AIR FRYER GRILL
Item codes: M366
Instructions for Use
Please read and retain these instructions for future reference
Power Details:
Voltage details: 220 – 240V
Frequency details: 50/60Hz
Wattage details: 1800W
Capacity: Crisper Basket- 3.8L
Use: This item needs two hands for safe use.
Please read this instruction manual thoroughly before starting and ensure you are familiar with the
operation of your Air Fryer Grill.
User instructions:
Key:
Indicates to read and review instructions to understand operation and use of product.
Indicates the presence of a hazard that can cause personal injury, death or substantial property damage if
the warning included with this symbol is ignored.
Take care to avoid contact with hot surface. Always use hand protection to avoid burns.
For indoor and household use only.
Product Structure Diagram:
1. Handle
2. Upper housing panel
3. Crisper Basket
4. Cooking Pot
5. Protective Mesh
6. Grill Grate
7. Top Cover Decorating Parts
8. Upper Housing
9. Top Cover (Hood)
10. Air Outlet
11. Supply Cord
12. Digital Touch Screen Display
13. Smart Temperature Sensor
14. Sensor Storage Box Cover
15. "START/STOP" Button
16. Cooking Presets- 12 Menus
17. "PREHEAT" Button
v001: 12/01/24
Cooking Pot- 4.5L
HOUSEHOLD USE ONLY
READ ALL INSTRUCTIONS BEFORE USE
Advertisement
Table of Contents
Related Manuals for Basilico M366
Summary of Contents for Basilico M366
- Page 1 AIR FRYER GRILL Item codes: M366 Instructions for Use v001: 12/01/24 Please read and retain these instructions for future reference Power Details: Voltage details: 220 – 240V Frequency details: 50/60Hz Wattage details: 1800W Capacity: Crisper Basket- 3.8L Cooking Pot- 4.5L Use: This item needs two hands for safe use.
-
Page 2: Function Buttons
18. Temperature Increase Button 19. Temperature Decrease Button 20. Temperature Display Digital Tube 21. Time Display 22. Time Increase Button 23. Time Decrease Button 24. “DIY” Button 25. “POWER” Button 26. Preset Mode selection Button. FUNCTION BUTTONS In total 12 preset modes (menus). They are fries, roasted chicken, steak, chicken wing, pizza, fish, prawn, baking, kebab, vegetable, nut (dried fruit), defrost. - Page 3 Remove the protective mesh for cleaning after every use. Once the protective mesh has cooled completely, remove it by pushing the upper left tab toward the back of the top cover. This will release the protective mesh, then you can remove it. Installing the protective mesh To install, insert the protective mesh so the grooves on the protective ring match those of the fixed heat shield ring notch on the right.
- Page 4 On the digital display the first 3 digits show the chosen menu default temperature, last 4 digits show ---- (Refer to below picture). After preheat completed, preheat light will go off. The buzzer will beep 3 short sounds bi-bi-bi. It is a reminder to add food. “Add Food” will be showed in the display. (Refer to below picture). Open the cover, put food inside, close it.
-
Page 5: Main Principle
SMART TEMPERATURE SENSOR: Main Principle： It is suggested to use this accessory while cooking large pieces of meat, for example, whole chicken, fish or steak. Insert the smart temperature sensor into the food, it can detect the CURRENT TEMP of the food. - Page 6 You can adjust the menu cooking temperature or use the default temperature. Press DIY button, the “TARGET TEMP” and “CURRENT TEMP” button will illuminate. The first 3 digits of the digital tube display the set temperature value (TARGET TEMP), and the last 4 digits display the CURRENT TEMP inside the food.
- Page 7 After CURRENT TEMP reaches the TARGET TEMP, the unit will stop working. The buzzer will beep 5 short sounds bi-bi-bi-bi-bi. “End” appear on the display. The unit will goes to stand-by status in 5 seconds. If no further operation, the unit will turn off in 15 seconds. Air Crisp Function Place cooking pot in the unit with the indent on the pot aligned with the bump on the main unit.
- Page 8 180-230 1-30 After the timer with Minutes count down preheat Steak passed 2/3. function After the timer with Chicken 1-60 count down preheat 125-200 Minutes passed 2/3. function Wing Pizza 125-200 1-60 After the timer with Minutes count down preheat passed 2/3.
-
Page 9: Grill Function
If no need preheating, you can skip it by pressing the PREHEAT button to cancel. Then, you can put in food to cook directly. Grill Function Place cooking pot in the unit with the indent on the pot aligned with the bump on the main unit. Then place the grill grate in the pot with handles facing up. - Page 10 WHEN USING ELECTRICAL APPLIANCES, BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE FOLLOWED: • READ ALL INSTRUCTIONS BEFORE USE. • FOR DOMESTIC USE ONLY. • BEFORE USE, CHECK THOROUGHLY FOR ANY DEFECTS AND DO NOT USE IF DEFECTS ARE FOUND. TAKE CARE NOT TO DROP THE APPLIANCE AS HEAVY IMPACTS MAY CAUSE INTERNAL DAMAGE. •...
- Page 11 • This appliance can be used by persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. •...
-
Page 12: Customer Services
• To deep clean the temperature sensor, soak the stainless-steel tip and plastic grip in warm, soapy water. DO NOT immerse the cord or jack in water or any other liquid. The temperature sensor is hand-wash only. NOTE: NEVER use abrasive tools or cleaners. NEVER immerse the main unit in water or any other liquid. •...
