Summary of Contents for Beko DFN 6831

  • Page 1 Dishwasher DFN 6831...
  • Page 2 Dear customer, Please read carefully right through this instruction booklet before installing or operating your dishwasher. The following instructions should prevent the risk of personal injury and/or damage to the appliance. Please keep these documents in a safe place for later reference. This operating manual has been written for several different machines, and some of the features mentioned here may not apply to your particular model.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS 1 Getting To Know Your Canceling a Program Programming the Delayed Start Machine Usage of Child Lock View of the Machine Salt Indicator Rinse Aid Indicator 2 Safety Instructions Rinse Aid Indicator Setting Before Installation Starting Your Machine Before First Use Child Safety 6 How to clean your...

  • Page 4: Getting To Know Your Machine

    Getting To Know Your Machine View of the Machine �� �� �� � �� � � �� � �� � � � � �� � 1.Upper basket with rack 11.Salt reservoir lid �� 2.Upper impeller 12.Upper basket rail 3.Lower impeller 13.Ceiling silverware basket 4.Filters...

  • Page 5: Safety Instructions

    Technical Specifications improve our products, we may change our specifications and designs without Permitted water pressure: 0,3 –10 prior notice. bar (= 3 – 100 N/cm² = 0,01-1,0Mpa) Electrical connection: 220-240 Volts, Note for Testing Institutes 10 Amps (see type plate) The necessary information for Energy efficiency class “A”...

  • Page 6: For Daily Operation

    while the appliance is open, as Problems the appliance may still contain • Repairs and modifications to the detergent leftovers. appliance may only be carried • The water in the dishwasher is not out by qualified customer service drinking water. Danger of caustic personel.

  • Page 7: Directions For Assembly

    Directions for Assembly Safety notes for installation Installing Your Dishwasher • Prior to installing and using your Choose a suitable location for your appliance, please check it for possible dishwasher. Take care to ensure transit damage. that the appliance is stable on a If the appliance is damaged, please level surface.

  • Page 8: Water Connection

    Water connection Permitted water temperature: up to 25°C 1009 • The dishwasher may not be connected to open warm water devices or flow-through water AQUASAFE+ (depending on the heaters. model) The AQUASAFE+ System protects Permitted water pressure: against water damage which may be Lowest permitted water pressure: 0.3 caused at the water inlet hose.

  • Page 9: Water Drainage

    Water drainage Extension hoses If a hose extension is required, a Connecting the drainage hose. drainage hose of equal quality must be used. Take care to ensure that the drainage hose is not bent or squeezed. The maximum length must not exceed 4m.

  • Page 10: Using Your Dishwasher

    Materials used are recyclable Packaging materials may be according to their labelling. Reuse, dangerous to children. Reusable recycling of materials and further substances may be dropped off at your reutilization of used products are local disposal facilities. You may obtain important contributions to protect our further information from your local environment.

  • Page 11: When Operating For The First Time

    When operating for the first � time: • Pour 1 litre of water into the salt container (Fig. C). • Pour the salt into the container with the aid of the salt funnel provided (Fig. D). • Pour in enough salt to fill the container.

  • Page 12: Filling The Rinse Aid Dispenser

    Filling the Rinse Aid Dispenser Rinse aids allow washing water to rinse off more cleanly and prevent watermarks or streaks on the dishes. Only use rinse aid designed for use in dishwashers. If you use “2 in 1” or “3 in 1“ 1013 detergents / tablets, you do not need �...

  • Page 13: Detergent

    Detergent The detergent container holds a total of 40 cm³ of detergent (1). Please use detergents produced specially for the dishwashers in your When the dishwasher is fully loaded machine. and the dishes are very dirty, we recommend filling the detergent Keep the opened detergent container up to the 25 cm³...

  • Page 14: Multipurpose Detergents

    Excessive usage of powder detergents Contact the detergent producer if your can cause the detergent not dissolve dishes are wet and/or if you notice lime completely and can also cause spots particularly on your glasses after scratches on the glassware. the washing program is over.

  • Page 15: Suggestions For Loading The Dishwasher

    • 4 folding plate support rods The movement of the spray arms must not be hindered (depends on the model) • Place all large and very dirty items There are four separate “folding plate in the lower basket. support rods” in the lower basket of •...
  • Page 16 2 folding plate support rods � � (depends on the model) There are two separate “folding plate support rods” in the lower basket of your dishwasher designed to allow 1054 you more space to accommodate saucepans and large bowls in the lower basket.
  • Page 17 Variable cutlery basket (depends on the model) The variable cutlery basket can be separated into 3 parts depending on the amount of cutlery and the degree of dirtiness. Small cutlery basket sections also fit into the upper basket. � To do this, turn the lock on the handle to the right (A).
  • Page 18 Cutlery Basket Movable Cutlery Basket (depends on the model) (depends on the model) Designed to allow free placement of the dishes according to their size, the movable cutlery basket can slide over the tines to the left (A) and right (B) side.
  • Page 19 Basket insert with variable height settings (depends on the model) You can also use this insert in the lower basket for glasses and long- handled cutlery / utensils. If you do not need the insert, fold the rack upwards at the angle shown (A). Push the entire insert upwards (B).

  • Page 20: Loading Suggestions

    Loading suggestions Load the upper basket with dessert plates, cups, glasses etc. 1027 Upper basket with variable height setting (depends on the model) The upper basket is equipped with a lifting mechanism which enables you to change the height of the basket without having to remove it from the dishwasher, even if it is fully loaded.
  • Page 21 Upper basket with variable height setting (depends on the model) The upper basket is equipped with a lifting mechanism which enables you to change the height of the basket without having to remove it from the dishwasher, even if it is fully loaded. �...
  • Page 22 Height setting with empty basket (depends on the model) In this model, the height setting of the upper basket may be changed using the wheels which are mounted at two different heights. Release the latches on both the right � and left tracks of the upper basket by pushing them outwards (C).
  • Page 23 Glass Support (depends on the model) When placing the glasses or goblets with a long grip, lean them against the glass support, the edge of the basket or the shelf but not against the other pieces. Do not lean the long glasses against each other, otherwise they do not remain stable during washing cycle and may get damaged.

  • Page 24: Removable 3Rd Basket

    Removable 3rd basket (depends on the model) The Removable 3rd basket is designed for small dishes, or long dishes that cannot fit into the cutlery basket. Thanks to the easy take-out feature, it allows removing the dishes from the machine together with the basket after washing operation.

  • Page 25: Program Selection And Operating Your Machine

    Program Selection and Operating Your Machine � � � � � � � � On / Off Button Express Button Start/Pause/Cancel Button Combi Tablet Button Display Delayed Start Button Program Selection Button Handle Half Load Button 10. Program Indicator �� ��...

  • Page 26: Button And Button Descriptions

    Button and Button Descriptions change depending on the model you have purchased. On / Off Button (1) Half Load Button (5) When you press the On/Off button, the If you want to run your machine without display switches on with the last program loading it completely, place your dishes used and it dims when you turn the into the machine as you desire.

  • Page 27: Program Selection

    Program Selection program selection button (4). Press the button of the function that You can select the desired program after you want to enable and check to turning on the machine by pressing the see thee indicator for the relevant On / Off button (1).

  • Page 28: Programming The Delayed Start

    Programming the Delayed press the Start / Pause / Cancel button (2) for three seconds. Release the Start button when symbols (12) start You can delay the start of the selected flashing in the display. For a couple of program until 24 hours. Delayed start minutes the machine will fulfill the can not be set after the program starts.

  • Page 29: Rinse Aid Indicator

    even if the salt container is empty. rinse aid indicator will never come (Adjusting the water hardness level is explained in Water Softening System section.) Starting Your Machine • Plug the mains plug into the wall Rinse Aid Indicator socket. •...
  • Page 30 (2) again. Program will resume running. • End of Program indicator (20 d) will light up. • Turn off your machine by pressing On / Off button (1). • Close the tap. • Unplug the mains plug from the wall socket. •...
  • Page 31 30 GB...

  • Page 32: How To Clean Your Dishwasher

    How to clean your dishwasher Cleaning your machine at regular intervals ensures longer product life and reduces the risk of reccurring problems. Always unplug the machine and � turn off the water supply before � cleaning. Use a gentle household cleaner for the outside and the door seals.

  • Page 33: Cleaning The Spray Arms

    Cleaning the spray arms Cleaning the filter inset in the water inlet hose (depends on the model) Dirt or calcium residue may block the Dirt from deposits in the water pipes is nozzles on the spray arms. For this prevented by a filter in the water inlet reason, regularly check the spray hose.

  • Page 34: Troubleshooting

    Troubleshooting: What to do if the dishwasher will not run • Check that the mains plug is properly connected. • Are all fuses working? • Is the water supply fully turned on? • Is the dishwasher door closed firmly? • Have you pressed the On/Off button? •...
  • Page 35 Inadequate rinse aid Increase rinse aid setting or add rinse aid into rinse aid compartment. Unsealed detergent dispenser lid Always ensure that the detergent compartment lid is closed tightly after every detergent filling process. Drying Disorderly placement Load your dishes as described in the manual. Inadequate rinse aid Increase rinse aid setting or add rinse aid into rinse aid compartment.
  • Page 36 1035 Lime Stains, Hazy Look Inadequate rinse aid Increase rinse aid setting or add rinse aid into rinse aid compartment. Insufficient water softening In products equipped with water softening setting, water softening should be properly set in accordance with the hardness of the supply water. Add salt into the salt container, if necessary.
  • Page 37 1041 Scratch / Break In Glassware Kitchenware containing Aluminum Kitchenware that contains aluminum should not be washed in dishwashers. Salt leakage* Use the supplied salt funnel while filling in softening salt. Make sure that the salt box cover is tightly closed after finishing the filling process. Run a washing program to clean up the salts spilled in the machine.
  • Page 38 1038 Detergent Remains In The Detergent Dispenser Damp detergent compartment Make sure that the detergent dispenser is well dried prior to filling it with detergent. Putting detergent in the detergent dispenser long before washing Take care that detergent is put shortly before startup of washing. Blocking the opening of detergent dispenser lid dwing washing Ensure that the lid of detergent dispenser is not blocked by improper loaded dishes.
  • Page 39 Leaving the dishes in the dishwasher for a long time If you are not going to run your dishwasher immediately, load the dishes into your machine after scraping the excessive soil on them and do not tightly close the door of the machine. Every other day, perform washing without detergent in the shortest program for products with program selecting feature.

  • Page 40: Service

    Service If your appliance ever malfunctions, check the notes and advice given in the operating manual. If this does not fix the problem, our customer service staff are available to assist you. 39 GB...
  • Page 41 17 9792 01 00 -AG-YM...
