SERVICE
MANUAL
Air Purifier
KPU-700.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KPU-700.1 and is the answer not in the manual?

Questions and answers

Related Manuals for Kaysun KPU-700.1

Summary of Contents for Kaysun KPU-700.1

  • Page 1 SERVICE MANUAL Air Purifier KPU-700.1...

  • Page 2: Air Purifier

    Air Purifier Faults Handling ....1.2 Guidance for product disassembly...
  • Page 4 Main machine User manual Casters Protective bag • Main machine (1) • Casters (4) • Filter screen (1 s et/ 2pcs) • User manual (1) • Protective bag (1) (Installed i n the main machine)
  • Page 5 Gaseous pollutant sensor PM2.5 sensor Air outlet grill Operation Handle Display screen Casters HEPA Filter Pre-Filter Air inlet grill...

  • Page 6: Control Panel

    Control panel Net ion button SPEED button Mode button On/Standby button Press to turn on/off the net Lo w, m edium a nd Automatic mode, sleep ion Long p ress f or 3s the high (optional) mode and high-speed Press to t urn o n/ Standby of the air mode (optional) filter;...
  • Page 8 Assembly 1. T ake down the air inlet grill. procedures Grasp t he c lasp position and pull outward to remove the air inlet grill. 2. T ake out the Pre-Filter. Press down and pull the U-shaped snap joint, and take out the Pre-Filter. 3.
  • Page 9 5. A ssemble the HEPA Filter. 6. A ssemble the Pre-Filter. Align the slot position at the bottom, and click into the upper U-shaped snap joint. 7. Assemble the air inlet grill. Align with the slot position at the bottom, press both sides of the upper part of the air inlet grill, and clasp the air inlet grill.
  • Page 10 Install the caster Tilt the machine body to install the casters and press into 4 casters with force in turn at the bottom Then power on for operation.
  • Page 11 Trial operation 1. Preparation Power on for the first time, the display panel flickers for 1s, and then the screen is turned off. The whole appliance is on standby state. Child Lock （Press 3s ） DIMMER PM2.5 Net ion Auto Sleep Turbo SPEED...
  • Page 12 Note 1. This appliance is provided with a disassembly protection function; the appliance can only operate normally after the air inlet grill and air outlet grill are assembled properly. 2. With the power on, each time after the machine starts, it enters the working mode before the standby state.
  • Page 14 1. When the last bar of the progress bar turns red and the cleaning indicator light is on, it prompts Cleaning of the that the Pre-Filter needs to be cleaned. filter components Clean Outlet Pre-Filter Grea t Good Poor Gaseous Pollutant Grea t Good Poor...
  • Page 15 6. Assemble the Pre-Filter. 7. Plug in the appliance, and start it. 8. Long press the net ion button for 3s, the cleaning indictor light is off, and the Pre-Filter is restored. Net ion (Sterilization) Child Lock （Press 3s） DIMMER PM2.5N Net ion Auto...
  • Page 16 Cleaning of the Wipe the body with a soft towel. machine body Main machine Open the air inlet grill, clean dust with a vacuum cleaner, and wipe it with a cloth. Air inlet grill Open the air outlet grill, clean dust with a vacuum cleaner, and wipe it with a cloth. Air outlet grill...
  • Page 17 Replacement 1. Filter model: FC-70H-1B (The unit needs 2 filters) of the filter components 2. When the last bar of the progress bar turns red and the replacement indicator light is on, it prompts that the HEPA Filter needs to be replaced. Change Outlet HEPA Filter...
  • Page 19 Faults Handling ....1.2 Guidance for product disassembly...
  • Page 20 Faults Handling Faults Handling Before inviting someone to inspect or repair, please check the following items. Faults phenomena Treatment The display screen shows "E3" The speed is out of control: contact the after-sales The display screen shows "EO" Main c o ntrol EEPROM har dware failure, and The display screen shows "E1"T he f ault is b ecause o f disassembly protection, and the air inlet and outlet grilles a re n ot...
  • Page 21 Guidance for product disassembly 1. Whole body 3. Take down the air outlet grille 2. Take down the air outlet grille The air outlet grill is an active removable part, take it out by hand The air inlet grill is an active removable part, take it out by hand 4.
  • Page 22 11. Pry the edges of the front shell on the right 12. Pry the upper part of the front shell 10. Take out the lamp cover (releasable) (releasable) to take down the front shell side and left side (releasable) Orange Enlarged indicates the structure diagram...
  • Page 23 21. Take out the partition and photochemical 19. Take out the odor sensor 20. Take out the negative ion generator plasma sterilization components Unscrew one screw as Unscrew two screws Unscrew one screw as shown in the red circle as shown in the red shown in the red circle to take the negative ion circle to take out the...
  • Page 24 28. Take out the wind rotor 29. Take out the fan 30. Take out the components of the power board Unscrew three screws, A socket wrench or and then take out the other tools are used to motor holder and motor. unscrew the nuts and take out the wind rotor.

  • Page 25: Exploded View

    Exploded View I. 3D Effect Picture of Explosion...
  • Page 26 II. 2D Picture of Explosion...

  • Page 28: Fault Disposal

    Fault disposal Fault code Fault description Remarks Solution Clear the fault by turning off 1. On/off operation; 2. Replace the again after turning on; power filter, 3. Replace the circuit board Write SN code error on, and then check it again assembly The fan speed is beyond The faults are displayed all...

  • Page 29: Electronic Control Description

    Electronic control description Material Serial Material number Material name Quantity Picture drawing No. 17157100001395 Function PCB RFID001A KJ40FE. Inverter control board 17257100000331 NY(POWER). subassembly JH.NX.DY.03A 17401202007448 Power cord DYX-BSI-06 Negative Ion 17456100001041 FLZ-101A Generator 17400511000484 PTC reed GHG-07 17400511000684 PTC reed GHG-09 CGQ-TS- Dust sensor...
  • Page 30 KJ20FE- NH2. JH. NX. 17157100000082 PFC Module PM25-03 Purifier Main Control Panel 17157100001217 KJKZ001 Board Purifier Display 17157100001435 KJXS001A Panel Assembly Purifier Display 17157100001436 KJAJ001A Panel Assembly Main control Display panel board interface; interface; Black Black five-pin six-pin terminal terminal Guidance for wiring of the display panel...
  • Page 31 Motor interface; Power cord interface; Red two-pin White big six-pin terminal terminal (classified by the terminal color) (classified by the terminal size) Guidance for wiring of the power panel components of the air purifier Main control board interface; Negative ion generator interface; White small six-pin terminal White two-pin terminal (classified by the (classified by the terminal size)
  • Page 32 Reed pipe Plasmacluster Main control keyboard WIFI board RFID Filter recognition Odor sensor PM2.5 sensor x 2 display board Power Board Negative ion...
