Cobra Jump Starter 1000A Quick Start Manual

Charging Your Devices
USB-A Charging
USB-C Charging
■■
I
Re-Charging Your Jump Starter 1 000A
OPTION A
To USB-C Fast Charge
D
Input/Output
�--------
□ �
WIIW�
OPTION B
To USB-C Fast Charge
Input/Output
OPTION C
To USB-C Fast Charge
Input/Output
In-Car Jump Starting FAQ
How do I know if my battery is charging?
When the 12V jumper cables are plugged into the Jump Starter 1 OOOA and vehicle's 12V
accessory port, the LCD screen will show a flashing 5-bar graph and the word 'Output'. As your
battery charges the flashing bars will begin to turn solid until the vehicle is ready to start, at
which point a 'Ready' message will appear on the screen and you are ready to start your vehicle.
How long will it take to charge?
In-car jump starting will take longer than jump starting with a direct-to-battery connection, up to
15 minutes total. If your vehicle does not start with the in-car method, try to jump start with the
direct-to-battery method.
What if I don't see the charging bars?
If the Jump Starter 1 OOOA does not have enough charge to jump start from within the car, the
current battery percentage will flash and a caution image will appear. In that case you will need
to jump start your vehicle by using the direct-to-battery method.
C
Tri-Color Status LED:
The Status LED will illuminate and the color will change if the following
conditions are present:
LED CONDITION
No LED Connection not detected or the Jump Starter 1 OOOA battery is
depleted. Check the battery charge level and verify the
connection of the jumper cable to the Jump Starter 1 OOOA.
Solid Red Reverse polarity connection. Reverse the clamps.
Flashing Red Over-current protection. Wait for 30 seconds and then
retry connection.
Solid Yellow Solid contact established and charging for jump start.
Flashing Yellow Either the cables are not properly connected or the Jump
Starter 1 OOOA is too hot. Remove cable and retry connection.
Red and Green Safety feature to prevent the battery from overheating from too
Flashing Alternatingly many jump start attempts in a short period of time.
Remove cable and wait a few minutes.
Solid Green Ready to jump start your vehicle.
adapter not included) NOTE: When connected to your vehicle's battery and charging, the Jump Starter 1 OOOA
make a clicking sound every 5 seconds. This is part of normal operation.
S,cob_ r a·
Jump Starter 1 000A
Lithium-Ion Jump Starter & Power Bank
With Fast Charge USB
FULLY CHARGE FIRST!
For optimal performance, charge
your Cobra Jump Starter prior to
first use and every 12 months.
QUICK START GUIDE
will
-■
