name for a group of traces. These file names are save exactly as entered. To save files with a chronologically numbered suffix, use the quick save. Quick Save uses the last enter base file name. If a base file name of SAMPLE is saved, the first Quick Save file will be SAMPLE.1, next SAMPLE.2 etc. FTE-7100 OTDR User's Guide Rev A 1/2019... - Page 42 When using CertSoft2, the file upload function is completed using the Software only once the OTDR is connected to the computer. Rename a Trace File To rename a trace file, highlight the file to be renamed. Pull the file tabs down from the top of the display touch edit and Rename. The file name will be displayed with the on-screen keyboard. Use the keyboard to rename the project and touch save. Exit File Management To exit the file management, pull the file management tabs down from the top of the display, touch File and Exit. FTE-7100 OTDR User's Guide Rev A 1/2019...
-
Page 43: Entering Video Scope Function
(Green) 120um Ring 25um Ring (Yellow) Contaminant Scale Pass/Fail Marker Pass/Fail Brightness Zoom Live/Pause and Pass/Fail Grading Auto Pass/Fail Icon Ring Overlay Icon Icon Adjustment Icon Icon Fig 11.1 11.3 Video Scope File/help Icon Menu The icons at the top of the display are Home, File Save, Project Management, File Management, and Help. Home Touch this icon to return to the Home screen. FTE-7100 OTDR User's Guide Rev A 1/2019... -
Page 44: Chapter 11 Video Scope
NOTE: If the connector shows all red or the test fails to complete, maneuver the probe tip to allow for centering of the image and retry the test. Brightness Touch the Brightness icon to cycle the brightness levels for best image quality. FTE-7100 OTDR User's Guide Rev A 1/2019... -
Page 45: Video Scope Operation
NOTE: To auto center the image, touch the center of the connector image and the connector will move as close as possible to the center of the display. FTE-7100 OTDR User's Guide Rev A 1/2019... - Page 46 Marking the points of contamination should be done last, just before saving the image. Once the unit is returned to live mode the markers are removed. Auto Pass/Fail Once the image has been centered as close as possible in the grading rings, set the P/F icon to Auto and touch Live/Pause-Auto Pass/Fail icon. The video scope will evaluate the image and grade it with Pass or Fail. Contamination will be displayed on the image. Exiting Video Scope Operation Touch the Home icon to return to the home screen. FTE-7100 OTDR User's Guide Rev A 1/2019...
- Page 47 Cladding Zone 25µm to 120µm 5 from 2µm to 5µm None > 3µm None > 5µm Adhesive Zone No limit No limit 120µm to 130µm Contact Zone 130µm to 250µm No limit None ≥ 10 µm FTE-7100 OTDR User's Guide Rev A 1/2019...
-
Page 48: Chapter 12 Loss Test Set
Modulation is located in the top right portion of the display. Touch the modulation value indicated and the list of available modulation values will be displayed. Touch the desired value to modulate the source or touch CW for a continuous wave. The available modulation values are CW, 270Hz, 1000Hz and 2000Hz. FTE-7100 OTDR User's Guide Rev A 1/2019... -
Page 49: Set Power Meter Wavelength
Chapter 10 of this user's guide. NOTE: File names will be saved exactly as entered using this method. To have the files saved with incremen- tally number suffixes, use the file manager to save the base file name with the suffix number as the first file to be save in a sequence and then use the Quick Save icon moving forward. Example: Use file man- ger to save the file test as test.001 and when you use quick save for the next test, the file name will be test.002 then test.003 ..12.7 Exiting Lost Test Set Touch the Home icon to exit the loss test set function and return to the home screen FTE-7100 OTDR User's Guide Rev A 1/2019... -
Page 50: Visible Fault Locator
It also aids in conserving battery life. The usable range for fault location depends on many factors, the type of fiber, the type of cable, the overall loss. To activate the VFL, tap the VFL icon to cycle through the available states of off, Continuous and Modulated. FTE-7100 OTDR User's Guide Rev A 1/2019... -
Page 51: Otdr Specifications
14.2 Power Meter Specifications Detector Type InGaAs Connector Type 2.5mm Interchangeable Dynamic Range +5 to -77dB (CATV - +25 to -57dB) Calibrated Wavelengths 850,1300,1310,1490,1550,1625nm (standard units) + 1431-1611nm (CWDM units) ± 0.18 dB under reference conditions, ± 0.25 dB from 0 to -65 dBm, Power Measurement Uncertainty ± 0.35 dB from 0 to +5 dBm and from -65 to -77 dBm Units of Measurement dBm, dB Resolution .01 dB TTI reserves the right to change specifications without notice FTE-7100 OTDR User's Guide Rev A 1/2019... -
Page 52: Light Source Specifications
TTI reserves the right to change specifications without notice. 14.4 Visible Fault Locator Specifications Laser Safety Laser Photo diode 1100 - 1700nm InGaAs -70-+9dBm Emitter Type with interchangeable FC Adapter Wavelength 650nm ±5nm Connector Type 2.5mm Universal Output Power 1mW Max. TTI reserves the right to change specifications without notice. FTE-7100 OTDR User's Guide Rev A 1/2019... -
Page 53: Repair/Warranty
(1) year from the date of delivery. This warranty does not apply to expendable parts such as batteries or optical panel connectors, nor to any instrument or component which has been subjected to misuse, alteration, or fiber connector damage. It is the customer’s responsibility to understand all the instructions and specifications prior to operating this instrument. This warranty does not extend to any loss or damage consequent to the failure of the warranted product. FTE-7100 OTDR User's Guide Rev A 1/2019... -
Page 54: Version Control
The version changes and approximate release dates are as follows. FTE-7100 OTDR V1.0.0.0 11/2018 - Original release FTE-7100 OTDR V1.0.2.0 11/2018 - Add Touch Screen Calibration FTE-7100 OTDR User's Guide Rev A 1/2019...
