ASROCK EC262D4U2-2Q/E810 User Manual

Server/workstation motherboard

Hide thumbs

Table Of Contents

Quick Links

Download this manual

User Manual

EC262D4U2-2L2Q/E810

EC266D4U2-2L2Q/E810

Version 1.0

Published September 2023

Table of Contents

Need help?

Do you have a question about the EC262D4U2-2Q/E810 and is the answer not in the manual?

Questions and answers

Summary of Contents for ASROCK EC262D4U2-2Q/E810

Page 2: Copyright Notice
(including damages for loss of profits, loss of business, loss of data, interruption of business and the like), even if ASRock Rack has been advised of the possibility of such damages arising from any defect or error in the documentation or product.
Page 3 INTEL END USER SOFTWARE LICENSE AGREEMENT IMPORTANT - READ BEFORE COPYING, INSTALLING OR USING. LICENSE. Licensee has a license under Intel’s copyrights to reproduce Intel’s Software only in its unmodified and binary form, (with the accompanying documentation, the “Software”) for Licensee’s personal use only, and not commercial use, in connection with Intel-based products for which the Software has been provided, subject to the following conditions: (a) Licensee may not disclose, distribute or transfer any part of the Software, and You agree...
Page 4 If you require assistance please call ASRock Rack Tel : +886-2-55599600 ext.123 (Standard International call charges apply)
Page 5 ASRock Rack follows the green design concept to design and manufacture our products, and makes sure that each stage of the product life cycle of ASRock Rack product is in line with global environmental regulations. In addition, ASRock Rack disclose the relevant in- formation based on regulation requirements.
Page 6: Table Of Contents
Contents Chapter 1 Introduction Package Contents Specifications Unique Features Motherboard Layout Onboard LED Indicators I/O Panel Block Diagram Chapter 2 Installation Screw Holes Pre-installation Precautions Installing the CPU Installing the CPU Fan and Heatsink Installing Memory Modules (DIMM) Expansion Slots (PCI Express Slots) Jumper Setup Onboard Headers and Connectors Dr.
Page 7 3.1.1 UEFI Menu Bar 3.1.2 Navigation Keys Main Screen 3.2.1 Motherboard Information 3.2.2 Processor Information 3.2.3 Memory Information Advanced Screen 3.3.1 CPU Configuration 3.3.2 DRAM Configuration 3.3.3 Chipset Configuration 3.3.4 Storage Configuration 3.3.5 NVME Configuration 3.3.6 ACPI Configuration 3.3.7 USB Configuration 3.3.8 Super IO Configuration 3.3.9 Serial Port Console Redirection 3.3.10 H/W Monitor...
Page 8 3.4.2 DNS Configuration 3.4.3 System Event Log 3.4.4 BMC Tools Event Logs Security Screen 3.6.1 Expert Key Management Boot Screen Exit Screen Chapter 4 Software Support Download and Install Operating System Download and Install Software Drivers Contact Information Chapter 5 Troubleshooting Troubleshooting Procedures Technical Support Procedures Returning Merchandise for Service...
Page 9: Chapter 1 Introduction
In case any modifications of this manual occur, the updated version will be available on ASRock Rack website without further notice. Find the latest memory and CPU support lists on ASRock Rack website as well. ASRock Rack’s Website: www.ASRockRack.com About this motherboard technical support, please visit the website for specific information http://www.asrockrack.com/support/...
Page 10: Specifications
1.2 Specifications EC262D4U2-2Q/E810, EC262D4U2-2L2Q/E810, EC266D4U2-2L2Q/E810 MB Physical Status Form Factor Micro-ATX Dimension 9.6'' x 9.6'' (244mm x 244mm) Processor System Supports Intel® Xeon® E-2400 series processors Socket Single Socket V1 (LGA1700) Thermal Design Power (TDP) EC262D4U2-2Q/E810, EC262D4U2-2L2Q/E810: Chipset Intel® C262 EC266D4U2-2L2Q/E810: Intel®...
Page 11 EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 SATA/SAS Storage Intel® C262/C266 (8 SATA 6Gb/s; RAID 0/1/5/10): PCH Built-in Storage 1 SlimSAS, 1 M.2 Ethernet EC262D4U2-2L2Q/E810, EC266D4U2-2L2Q/E810: Additional Ethernet 2 SFP28 (25GbE) by Intel® E810-XXVAM2* Controller 2 RJ45 (1GbE) by Intel® i210 EC262D4U2-2Q/E810: 2 SFP28 (25GbE) by Intel® E810-XXVAM2* Note * M.2 share lanes with 2x 25GbE SFP28, 2x SFP28 supports possible by...
Page 12 Type AMI 256Mb SPI Flash ROM Features Plug and Play, ACPI 6.4 and above compliance wake up events, SMBIOS 2.8 and above, ASRock Rack Instant Flash Internal Connectors/Headers PSU Connector 1 (24-pin, ATX main power), 2 (8-pin, ATX 12V) Auxiliary Panel...
Page 13 EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 Support OS Microsoft® Windows® - Server 2022 (64bit) Linux® - Red Hat Enterprise Linux Server 8.5 (64bit) / 9.2 (64bit) - SUSE Enterprise Linux Server 15 SP3 (64bit) / 15SP5 (64bit) - Ubuntu 21.04 (64 bit) / 22.04.2 (64bit) *Please refer to the website for the latest OS support list.
Page 14: Unique Features
. With this utility, press the <F6> key during the POST or the <F2> key to enter into the BIOS setup menu to access ASRock Rack Instant Flash. Just launch this tool and save the new BIOS file to the USB flash drive, floppy disk or hard drive, then update the BIOS only in a few clicks without preparing an additional floppy diskette or other complicated flash utility.
Page 15: Motherboard Layout
EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 1.4 Motherboard Layout 24.4cm (9.6in) PWM_CFG1 PSU_SMB1 FRNT_VGA1 BAT1 ATX12V1 ATX12V2 ATXPWR1 DDR5_B2 FAN7 DDR5_B1 FAN6 DDR5_A2 FAN5 DDR5_A1 EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 BUZZER1 FAN4 EC266D4U2-2L2Q/E810 CPU1 (EC262D4U2-2L2Q, EC266D4U2-2L2Q only) SPEAKER1 NUT80_2 SFP28_1 Intel®E810 SFP28_2 USB3_3_4 (EC266D4U2-2L2Q only) UID1...
Page 16 Description Chassis Fan Connector (FAN6) Chassis Fan Connector (FAN7) Front VGA Header (FRNT_VGA1) PWM Configuration Header (PWM_CFG1) ATX 12V Power Connector (ATX12V1) ATX 12V Power Connector (ATX12V2) PSU SMBus Header (PSU_SMB1) ATX Power Connector (ATXPWR1) 2 x 288-pin DDR5 DIMM Slots (DDR5_A2, DDR5_B2)* 2 x 288-pin DDR5 DIMM Slots (DDR5_A1, DDR5_B1)* Chassis Fan Connector (FAN4) Chassis Speaker Header (SPEAKER1)
Page 17 EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 Description Security Override Jumper (SEC_OR1) Front LAN LED Connector (LED_LAN3_4) (EC262D4U2-2L2Q/E810, EC266D4U2-2L2Q/E810 only) PCI Express 4.0 x4 Slot (PCIE4) Clear CMOS Pad (CLRMOS1) M.2 Socket (M2_1) (Type 2230/2242/2260/2280) PCI Express 5.0 x16 Slot (PCIE6) M.2 Socket (M2_2) (Type 2280)
Page 18: Onboard Led Indicators
1.5 Onboard LED Indicators The layout below is only for EC266 reference, both EC266 and EC262 LED locations are the same. 1 2 3 Item Status Description LED_FAN5 FAN5 failed LED_FAN6 FAN6 failed LED_FAN7 FAN7 failed LED_FAN4 FAN4 failed LED_FAN3 FAN3 failed LED_FAN2 FAN2 failed...
Page 19: I/O Panel
UID Switch (UID1) 1G LAN RJ-45 Port (LAN1, shared NIC)** * EC262D4U2-2Q/E810 does not support LAN1 and LAN2. LAN Port LED Indications *There is an LED on each side of IPMI LAN port. Please refer to the table below for the LAN port LED indications.
Page 20 **There is an LED on each side of 1G LAN port. Please refer to the table below for the LAN port LED indications. ACT/LINK LED SPEED LED LAN Port ACT/LINK LED SPEED LED 1G LAN Port LED Indications (EC262D4U2-2L2Q/E810, EC266D4U2-2L2Q/E810 only) Activity / Link LED Speed LED Status...
Page 21: Block Diagram
EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 1.7 Block Diagram EC266D4U2‐2L2Q/E810 EC262D4U2‐2L2Q/E810 topology DDR5 [ECC] DDR5 [ECC] 4400MT/s (2SPC-1DIMM) PCI‐E SLOT6 4000MT/s (2SPC-2DIMM 1R) 3600MT/s (2SPC-2DIMM 2R) DDR5 [ECC] INTEL DDR5 [ECC] Raptor Lake‐S CPU SLIM_SAS4 PCIE x4 Gen4 LGA‐1700 Pin Socket USB 3.2 Gen1 LAN1 2 rear ports I210 PCIE x1 Gen2 (shared NIC) USB 3.2 Gen1 (C262‐2Q not support) 2 front ports I210 LAN2 PCIE x1 Gen2 USB 2.0 USB 2.0 2 front ports...
Page 22: Chapter 2 Installation
Chapter 2 Installation This is a Micro-ATX form factor (9.6'' x 9.6'', 24.4cm x 24.4cm) motherboard. Before installing the motherboard, study the configuration of the chassis to ensure that the motherboard fits into it. Make sure to unplug the power cord before installing or removing the motherboard. Failure to do so may cause physical injuries and motherboard damages.
Page 23: Installing The Cpu
EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 2.3 Installing the CPU 1. Before inserting the 1700-Pin CPU into the socket, please check if the PnP cap is on the socket, if the CPU surface is unclean, or if there are any bent pins in the socket.
Page 24 Please save and replace the cover if the processor is removed. The cover must be placed if wishing to return the motherboard for after service.
Page 25: Installing The Cpu Fan And Heatsink
EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 2.4 Installing the CPU Fan and Heatsink...
Page 26: Installing Memory Modules (Dimm)
2.5 Installing Memory Modules (DIMM) This motherboard provides four 288-pin DDR5 (Double Data Rate 5) DIMM slots, and supports Dual Channel Memory Technology. 1. For dual channel configuration, it always needs to install identical (the same brand, speed, size and chip-type) DDR5 DIMM pairs. 2.
Page 27 EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 The DIMM only fits in one correct orientation. It will cause permanent damage to the motherboard and the DIMM if forcing the DIMM into the slot at incorrect orientation.
Page 28: Expansion Slots (Pci Express Slots)
2.6 Expansion Slots (PCI Express Slots) There are 2 PCI Express slots on this motherboard. PCIE slots: PCIE4 (PCIe 4.0 x4 slot) is used for PCI Express x1 lane width cards. PCIE6 (PCIe 5.0 x16 slot) is used for PCI Express x16 lane width cards. Slot Generation Mechanical...
Page 29: Jumper Setup
EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 2.7 Jumper Setup The illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. The illustration shows a 3-pin jumper whose pin1 and pin2 are “Short”...
Page 30: Onboard Headers And Connectors
2.8 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard. System Panel Header Connect the power switch, PLED+ PLED-...
Page 31 EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 Auxiliary Panel Header This header supports multiple (18-pin AUX PANEL1) functions on the front panel, (see p.7, No. 25) including the front panel SMB, internet status indicator and chassis intrusion pin. A. Front panel SMBus connecting pin (6-1 pin FPSMB) This header allows user to connect SMBus (System Management Bus) equipment.
Page 32 SPI TPM Header This connector supports SPI (13-pin TPM_BIOS_PH1) Trusted Platform Module (see p.7, No. 27) (TPM) system, which can securely store keys, digital certificates, passwords, and data. A TPM system also helps enhance network security, protects digital identities, and ensures platform integrity.
Page 33 EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 ATX Power Connector This motherboard provides a (24-pin ATXPWR1) 24-pin ATX power connector. (see p.7, No. 8) To use a 20-pin ATX power supply, please plug it along Pin 1 and Pin 13. Serial ATA3 Connectors These connectors are...
Page 34 Thermal Sensor Header Please connect the thermal (3-pin TR1) sensor cable to either pin 1-2 (see p.7, No. 30) or pin 2-3 and the other end to the device to monitor its temperature. PWM Configuration This header is used for PWM Header configurations.
Page 35 EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 USB 3.2 Gen1 Header Besides two default USB 3.2 IntA_PA_D+ IntA_PA_D- (19-pin USB3_3_4) Gen1 ports on the I/O panel, IntA_PA_SSTX+ (see p.7, No. 16) there is one USB 3.2 Gen1 IntA_PA_SSTX- header on this motherboard. IntA_PA_SSRX+ IntA_PA_SSRX- This USB 3.2 Gen1 header can...
Page 36: Dr. Debug
2.9 Dr. Debug Dr. Debug is used to provide code information, which makes troubleshooting even easier. Please see the diagrams below for reading the Dr. Debug codes. Code Description 0x10 PEI_CORE_STARTED 0x11 PEI_CAR_CPU_INIT 0x15 PEI_CAR_NB_INIT 0x19 PEI_CAR_SB_INIT 0x31 PEI_MEMORY_INSTALLED 0x32 PEI_CPU_INIT 0x33 PEI_CPU_CACHE_INIT...
Page 37 EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 0x63 DXE_CPU_INIT 0x68 DXE_NB_HB_INIT 0x69 DXE_NB_INIT 0x6A DXE_NB_SMM_INIT 0x70 DXE_SB_INIT 0x71 DXE_SB_SMM_INIT 0x72 DXE_SB_DEVICES_INIT 0x78 DXE_ACPI_INIT 0x79 DXE_CSM_INIT 0x90 DXE_BDS_STARTED 0x91 DXE_BDS_CONNECT_DRIVERS 0x92 DXE_PCI_BUS_BEGIN 0x93 DXE_PCI_BUS_HPC_INIT 0x94 DXE_PCI_BUS_ENUM 0x95 DXE_PCI_BUS_REQUEST_RESOURCES 0x96 DXE_PCI_BUS_ASSIGN_RESOURCES 0x97 DXE_CON_OUT_CONNECT 0x98 DXE_CON_IN_CONNECT...
Page 38 0x99 DXE_SIO_INIT 0x9A DXE_USB_BEGIN 0x9B DXE_USB_RESET 0x9C DXE_USB_DETECT 0x9D DXE_USB_ENABLE 0xA0 DXE_IDE_BEGIN 0xA1 DXE_IDE_RESET 0xA2 DXE_IDE_DETECT 0xA3 DXE_IDE_ENABLE 0xA4 DXE_SCSI_BEGIN 0xA5 DXE_SCSI_RESET 0xA6 DXE_SCSI_DETECT 0xA7 DXE_SCSI_ENABLE 0xA8 DXE_SETUP_VERIFYING_PASSWORD 0xA9 DXE_SETUP_START 0xAB DXE_SETUP_INPUT_WAIT 0xAD DXE_READY_TO_BOOT 0xAE DXE_LEGACY_BOOT...
Page 39 EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 0xAF DXE_EXIT_BOOT_SERVICES 0xB0 RT_SET_VIRTUAL_ADDRESS_MAP_BEGIN 0xB1 RT_SET_VIRTUAL_ADDRESS_MAP_END 0xB2 DXE_LEGACY_OPROM_INIT 0xB3 DXE_RESET_SYSTEM 0xB4 DXE_USB_HOTPLUG 0xB5 DXE_PCI_BUS_HOTPLUG 0xB6 DXE_NVRAM_CLEANUP 0xB7 DXE_CONFIGURATION_RESET 0xF0 PEI_RECOVERY_AUTO 0xF1 PEI_RECOVERY_USER 0xF2 PEI_RECOVERY_STARTED 0xF3 PEI_RECOVERY_CAPSULE_FOUND 0xF4 PEI_RECOVERY_CAPSULE_LOADED 0xE0 PEI_S3_STARTED 0xE1 PEI_S3_BOOT_SCRIPT 0xE2 PEI_S3_VIDEO_REPOST...
Page 40 0xE3 PEI_S3_OS_WAKE 0x50 PEI_MEMORY_INVALID_TYPE 0x53 PEI_MEMORY_NOT_DETECTED 0x55 PEI_MEMORY_NOT_INSTALLED 0x57 PEI_CPU_MISMATCH 0x58 PEI_CPU_SELF_TEST_FAILED 0x59 PEI_CPU_NO_MICROCODE 0x5A PEI_CPU_ERROR 0x5B PEI_RESET_NOT_AVAILABLE 0xD0 DXE_CPU_ERROR 0xD1 DXE_NB_ERROR 0xD2 DXE_SB_ERROR 0xD3 DXE_ARCH_PROTOCOL_NOT_AVAILABLE 0xD4 DXE_PCI_BUS_OUT_OF_RESOURCES 0xD5 DXE_LEGACY_OPROM_NO_SPACE 0xD6 DXE_NO_CON_OUT 0xD7 DXE_NO_CON_IN...
Page 41 EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 0xD8 DXE_INVALID_PASSWORD 0xD9 DXE_BOOT_OPTION_LOAD_ERROR 0xDA DXE_BOOT_OPTION_FAILED 0xDB DXE_FLASH_UPDATE_FAILED 0xDC DXE_RESET_NOT_AVAILABLE 0xE8 PEI_MEMORY_S3_RESUME_FAILED 0xE9 PEI_S3_RESUME_PPI_NOT_FOUND 0xEA PEI_S3_BOOT_SCRIPT_ERROR 0xEB PEI_S3_OS_WAKE_ERROR...
Page 42: Unit Identification Purpose Led/Switch
2.10 Unit Identification purpose LED/Switch With the UID button, user can be able to locate the server working on from behind a rack of servers. Unit Identification When the UID button on the purpose LED/Switch front or rear panel is pressed, (UID1) the front/rear UID blue LED indicator will be truned on.
Page 43: Dual Lan And Teaming Operation Guide
EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 2.11 Dual LAN and Teaming Operation Guide Dual LAN with Teaming enabled on this motherboard allows two single connections to act as one single connection for twice the transmission bandwidth, making data transmission more effective and improving the quality of transmission of distant images. Fault tolerance on the dual LAN network prevents network downtime by transferring the workload from a failed port to a working port.
Page 44: Ssd Module Installation Guide
2.12 M.2 SSD Module Installation Guide There are two Ultra M.2 Sockets on this motherboard. - M2_1 (Key M) supports type 2230/2242/2260/2280 M.2 PCI Express module up to Gen4 x4 (16GT/s x4). - M2_2 (Key M) supports type 2280 M.2 PCI Express module up to Gen4 x4 (16GT/s x4). (BOM option with E810) Installing the M.2 SSD Module Step 1...
Page 45 EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 Step 3 Move the standoff based on the module type and length. The standoff is placed at the nut location D by default. Skip Step 3 and 4 and go straight to Step 5 if using the default nut.
Page 46: Chapter 3 Uefi Setup Utility
Chapter 3 UEFI Setup Utility 3.1 Introduction This section explains how to use the UEFI SETUP UTILITY to configure the system. The UEFI chip on the motherboard stores the UEFI SETUP UTILITY. Run the UEFI SETUP UTILITY when starting up the computer. Please press <F2> or <Del> during the Power- On-Self-Test (POST) to enter the UEFI SETUP UTILITY;...
Page 47: Navigation Keys
EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 3.1.2 Navigation Keys Please check the following table for the function description of each navigation key. Navigation Key(s) Function Description Moves cursor left or right to select Screens Moves cursor up or down to select items + / - To change option for the selected items <Tab>...
Page 48: Main Screen
3.2 Main Screen Once entering the UEFI SETUP UTILITY, the Main screen will appear and display the system overview. The Main screen provides system overview information and allows user- to set the system time and date.
Page 49: Motherboard Information
EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 3.2.1 Motherboard Information Press [Enter] to view the information of the motheboard. 3.2.2 Processor Information Press [Enter] to view the information of the processor.
Page 50: Memory Information
3.2.3 Memory Information Press [Enter] to view the information of the memory.
Page 51: Advanced Screen
EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 3.3 Advanced Screen In this section, set the configurations for the following items: CPU Configuration, DRAM Configuration, Chipset Configuration, Storage Configuration, NVMe Configuration, ACPI Configuration, USB Configuration, Super IO Configuration, Serial Port Console Redirection, H/W Monitor, Network Stack Configuration, Intel SPS Configuration, Drive Health, Tls Auth Configuration and Instant Flash.
Page 52: Cpu Configuration
3.3.1 CPU Configuration Intel(R) Hyper Threading Technology Intel Hyper Threading Technology allows multiple threads to run on each core, so that the overall performance on threaded software is improved. Active Performance-Cores Select the number of cores to enable in each processor package. Please note that the Number of Cores and E-cores are looked at together.
Page 53: Hardware Prefetcher
EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 CPU C6 State Support Use this item to enable C6 deep sleep state for lower power consumption. CPU C7 State Support Use this item to enable C7 deep sleep state for lower power consumption. Package C State Support Use this item to enable CPU, PCIe, Memory, Graphics C State Support for power saving.
Page 54: Intel Trusted Execution Technology
Intel Trusted Execution Technology Enable the utilization of additional hardware capabilities provided by Intel(R) Trusted Execution Technology. It requires a full power cycle to change this for taking effect. CPU Thermal Throttling Enable CPU internal thermal control mechanisms to keep the CPU from overheating.
Page 55: Dram Configuration
EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 3.3.2 DRAM Configuration DRAM Frequency If [Auto] is selected, the motherboard will detect the memory module(s) inserted and assign the appropriate frequency automatically.
Page 56: Chipset Configuration
3.3.3 Chipset Configuration Re-Size BAR Support If system has Resizable BAR capable PCIe Devices, select this item to enable or disable Resizable BAR Support. Onboard LAN1/LAN2/SFP28_1/SFP28_2 EC262D4U2-2Q does not support LAN1/LAN2) Use this item to enable or disable the Onboard LAN function. VT-d Intel Virtualization Technology for Directed I/O helps the virtual machine monitor better utilize hardware by improving application compatibility and reliability, and providing ad-...
Page 57 EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 SLIM2 Mode Selection ( EC266 only) Switch device function to PCIE/SATA. PCIE Link Width Select this item to configure PCIE Link Width. PCIE6 Link Width Select the Link Width for PCIE6. PCIE Link Speed Select PCIE Link Speed.
Page 58: Storage Configuration
3.3.4 Storage Configuration SATA Controller Select this item to enable or disable the SATA controllers. SATA Mode Selection AHCI: Supports new features that improve performance. RAID: Combine multiple disk drives into a logical unit. Please press <CTRL-I> to enter RAID ROM during UEFI POST process. SATA Aggressive Link Power Management SATA Aggressive Link Power Management allows SATA devices to enter a low power state during periods of inactivity to save power.
Page 59: Nvme Configuration
EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 3.3.5 NVME Configuration Launch NVMe driver Select this item to enable or disable launch NVMe driver.
Page 60: Acpi Configuration
3.3.6 ACPI Configuration PCIE Devices Power On Allow the system to be waked up by a PCIE device and enable wake on LAN. Ring-In Power On Allow the system to be waked up by onboard COM port modem Ring-In signals. RTC Alarm Power On Allow the system to be waked up by the real time clock alarm.
Page 61: Usb Configuration
EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 3.3.7 USB Configuration This page displays the information of the USB Module Version, USB Controllers and USB Devices.
Page 62: Super Io Configuration
3.3.8 Super IO Configuration Serial Port 1 Configuration Use this item to set parameters of Serial Port1 (COMA). Serial Port Use this item to enable or disable the serial port (COM). Change Settings Use this item to select an optimal setting for Super IO device. Serial Port 2 Configuration Use this item to set parameters of Serial Port2 (COMB).
Page 63: Serial Port Console Redirection
EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 3.3.9 Serial Port Console Redirection COM1 / SOL Console Redirection Use this item to enable or disable Console Redirection. If this item is set to Enabled, user can configure the Console Redirection Settings. Console Redirection Settings Use this item to configure Console Redirection Settings, and specify how the computer and host computer to which user are connected exchange information.
Page 64: Flow Control
Bits Per Second Use this item to select the serial port transmission speed. The speed used in the host computer and the client computer must be the same. Long or noisy lines may require lower transmission speed. The options include [9600], [19200], [38400], [57600] and [115200]. Data Bits Use this item to set the data transmission size.
Page 65: Serial Port For Out-Of-Band Management/Windows Emergency Management Services (Ems)
EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 Serial Port for Out-of-Band Management/Windows Emergency Management Services (EMS) Console Redirection Use this item to enable or disable Console Redirection. If this item is set to Enabled, user can configure the Console Redirection Settings. Console Redirection Settings Use this item to configure Console Redirection Settings, and specify how the computer and the host computer to which user are connected exchange information.
Page 66: H/W Monitor
3.3.10 H/W Monitor In this section, it allows user to monitor the status of the hardware on the system, includ- ing the parameters of the CPU temperature, motherboard temperature, CPU fan speed, chassis fan speed, and the critical voltage.
Page 67: Network Stack Configuration
EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 3.3.11 Network Stack Configuration Network Stack Use this item to enable or disable UEFI Network Stack. IPv4 PXE Support Use this item to enable or disable IPv4 PXE boot support. If disabled, IPv4 PXE boot support will not be available.
Page 68 PXE Boot Wait Time Specifies the wait time and press the ESC key to abort the PXE boot. Media Detect Count Specifies the number of times the presence of physical storage device are verified on a system reset or power cycle.
Page 69: Intel Sps Configuration
EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 3.3.12 Intel SPS Configuration SPS screen displays the Intel SPS Configuration information, such as Operational Firmware Version and Firmware State.
Page 70: Driver Health
3.3.13 Driver Health Inter (R) PRO/1000 6.5.01 PCI-E Healthy Provides Health Status for the Drivers/Controllers Inter (R) 800 Series Ethernet Driver 4.0.75 Healthy Provides Health Status for the Drivers/Controllers...
Page 71: Tls Auth Configuration
EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 3.3.14 Tls Auth Configuration Server CA Configuration Press <Enter> to configure Server CA. Client Cert Configuration Press <Enter> to configure Client Cert. Enroll Cert Press <Enter> to enroll cert. Delete Cert Press <Enter> to delete cert.
Page 72: Instant Flash
3.3.15 Instant Flash Instant Flash is a UEFI flash utility embedded in Flash ROM. This convenient UEFI update tool allows user to update system UEFI without entering operating systems first like MS- ® DOS or Windows . Just save the new UEFI file to the USB flash drive, floppy disk or hard drive and launch this tool, then update the UEFI only in a few clicks without preparing an additional floppy diskette or other complicated flash utility.
Page 73: Server Mgmt
EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 3.4 Server Mgmt Wait For BMC Wait For BMC response for specified time out. BMC starts at the same time when BIOS starts during AC power ON. It takes around 255 seconds to initialize Host to BMC interfaces.
Page 74 OS Wtd Timer Timeout Configure the OS Boot Watchdog Timer Expiration between 1 to 30 min value. If the OS Boot Watchdog Timer is disabled, this item is not available. OS Wtd Timer Policy Configure how the system should respond if the OS Boot Watchdog Timer expires. If the OS Boot Watchdog Timer is disabled, this item is not available.
Page 75: Bmc Network Configuration
EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 3.4.1 BMC Network Configuration Bonding Setting Select this item to enabled or disabled bonding. Please enable all lan channel first when want to enable bonding. Lan Channel (Failover) Manual Setting IPMI LAN If [No] is selected, the IP address is assigned by DHCP. If using a static IP address, toggle to [Yes], and the changes take effect after the system reboots.
Page 76: Ipv6 Support
The default login information for the IPMI web interface is: Username: admin Password: admin For more instructions on how to set up remote control environment and use the IPMI man- agement platform, please refer to the IPMI Configuration User Guide or go to the Support website at: http://www.asrockrack.com/support/faq.asp VLAN Select this item to enabled or disabled Virtual Local Area Network.
Page 77: Dns Configuration
EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 3.4.2 DNS Configuration Manual DNS Configuration Select this item to manual configure DNS. If [YES] is selected, configure the items below. DNS Service Select this item to enable or disable DNS Service Configuration. Host Name Settings Select this item to automatic or manual Host Name Settings.
Page 78 Domain Name Server Setting Select this item to configure DNS Server Settings. IP Priority Select this item to configure IP Priority.
Page 79: System Event Log
EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 3.4.3 System Event Log SEL Components Change this to enable ro disable event logging for error/progress codes during boot. Erase SEL Use this to choose options for earsing SEL. When SEL is Full Use this to choose options for reactions to a full SEL.
Page 80: Bmc Tools
3.4.4 BMC Tools KCS Control Select this KCS interface state after POST end. If [Enabled] us selected, the BMC will remain KCS interface after POST stage. If [Disabled] is selected, the BMC will disable KCS interface after POST stage Restore AC Power Loss This allows user to set the power state after an unexpected AC/power loss.
Page 81: Event Logs
EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 3.5 Event Logs Change Smbios Event Log Settings Select this item to configure the Smbios Event Log Settings. When entering the item, the screen displays following sub-items: Smbios Event Log Select this item to enable or disable all features of the SMBIOS Event Logging during system boot.
Page 82: Security Screen
3.6 Security Screen This section allows user to set or change the supervisor/user password for the system. For the user password item is allowed user to clear it. Supervisor Password Set or change the password for the administrator account. Only the administrator has authority to change the settings in the UEFI Setup Utility.
Page 83: Expert Key Management
EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 3.6.1 Expert Key Management In this section, expert users can modify Secure Boot Policy variables without variable au- thentication. Factory Key Provision Install factory default Secure Boot keys after the platform reset and while the System is in Setup mode.
Page 84 Platform Key(PK) Enroll Factory Defaults or load certificates from a file: 1. Public Key Certificate in: a) EFI_SIGNATURE_LIST b) EFI_CERT_X509 (DER) c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHAXXX 2. Authenticated UEFI Variable 3. EFI PE/COFF Image(SHA256) Key Source: Factory, Modified, Mixed Key Exchange Keys(KEK) Enroll Factory Defaults or load certificates from a file: 1.
Page 85 EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 2. Authenticated UEFI Variable 3. EFI PE/COFF Image(SHA256) Key Source: Factory, Modified, Mixed Forbidden Signatures(dbx) Enroll Factory Defaults or load certificates from a file: 1. Public Key Certificate in: a) EFI_SIGNATURE_LIST b) EFI_CERT_X509 (DER) c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHAXXX 2.
Page 86 b) EFI_CERT_X509 (DER) c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHAXXX 2. Authenticated UEFI Variable 3. EFI PE/COFF Image(SHA256) Key Source: Factory, Modified, Mixed...
Page 87: Boot Screen
EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 3.7 Boot Screen In this section, it will display the available devices on the system for user to configure the boot settings and the boot priority. Boot Option #1~#6 Use this item to set the system boot order.
Page 88 Full Screen Logo Enable to display boot logo or disable to show normal POST messages. The default value is [Enabled]. CSM (Compatibility Support Module) Select this item to enable or disable the Compatibility Support Module support. When enabling this item, the sub-items as below are displayed: Launch PXE OpROM Policy Select UEFI only to run those that support UEFI option ROM only.
Page 89: Exit Screen
EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 3.8 Exit Screen Save Changes and Exit Exit system setup after saving the changes. Discard Changes and Exit Exit system setup without saving any changes. Save Changes Save changes done so far to any of the setup options.
Page 90: Chapter 4 Software Support
Please download the operating system from the OS manufacturer. Please refer to the OS documentation for more instructions. * Please download the Intel® SATA Floppy Image driver from the ASRock Rack’s website (www.asrockrack.com) to the USB drive while installing OS in SATA RAID mode.
Page 91: Chapter 5 Troubleshooting
EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 Chapter 5 Troubleshooting 5.1 Troubleshooting Procedures Follow the procedures below to troubleshoot the system. Always unplug the power cord before adding, removing or changing any hardware components. Failure to do so may cause physical injuries and damages to motherboard components.
Page 92 1. Verify if the battery on the motherboard provides ~3VDC. Install a new battery if it does not. 2. Confirm whether the power supply provides adaquate and stable power. Other problems... 1. Try searching keywords related to the related problem on ASRock Rack’s FAQ page: http://www.asrockrack.com/support...
Page 93: Technical Support Procedures
EC262D4U2-2Q/E810 EC262D4U2-2L2Q/E810 EC266D4U2-2L2Q/E810 5.2 Technical Support Procedures If the problems are still unsolved, please contact ASRock Rack’s technical support with the following information: 1. Contact information 2. Model name, BIOS version and problem type. 3. System configuration. 4. Problem description.
Page 94: Contact Information
Contact Information If it needs to contact ASRock Rack or want to know more about ASRock Rack, you’re welcome to visit ASRock Rack’s website at http://www.asrockrack.com; or contact the dealer for further information. For technical questions, please submit a support request form at https://event.asrockrack.com/tsd.asp...
