Supplementary assembly instructions for the 'Clock book'
The Mechanica M3 '20 years Uhrenbausatz' is an exclusive clock kit limited to 20 pieces.
Due to the additional components, the assembly differs significantly from the 'Clock book'
in some sections. Therefore, please refer to the following supplementary assembly
instructions.
Bag 1
24-hours intermediate wheel
◊
24-hours intermediate wheel stud
◊
Cylinder head screw M 1,4 x 3
◊
2 x Cylinder head screw M 2 x 4
◊
24-hours wheel
◊
24-hours wheel stud
◊
Bag 2
Jumper spring stud
◊
Jumper spring
◊
Cylinder head screw M 2,5 x 16
◊
Moon driving wheel
◊
Moon wheel pillar
◊
2 x Cylinder head screw M 2 x 4
◊
Driving wheel
◊
Driving wheel pillar
◊
Cylinder head screw M 1,4 x 3
◊
Bag 3
4 polished knurled nuts
◊
Mechanica M3
"20 years Uhrenbausatz"
- Limited Edition -
Compartment 11
Compartment 11
Compartment 11
Components
Advertisement
Related Manuals for Uhrenbausatz Mechanica M3 20 years Uhrenbausatz
Summary of Contents for Uhrenbausatz Mechanica M3 20 years Uhrenbausatz
- Page 1 - Limited Edition - Supplementary assembly instructions for the ‘Clock book’ The Mechanica M3 ‘20 years Uhrenbausatz’ is an exclusive clock kit limited to 20 pieces. Due to the additional components, the assembly differs significantly from the ‘Clock book’ in some sections. Therefore, please refer to the following supplementary assembly instructions.
- Page 2 Please assemble your Mechanica as described in the clock book. The first difference can be found on page 47 of the book. Preparing the front plate After installing the escapement lever bearings, ensure that the following studs are screwed into the correct positions (from the inside). (see figure 1) The following components from compartment 11, bag 1 are required Compartment 11 Intermediate wheel stud with cylinder head screw M 2 x 4...
- Page 3 Preparing the front plate The following additional components from compartment 11, bag 2 are required Driving wheel pillar with cylinder head screw M 2 x 4 Compartment 11 Moon wheel pillar with cylinder head screw M 2 x 4 Compartment 11 Jumper spring stud and jumper spring and cylinder head screw M 2,5 x 16 Compartment 11 Fitting of the driving wheel and moon wheel pillar, as well as the jumper spring...
- Page 4 To rule out jamming in the bearing points, check the height clearance of the shafts after screwing the plates together. To do this, carefully grab the shaft with the tweezers and make a movement in the axial direction. When you turn the movement over, the shafts must fall audibly against the respective bearings facing the floor.
- Page 5 Fitting the 24-hour module and the moon phase module Please proceed as follows: The following components from compartment 11, bag 2 are required Compartment 11 Hour wheel with hour pipe Compartment 11 Driving wheel with cylinder head screw M 1,4x3 Caution: the driving pin must point upwards First place the hour wheel (4.) on the centre wheel arbor.
-
Page 6: Function Check
When installing the moon wheel (4.), please ensure that the driving pin of the driving wheel is exposed and is not clamped by the moon wheel. It is also important to ensure that the jumper spring rests against the circumference of the moon wheel. It must not be under or over the wheel. - Page 7 Please note: The moon phase must never be adjusted between 10pm and 2am. Moon phase calculator Please refer to the moon phase calculation on our website: https://www.uhrenbausatz.de/en/moon-phase/ or just scan the OR code Call us on Monday till Friday from 9am to 4pm.
- Page 8 February March April 1/31 June July 2/31 August September October November 2/31 1/30 December = full moon = new moon MÜLLER & SATTLER UHRENBAUSATZ GMBH Lohenstraße 6 · D - 82166 Gräfelfing Phone: +49 (0)89 89 55 806-20 info@uhrenbausatz.de www.uhrenbausatz.de...
