Introduction ................................................................................................................................................................. 1
Parts (Package Contents) .......................................................................................................................................... 1
System Operation ....................................................................................................................................................... 2
Transmitters................................................................................................................................................................ 3
Installation and Interconnection .................................................................................................................................. 4
Operating the System ................................................................................................................................................. 5
Features and Specifications ....................................................................................................................................... 6
Troubleshooting .......................................................................................................................................................... 7
Cleaning ..................................................................................................................................................................... 8
Introduction
Thank you for choosing our wireless system! This wireless microphone (mic) system is a dual-
Channel model; standard rack-mounting design; central control LCD display; independent IR
Sync buttons for each frequency channel; pre-set frequency groups; avoidance of frequency
incompatibilities; and ease of operation. It employs new PLL frequency-synthesis double-
conversion technology, provides low spurious emissions, a sound squelch code locked
function, and strong anti-interference properties. These highly cost-effective models yield nice
sound quality and performance, clear voice, and stable audio carrier signal transmission over
a 60 m clear line of sight.
Using This Manual
This booklet provides instructions for operating the wireless system. It includes a description
of its features, a quick user controls guide, a step-by-step guide to operations for each item,
system specifications, and a troubleshooting guide.
Parts (Package Contents)
•
Handheld microphone with transmitter (1)
•
Headset microphone (1)
•
Lapel microphone (1)
•
Body-worn transmitter (1)
•
DC power pack (100-240 VAC in, nominally 14 V DC500 mA DC out) (1)
•
Receiver (1)
•
Cable (1)
•
Non-rechargeable AA 1.5 V batteries (4)
•
User manual (1)
Be sure to keep original packaging in case re-shipping is needed.
Contents
1 |
P a g e
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for swamp ICM IU-2079 B10-H10
-
Page 1: Table Of Contents
Contents Introduction ................................. 1 Parts (Package Contents) ............................1 System Operation ............................... 2 Transmitters................................3 Installation and Interconnection ..........................4 Operating the System ..............................5 Features and Specifications ............................6 Troubleshooting ................................7 Cleaning ..................................8 Introduction Thank you for choosing our wireless system! This wireless microphone (mic) system is a dual- Channel model;... -
Page 2: System Operation
System Operation Receiver Front Panel – Power button: Press to turn the receiver ON/OFF. – IR transmitting window. – ‘Channel A’ operation button: SYNC – ‘Channel A’ radio frequency (“RF”) / Audio frequency (“AF”) – ‘Channel A’ volume control: Rotate to control the volume level. –... -
Page 3: Transmitters
Transmitters Wireless Hand-held Microphone with Integrated Transmitter – The cap of the mic – Handle of the wireless mic – LCD screen – IR lens – Power switch – Battery compartment (open in order to insert batteries) – Antenna Body-pack Transmitter –... -
Page 4: Installation And Interconnection
Installation and Interconnection ‘MIX OUT’ (unbalanced) socket DC power CH2 antenna CH2 & CH1 XLR CH1 antenna pack socket socket (balanced) O/Ps 1) Connect to 12-18 V 350 mA DC power pack. 2) Connect one end of the cable (¼” mono microphone jack) to the receiver’s ‘MIX OUT’ socket and the other end to a mixer, karaoke player, recorder or power amplifier’s ¼”... -
Page 5: Setting Up The System
Setting up the System ressing the power switch for 2-3 seconds will turn the receiver on. Likewise, pressing the 1. P microphone’s or body-pack transmitter’s power button for 2-3 seconds will turn that item on (the receiver’s RF indicator lamp should then light up). 2. -
Page 6: Features And Specifications
Features and Specifications SELECTABLE RECEIVER FREQUENCIES Freq Freq Freq 533.900 524.250 530.100 521.600 * 524.800 530.800 522.000 525.550 531.650 522.900 526.550 532.050 528.000 527.700 533.050 535.100 528.100 534.850 539.000 529.050 535.750 540.500 540.400 523.000 * 542.900 535.250 520.800 543.950 536.750 521.250 536.350 * 542.900... - Page 7 Features • UHF band, PLL circuit, stable character, low spurious emissions. • 10 selectable groups of 10 pre-set compatible frequencies. • Up to 50 MHz of tuneable transmit/receive bandwidth for all 10 channels (depending on region of the world?) • Rack mounting kit conforming to International EIA standard.
-
Page 8: Troubleshooting
Troubleshooting If you are having problems operating or suspect something is wrong with the unit, please check the troubleshoot list below to see if the issue is a result of incorrect set-up or operation rather than equipment malfunction. Problem Possible cause Solution •... -
Page 9: Cleaning
Cleaning and Protecting the Device CAUTION! Make sure the power is disconnected before cleaning or repairing the unit. Do not allow the device to touch any liquid. Liquid may damage the electronic components. It may soak into the shell and result in the short-circuit of electronic components.
