- Page 1 Ibex- Mounting Flat Landscape Kit Installation Manual...
- Page 2 Ibex-Mounting this manual is not allowed to be applied to any scene except Ibex-Mounting Flat Landscape Kit installation. Don’t try to use this on your cabinet! We know that “The Netherlands” is relatively close to “Scandinavia”. I mean, compared to Japan or something, but the Scandinavians know better than we do how to build their cabinet.
-
Page 3: Table Of Contents
Table of contents Safety instructions Safety recommendations System layout Layout overview Pre-tightening force value of fastener How to instal Adjustment and installation of preassembly of ballast bottom beam 3.1.1 Installation EPDM block 3.1.2 Adjusted support combination (adjusted to 15°°, if no skip) Installation of bottom beam connectors 3.2.1 Installation of grounding lug (if no skip) -
Page 4: Safety Instructions
Do not modify or alter specifications on your own, as this could lead to accidents or malfunctions. Do not use the product if it is damaged, faulty, or deformed, as this could lead to personal injury or accidents. Do not wear an Ibex costume while on the roof. This is simply not safe. -
Page 5: System Layout
System layout Layout overview PRE-ASSEMBLY COMBINATION BALLAST BOTTOM BEAM Adopt AL6005-T6 aluminum material Install under the component Used to support components Preassembled for 5 ° and 10° ° scenarios. BOTTOM BEAM 15° ° REAR LEG CONNECTOR Adopt AL6005-T6 aluminum material Adopt AL6005-T6 aluminum material Installed on the 10°... -
Page 6: Pre-Tightening Force Value Of Fastener
Pre-tightening force value of fastener M8: 10° ~ 12 N*M M8: 10° ~ 12 N*M M6: 4 ~ 6 N*M M6: 4 ~ 6 N*M Rotate 90 degrees M6: 4 ~ 6 N*M As shown in the above figure, the recommended torsion values of fasteners at each joint are sorted into the following table: Recommended torque value for Bolt specification... -
Page 7: How To Instal
How to instal Adjustment and installation of preassembly of ballast bottom beam 3.1.1 Installation EPDM block Tear off the release film (also known as release paper or anti-sticking paper) at the glue back on one side of the EPDM rubber block, and bond and fix the glue side with the correspond- ing bottom beam. -
Page 8: Adjusted Support Combination (Adjusted To 15°°, If No Skip)
3.1.2 Adjusted support combination (adjusted to 15°°, if no skip) Loosen the two M6 bolts on the back of the 10°° rear leg, take out the extended support part and assemble it, and fix the lower and middle parts with two M6 bolts, and the middle and upper parts with two M6 bolts. -
Page 9: Installation Of Bottom Beam Connectors
Installation of bottom beam connectors Pre-loosen two M6 bolts at the corresponding positions of the bottom beam connector(not all of them should be loosened), then slide half of the ballast bottom beam connector into the ballast bottom beam and lock the bolts; Then slide another ballast bottom beam into the ballast bottom beam connector combination, so that the two bottom beams are flush to the top, and lock the bolts on the other side. -
Page 10: Installation Of Grounding Lug (If No Skip)
3.2.1 Installation of grounding lug (if no skip) On the side wall of the end of the installed ballast bottom beam, combine and fix the grounding lug to the bottom beam with self-tapping nails, and pay attention to ensure that the conductive sheet pierces the bottom beam and grounding lug Combination of contiguous blocks... -
Page 11: Installation Of C Steel
Installation of C steel According to the construction drawings of the corresponding project, place the installed bottom beam and support at the corresponding position, and align the corresponding notch of C steel with the chute of ballast bottom beam; Take out the rotating clamp and put it into the notch, and then rotate it 90 degrees. -
Page 12: Installation Of Cement Block
C steel installation completion drawing (single orientation) Installation of cement block Place a corresponding number of concrete piers on the C steel (subject to the actual project) to achieve a fixed arrangement. Back-to-back cement block installation completion drawing Complete installation drawing of single orienta- tion cement block... -
Page 13: Installation Of Photovoltaic Modules
Installation of photovoltaic modules Pre-loosen the side pressing blocks on the front support assembly and the rear support assembly (not completely loosened), and pre-loosen the fixed clamping blocks on the front support assembly (not completely loosened). Pre-loosening-side pressing block (M6) Pre-release-front support (M6) Pre-release-bottom... -
Page 14: Installation Precautions
Installation precautions Two sections back to back Two sections of single orientation Six segments back to back Four sections of single orientation... -
Page 15: Installation Dimension Description
5. Installation precautions Installation dimension description The specific dimensions involved in engineering installation shall be subject to the engi- neering construction drawing, and it is necessary to ensure that the installation dimensions conform to the corresponding engineering construction drawing. This installation instruction is only used to explain the installation method of products. - Page 16 Be bold, go at it!
