  • Page 1 Technical Support and E-Warranty Certificate www.vevor.com/support WIND TURBINE GENERATOR MODEL: FA200W We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represents an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and does not necessarily mean to cover all categories of tools offered by us.
  • Page 2 This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if there are any technology or software updates on our product.

  • Page 3: Correct Disposal

    Warning-To reduce the risk of injury, user must read instructions manual carefully. CORRECT DISPOSAL This product is subject to the provision of European Directive 2012/19/EC. The symbol showing a wheelie bin crossed through indicates that the product requires separate refuse collection in the European Union.

  • Page 4: Fcc Information

    FCC Information CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment! This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) This product may cause harmful interference.
  • Page 5 harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this product does cause harmful interference to radio or television reception,which can be determined by turning the product off and on, the user is encouraged to try to correct the interference by one or more of the following measures.
  • Page 6 3.WIND TURBINE ASSEMBLY PROCEDURES  Wind turbine and tower connection: wind turbine sets on top of towers or poles, such as Figure 1: A special connection sleeve for the top of a tower or pole Figure 1 3.1 Unpacking Check According to the following table to check the box interior parts are complete, - 5 -...
  • Page 7 in order to ensure the normal assembly. Item Description Number Wind Generator Wind Blades Flange Bolts Casing Install Manual 3.2 Wind Turbine Generator Install Steps 1) The tower will be tilted (inclined angle to facilitate the installation of wind turbines is appropriate); the two cables from the bottom of the tower through the top hole out;...
  • Page 8 Figure5 Figure4 Figure2 Figure3 3) wind blades is mounted on the flange,pay attention to the word with a face outward (as shown in Figure 6), with M6*20 (3) Hexagon screw and M6 self-locking nut will be connected to the flange,self-locking nut fixed in the flange groove with a 5mm hex wrench locking tightly (shown in Figure 7), in this way, the other two wind blades fixed on the flange, adjust the distance between the two tips within 5.0mm and then tighten the bolts to...
  • Page 9 Note: Literal face outward. Figure6 Figure7 Figure8 4) Remove the M16 nut from the wind turbine generator (made finish in step 3) and connect on the rotor shaft of wind turbine generator, and then install the nut in the groove of the flange, with the 8mm hex wrench into the hexagonal hole in the middle of the rotor shaft and turn the rotor shaft counter clockwise to Lock it, at least 3 teeth out;...

  • Page 10: Maintenance

    Figure 9 Figure10 6) Tower installation fixed,when install tower,please ensure that the tower is perpendicular to the horizontal plane,deviation should be 0.5 degrees or less; 7) Charge controller installation: charge controller connected to the battery first,the battery connection terminal “+”“-” connect to the charge controller “+” “-”o n the right. 8) Connect the wire line.

  • Page 11: Trouble Clearing

    blades.The blades are balanced as sets.  Check the blade bolts and the hub but for tightness.  Check nosecone for cracks and proper fit.  Wash off any built-up dirt or debris from the blades.  Check all electrical connections to make sure they are tight and free from corrosion.
  • Page 12 1. Tipped fan bracket, check all parts Exclusion 2. Replace bearings Method 3. Examination to exclude 1. Generator stator and rotor friction Failure 2. Stator winding short circuit or output Causes short circuit Significantl 3. Switch is in the down position controller y reduced 1.
  • Page 13 But no DC Exclusion 1. Replace the fuse output Method 2. Identify the reasons, turn circuit 1. Generator output voltage is too low Battery Failure 2. Poor conductivity battery posts output Causes 3. Battery failure capacity is Exclusion 1. Excluded by the above examinations insufficient Method 2.
