INSTRUCTIONS
BANO
EASY BVT
CONSISTING OF
801536
EASY INSTALLATION BASEPLATE & FRAME
BANOs produkter oppfyller kravene til EUs
sikkerhetskrav i "Direktiv for medisinsk
utstyr" 93/42/EEC, klasse 1.
Bano AS
Telefon: +47 57 86 98 00
Industrivegen 22
www.bano.no
6823 Sandane
E-post: post@bano.no
®
Ved fabrikasjonsfeil gir BANO kunden
rett til å bytte produktet til tilsvarende
produkt, eller produkt med tilsvarende
egenskaper, i 3 år fra installasjon.

Advertisement

loading
Need help?

Need help?

Do you have a question about the EASY BVT and is the answer not in the manual?

Questions and answers

Related Manuals for Bano EASY BVT

Summary of Contents for Bano EASY BVT

  • Page 1 BANO EASY BVT CONSISTING OF 801536 EASY INSTALLATION BASEPLATE & FRAME Ved fabrikasjonsfeil gir BANO kunden BANOs produkter oppfyller kravene til EUs rett til å bytte produktet til tilsvarende sikkerhetskrav i “Direktiv for medisinsk produkt, eller produkt med tilsvarende utstyr” 93/42/EEC, klasse 1.
  • Page 2 Bano’s EASY system is designed to make accessible bathroom solutions more flexible and versatile for individual use cases. The EASY frame and baseplate allow for the installation of the BVT (Bano’s rotating toilet and electronic raising cistern) without the need to affix anything aside from the plumbing to the walls or floor.
  • Page 3 B BANO ® Designed for care ATTACHING A CISTERN TO THE FRAME 1. Slide the EASY frame into the slots on the bottom rear of the cistern until the two frames are lined up and flush with each other. The holes on the bottom and rear of the...

  • Page 4: Assembling The Baseplate

    B BANO ® Designed for care ASSEMBLING THE BASEPLATE 1. Insert the two countersunk M12 bolts through the bottom of the baseplate, so that the heads of the bolts are in full contact with the inside of he countersunk holes on the underside.

  • Page 5: Final Assembly

    B BANO ® Designed for care FINAL ASSEMBLY 1. The cistern and frame can now be lowered onto the baseplate, over the upright bolts. The smaller hole in the rear crossbar should be lied up with the holes/slot in the rear of the frame 2.
  • Page 6 B BANO ® Designed for care LEVELLING THE CISTERN In cases where the EASY system is going to be used on an unlevel surface, it may be necessary to level the cistern on the baseplate to ensure that the BVT remains in the correct orientation for use comfortably.
