Operating instructions | Multi transmitter feel FM
Online version
1 Introduction
1.1 Notes on the operating instructions
These operating instructions are intended to ensure optimum installation, commissioning, operation and
maintenance of the device and must be read prior to these actions. Keep this documentation handy and
accessible to every user in order to be able to refer to it if necessary. If any difficulties should nevertheless
arise during commissioning or operation, please do not make any unauthorized modifications to the device.
Doing so could jeopardize your warranty claim. In such cases, please contact us immediately:
FSM AG | Erich-Rieder-Straße 2 | D-79199 Kirchzarten | Tel: +49 7661 9855 0 | Mail: messtechnik@fsm.ag
1.2 Intended purpose and foreseeable misuse
The feel FM multi-measuring transducer is used to record various measured variables such as differential
pressure, temperature, humidity, VOC and CO2 and convert them into a proportional measurement signal.
The device may only be used in the specified measuring range. Do not use the device in potentially explosive
atmospheres. No liability is accepted for damage resulting from improper use. In this case, warranty claims
become invalid. Unauthorized structural modifications as well as additions or conversions to the device are
prohibited.
2 Notes for your safety
To avoid danger to all persons involved, this device must only be installed and commissioned by qualified and
trained personnel. Furthermore, persons using this device must take measures to protect themselves from
direct contact with the live parts and must have read and understood these instructions.
Version: 1
Bedienungsanleitung
Datasheet
FSM AG │ Erich-Rieder-Str. 2 │ 79199 Kirchzarten www.fsm.ag
Seite 1 von 9
Advertisement
Table of Contents
Related Manuals for FSM feel FM
Summary of Contents for FSM feel FM
- Page 1 Doing so could jeopardize your warranty claim. In such cases, please contact us immediately: FSM AG | Erich-Rieder-Straße 2 | D-79199 Kirchzarten | Tel: +49 7661 9855 0 | Mail: messtechnik@fsm.ag 1.2 Intended purpose and foreseeable misuse The feel FM multi-measuring transducer is used to record various measured variables such as differential pressure, temperature, humidity, VOC and CO2 and convert them into a proportional measurement signal.
-
Page 2: Installation And Start-Up
The figure below shows all connection, control and display elements of the transmitter board and describes their functionality. Figure 1 Connection, control and display elements Version: 1 FSM AG │ Erich-Rieder-Str. 2 │ 79199 Kirchzarten www.fsm.ag Bedienungsanleitung Seite 2 von 9... -
Page 3: Setting The Measuring Range
Enthalpy: -50… 400 kJ/kg | -40… 80°C DIP 1 OFF | DIP 2 ON Abs. Humidity: 0… 150 g/m³ | -40… 80 °C DIP 1 On | DIP 2 ON Version: 1 FSM AG │ Erich-Rieder-Str. 2 │ 79199 Kirchzarten www.fsm.ag Bedienungsanleitung Seite 3 von 9... -
Page 4: Setting The Output Signal
63% (t63) of the nominal value. The time constant can be set as follows via DIP switches 10 and 11 (see 3.2 (1) DIP switches): Version: 1 FSM AG │ Erich-Rieder-Str. 2 │ 79199 Kirchzarten www.fsm.ag Bedienungsanleitung Seite 4 von 9... - Page 5 It is possible to assign a customer-specific number for unique identification of the transmitter via the • "Customer serial number" field. 5.3 Configuration of the transmitter 5.3.1 Unit Open the "Sensors" menu item and select the desired sensor. • Version: 1 FSM AG │ Erich-Rieder-Str. 2 │ 79199 Kirchzarten www.fsm.ag Bedienungsanleitung Seite 5 von 9...
-
Page 6: Measurement Range
As soon as the reference has stably adjusted the calibration point, the transmitter can be adjusted at this point by pressing the respective Version: 1 FSM AG │ Erich-Rieder-Str. 2 │ 79199 Kirchzarten www.fsm.ag Bedienungsanleitung Seite 6 von 9... -
Page 7: Output Signal
The transmitter is now adjusted at the desired point. If the current measured value is +/- 10% outside • the set point, no adjustment is made to avoid false conditions. Parameter Set-Point DIP switch positions Buttons No adjustment possibilty Version: 1 FSM AG │ Erich-Rieder-Str. 2 │ 79199 Kirchzarten www.fsm.ag Bedienungsanleitung Seite 7 von 9... - Page 8 The table below describes the displayed messages and LED states. If the error that has occurred is not listed, please contact FSM AG as soon as possible or send the device in for repair with a meaningful error description.
- Page 9 Incorrect disposal can be hazardous to the environment. Device components and packaging materials must be disposed of in an environmentally friendly manner in accordance with the country-specific waste treatment and disposal regulations. Version: 1 FSM AG │ Erich-Rieder-Str. 2 │ 79199 Kirchzarten www.fsm.ag Bedienungsanleitung Seite 9 von 9...
