Yale Stellar Safe
User Manual
Opening the safe for the first time.
• Remove the keyhole cover on the front panel.
• Insert the key into the lock and turn it clockwise whilst turning the knob
clockwise.
• Remove the battery cover and install the batteries into the compartment
ensuring that they are fitted with the correct corresponding polarity.
• Check whether the key operation is normal, and then close the battery
cover.
• Close the door, and turn the knob counter clockwise to the bottom to lock
safe.
• Turn the override key counter clockwise to the end, and remove the key and
keep it properly (note: do not store it in the safe).
• Close the keyhole cover.
• Press "START"key follow by factory user code 0,0,0,0 and press "START"
screen will display "OPEN" turn the knob to "OPEN" the safe door.
Safe operational usage
1. Set the user code
• Press the red button and the screen displays "SET CSFP" or "SET CUFP".
• Enter 3 to 8 digits and press the "START" button to confirm.
• After the beep is heard, the screen displays "IN" and the new code,
indicating a successful setup.
2. Set the administrator code
• Press the red button, then press the "START" button. Display will show
"OLD CODE"
• Enter the original management code (factory preset code: 8, 8, 8, 8),
press "START" key, the display will display "SET".
• Enter 3 to 8 digits and press the "START" button to confirm. Display will
show "RE INPUT".
• Enter the new administrator code again and press the "START" button.
Upon hearing the beep, the display will display 'IN' and the new
administrative code, indicating a successful setup.
3. Set master fingerprint
• Press the red button, the screen displays "SET CSFP" and wait for the first
scan of the fingerprint.
• Tap your finger on the scanner, the screen displays FPIN 1 and wait for the
second scan of the fingerprint.
• Tap your same finger on the scanner again, the screen displays FPIN 2 and
wait for the fingerprint scanning for third time.
• Tap your same finger on the scanner 3rd time, the screen displays FPIN 3,
and then the screen will display FPN XX(X represents the number of stored
fingerprints), and the green light is on, indicating successful setting.
NOTE: You need to scan the same fingerprint 3 times for register.
• On scan of wrong fingerprint or time out, the screen displays ERROR,
indicating that the addition is unsuccessful.
• The system can store up to 30 fingerprints. First two fingerprints are
registered as master fingerprint.
4. Set user fingerprints
Fingerprint Settings: After addition of two master users, third user onwards
registers as user fingerprints. Master user fingerprint has to be verified before
setting.
• Press the red button, the screen displays "SET CUFP" and prompts to press
the master fingerprint.
• After the master fingerprint authentication, the screen displays "FPIN 0"
and wait for the first scan of the user's fingerprint.
• Tap your finger on the scanner, the screen displays FPIN 1 and wait for the
second scan of the fingerprint.
• Tap your same finger on the scanner again, the screen displays FPIN 2 and
wait for the fingerprint scanning for third time.
• Tap your same finger on the scanner 3rd time, the screen displays FPIN 3,
and then the screen will display FPN XX(X represents the number of stored
fingerprints), and the green light is on, indicating successful setting.
NOTE: You need to scan the same fingerprint 3 times for register.
• If the fingerprint is incorrectly scanned or time out, the screen displays
ERROR, indicating that the addition is unsuccessful.
Part of ASSA ABLOY
IMPORTANT
If you or an intruder inputs the incorrect code, you will hear a beep with
the display showing "Error" and it will not unlock. If incorrect password
attempted 4 times consecutively, the display will show "Error" and the
buzzer will sound for approximately 3 minutes. The correct code
cannot be entered until 3 minutes elapsed.
5. Set unlock mode (Note: Default unlock mode is mode 0)
• Mode 0: Press START button, input 0, press red button behind the door,
display C or F. Enable Pincode or fingerprint to unlock the safe.
• Mode 1: Press START button, input 1, press red button behind the door,
display C and F. Enable Pincode +fingerprint to unlock the safe.
6. Alarms
• On continuous 4 inputs of incorrect usage of Wrong Code or fingerprint
identification "beep" sound will prompt and display "ERROR" & the buzzer
will ring for about 3 minutes(Press the reset button to remove the sound)
Pin-code and fingerprint authentication will not work during the lock state.
7. Unlock the safe
PIN code Access
• Press the "START" button, and the display on the panel will show "- - - - - -".
• Enter the user code or administration code and press the "START" button to
confirm.
• A beep will be heard and the screen will display "OPEN", the electromagnet
pulls on for 5 seconds. Turn the knob to "OPEN"the safe door.
Fingerprint Access
• Press the registered fingerprint on the fingerprint scanner and the fingerprin
module light on, display will show "Open", the electromagnet pulls on for 5
seconds. Turn the knob to "OPEN"the safe door.
PIN code + Fingerprint (unlock mode 1)
• Press "START" button input your preset pincode, the screen displays "GOOD"
then "FP IN". Follow by scanning your preset fingerprint, The screen will
display "OPEN", and the electromagnet pulls on for 5 seconds. Turn the knob
to OPEN the safe door.
Hiding PIN code
• If you do not want to display numbers when you open the safe, just press
the "START" button twice before entering the registered pin code.
Battery replacement warning
Low battery alarm
• If after pressing the 'START' button, display shows 'LO BAT' batteries should
be replaced on priority. When the safe is opened under low-voltage, the
screen displays "OPEN" and "LO BAT" alternately until the electromagnet is
released.
Reset code and fingerprint
• If you forget your password, you can reset it by following below steps.
• Open the safe box with the mechanical key, hold the RESET button for more
than 3 seconds. Beep will be prompted with display showing "RESET" and
then "GOOD". The admin code will be restored to the factory setting "8888"
&the user password will be restored to "0000".
Important : In case of exhausted battery, you can open the safe via emergency
charging option provided at the side of the panel or alternatively it can be
opened via mechanical key provided.
