T.BONE Tour Guide Micro TX Quick Start Manual

Quick start guide
This document contains important information on the safe use of the product. Read and follow the safety instructions and all other instructions. Keep the document for
future reference. If you pass the product on to others, please include this document.
Contents are subject to change. Please refer to the latest version of the documentation, which is ready for download under www.thomann.de.
Safety instructions
Intended use
This device is designed to convert acoustic signals into radio signals and transmit
them. Any other use or use under other operating conditions is considered to be
improper and may result in personal injury or property damage. No liability will be
assumed for damage resulting from improper use. This product may be used only
by persons with sufficient physical, sensory, and intellectual abilities and having
corresponding knowledge and experience. Other persons may use this device only
if they are supervised or instructed by a person who is responsible for their safety.
Risk of injury and choking hazard for children!
Children can suffocate on packaging material and small parts. Children
can injure themselves when handling the product. Never allow children
to play with the packaging material and the device. Always store packag-
ing material out of the reach of babies and small children. Always dispose
of packaging material properly when it is not in use. Never allow children
to use the device without supervision. Keep small parts away from children
and make sure that the device does not shed any small parts (such as
knobs) that children could play with.
Possible hearing damage due to high volumes on headphones or earphones!
The use of headphones or earphones at high volumes or for an extended
period of time may result in permanent hearing impairment. Set the vol-
ume of your audio device to a medium value. Do not use the headphones
or earphones for more than about an hour a day.
Features
Tour Guide Micro TX (item no. 573015)
UHF tour guide transmitter, designed as a bodypack
ƒ
42 transmission channels available
ƒ
3.5 mm jack socket
ƒ
Built-in rechargeable Li-polymer battery (3.7 V
ƒ
Range: 50 m
ƒ
Micro-USB charging port
ƒ
16 hours of operation per battery charge
ƒ
Built-in microphone
ƒ
Charging contacts for optional charging station (item no. 573020)
ƒ
Lanyard included
ƒ
Technical specifications
Tour Guide Micro TX (item no. 573015)
Number of systems that
can be operated in parallel:
Charging connection:
Audio input:
Audio frequency response:
Audio sampling rate:
Radio frequency range:
Dynamic range:
Signal-to-noise ratio:
Total harmonic distortion:
Carrier frequency range:
Max. transmission power:
Modulation:
Charging source:
Battery:
Charging time:
Operating time:
Dimensions (W × H × D):
Weight:
Temperature range:
Relative humidity
1,300 mAh)
16 (distance TX to TX > 1 m)
Micro-USB, charging contacts
3.5 mm jack socket,
unbalanced
300 Hz - 3.4 kHz
8 kHz, 16 bit
823 MHz – 832 MHz, 863 MHz – 865 MHz
> 80 dB
> 70 dB
< 4.5%
UHF 300 Hz – 3.4 kHz
10 mW
GFSK
5 V Micro-USB
Li-polymer (3.7 V , 1,300 mAh)
5 hours
16 hours
70 mm × 100 mm × 25 mm
50 g
0 °C...40 °C
20%...80% (non-condensing)
Tour Guide Micro TX
Tour Guide Micro RX
Operating location
Never use this product:
in direct sunlight
ƒ
in conditions of extreme temperature or humidity
ƒ
in extremely dusty or dirty places
ƒ
in locations where the device may get wet
ƒ
in the vicinity of magnetic fields
ƒ
General handling
To prevent damage, never exert force while operating the device.
ƒ
Never immerse the device in water. Wipe only with a clean and dry cloth. Do not
ƒ
use liquid cleaners such as benzene, thinners or flammable cleaning agents
Keep the device away from impurities!
Keep the device away containers with liquid. Should liquid enter the device, this
could lead to its destruction or fire. Ensure that no metallic parts enter the device.
Interference with other electrical devices
Using the device near radios or TV sets may cause interference. In that case, in-
crease the distance between the devices.
Notes on radio transmission
This equipment uses a frequency range that is free of charge and registration
within the European Union (EU). For more information, please visit: www.thomann.
de. During operation, make sure that transmitter and receiver are set to the same
channel. Never set more than one transmitter to the same channel. Make sure
that no metal objects are located between transmitter and receiver. Avoid interfer-
ence by other radio and in-ear systems.
Tour Guide Micro RX (item no. 573009)
UHF tour guide receiver, designed as on-ear headphones
ƒ
Built-in rechargeable Li-polymer battery (3.7 V
ƒ
Range: 50 m
ƒ
8 hours of operation per battery charge
ƒ
Charging contacts for charging station (item no. 573020)
ƒ
Tour Guide Micro RX (item no. 573009)
Number of systems that
can be operated in parallel:
Charging connection:
Audio frequency response:
Audio sampling rate:
Radio frequency range:
Dynamic range:
Signal-to-noise ratio:
Total harmonic distortion:
Carrier frequency range:
Max. transmission power:
Modulation:
Battery:
Charging time:
Operating time:
Dimensions (W × H × D):
Weight:
Temperature range:
Relative humidity
EN
200 mAh)
16 (distance TX to TX > 1 m)
Charging contacts
300 Hz - 3.4 kHz
8 kHz, 16 bit
823 MHz – 832 MHz, 863 MHz – 865 MHz
> 80 dB
> 70 dB
< 4.5%
UHF 300 Hz – 3.4 kHz
10 mW
GFSK
Li-polymer (3.7 V , 200 mAh)
2 hours
8 hours
27 mm × 70 mm × 25 mm
20 g
0 °C...40 °C
20%...80% (non-condensing)
