Summary of Contents for AGT INDUSTRIAL AGT-TAS74
- Page 1 AGT INDUSTRIAL PRODUCT MANUAL 3 Point Linkage Tractor Rototiller Model:AGT-TAS74/81 Ver.1.1.3...
-
Page 2: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS 2/17 TO THE OWNERS 3/17 SAFETY PRECAUTIONS 4/17 ROTOTILLER ASSEMBLES 7/17 DRIVE SHAFT ASSEMBLES 13/17 OPERATION INSTRUCTIONS 15/17 NOTES 17/17... -
Page 3: To The Owners
TO THE OWNERS GENERAL COMMENTS Congratulations for having this Tractor Rototiller ! Your Tractor Rototiller was carefully designed and manufactured to give you years of dependable service. Your Tractor Rototiller will require some minor maintenance to keep it in top working condition. Please observe all safety precautions and maintenance procedures as described in this manual. -
Page 4: Safety Precautions
SAFETY PRECAUTIONS BEFORE OPERATION 1. The operator must read the operation manual carefully before installation, operation or maintenance. Improper operation will cause the machine damage or the operator death. 2. Read all the safe signs and safe declarations. Follow all the professional safe terms, local laws or the professional directions. -
Page 5: Operator Safety
SAFETY PRECAUTIONS Operator Safety ►Wear protective clothing and equipment appropriate for the job. Clothing should be snug fitting without fringes and pull strings to avoid entanglement with moving parts. ►Prolonged exposure to loud noise can cause hearing impairment or hearing loss. Wear suitable hearing protection such as earmuffs or earplugs. ►Operating equipment safely requires the operators all attention, Avoid wearing radio headphones while operating machinery. -
Page 6: Transportation And Storing
SAFETY PRECAUTIONS Wear Protective Equipment ►Escaping fluid under pressure can penetrate the skin causing serious injury. ►Avoid the hazard by relieving pressure before disconnecting hydraulic lines or performing work on the system. ►Make sure all hydraulic fluid connections are tight and all hydraulic hoses and lines are in good condition before applying pressure to the system. -
Page 7: Rototiller Assembles
ROTOTILLER ASSEMBLES PART NO. PART DESCRIPTION QTYS NOTE Bolt M10*25 GB/T5783-2000 Bolt M0*25 GB/T5783-2000 Bolt M10*25 GB/T5783-2000 Frame Weldment TS-81-01-01-00 Frame Weldment TS-74-01-01-00 Frame Weldment TS-66-01-01-00 Frame Weldment TS-58-01-01-00 Frame Weldment TS-50-01-01-00 split pin TS-66-01-02-03... - Page 8 ROTOTILLER ASSEMBLES PART NO. PART DESCRIPTION QTYS NOTE Lower Hitch Block TS-66-01-02-02 Lower Hitch Connecting Seat Panel TS-81.01.02. 01-02 Lower suspension connecting plate Weldment TS-81.01.02. 01 Lower suspension connecting plate Weldment TS-50/58/66/74 V Bolt TS-66-01-02-01 Bolt Ml2*35 GB/T5783-2000 Bolt Ml2*35 GB/T5783-2000 Bolt M2*30 GB/T5783-2000...
- Page 9 ROTOTILLER ASSEMBLES PART NO. PART DESCRIPTION QTYS NOTE Gearbox Support Tube TS-74-04-00 Gearbox Support Tube TS-66-04-00 Gearbox Support Tube TS-50/58-04-00 Floating Seal 72*35*10 HG4-692-67 Snap Ring 072 GB/T893. 1-1986 Bearing 6207 GB/T276-1994 Pinion Gear TS-66-02-05 Bolt M8*16 GB/T5783-2000 Gearbox Oil Plug (Dip Stick) Housing - Gearbox TS-66-02-01...
- Page 10 ROTOTILLER ASSEMBLES PART NO. PART DESCRIPTION QTYS NOTE Bolt Ml0*30 GB/T5783-2000 Bolt Ml2*25 GB/T5783-2000 Side Panel - Left TS-66-01-04-00 Gasket - Drive shaft （ 151*136*0. 5 ） TS-66-02-07 Drive Shaft Tube Housing TS-81-02-01-00 Drive Shaft Tube Housing TS-74-02-01-00 Drive Shaft Tube Housing TS-66-02-01-00 Drive Shaft Tube Housing TS-58-02-01-00...
- Page 11 ROTOTILLER ASSEMBLES PART NO. PART DESCRIPTION QTYS NOTE Rotor Shield-Left TS-66-08-09 Bolt M12*35 GB/T5783-2000 Bolt M12*30 GB/T5783-2000 Bolt M2*1. 25*35 GB/T5786-2000 Tiller Blade 2-012.4 pitch 42. 4 Rotor Weldment TS-81-09-01-01-00 Rotor Weldment TS-74-09-01-01-00 Rotor Weldment TS-66-09-01-01-00 Rotor Weldment TS-58-09-01-01-00 Rotor Weldment TS-50-09-01-01-00 Dust Cover-Right TS-66-09-01...
- Page 12 ROTOTILLER ASSEMBLES PART NO. PART DESCRIPTION QTYS NOTE Tailgate TS-74-07-01-00 Tailgate TS-66-07-01-00 Tailgate TS-58-07-01-00 Tailgate TS-50-07-01-00 Tailgate Chain assembly TS-66-07-02-01 Side Panel - Right TS-66-01-01 Gasket 2 (0119*0*95*0. 5) TS-66-09-06 Gasket 1( 150* 108*0. 5) TS-66-09-05 Shim 2 T*.04-02...
-
Page 13: Drive Shaft Assembles
DRIVE SHAFT ASSEMBLES PART NO. PART DESCRIPTION QTYS NOTE 6 Spline Yoke for tractor side Pin Ф13*47 Spring Ф0.9*25 Circlips Ф27 U.joint 27x74.5 Outer tube yoke pin Ф10*65 Triangle Outer tube Outer shield cone Outer shield bearing Outer shield tube Inner shield tube Inner shield bearing Inner shield cone... - Page 14 DRIVE SHAFT ASSEMBLES PART NO. PART DESCRIPTION QTYS NOTE blind flange driven plate Friction disk Bolt M12*70 Washer Ф12 Nylon self-locking nut M12 flange Nylon bushing Clutch Yoke Inner tube Yoke Pin Ф10X60 Triangle Inner tube...
-
Page 15: Operation Instructions
OPERATION INSTRUCTIONS Check the unit before attaching the rotary tiller to the tractor to ensure there is oil in the top and side gear box. See Maintenance section for lubricant specifications. Check the oil grease points before starting operation Oil level: Top gearbox 1 1/2” from the end of the dip stick. When sitting slightly tilted forward, oil should at the bottom of the fill plug on the side gearbox cover. - Page 16 OPERATION INSTRUCTIONS Caution: Slip Clutches may get hot. Do Not Touch. Keep the slip clutch area clear of an material that may catch fire. Slip clutches have adjustable torque settings. The torque setting varies with the different compression of each spring. All the springs should have an equal amount of compression. IMPORTANT: Do not over-tighten the compression nuts as this may impair performance or cause premature wearing of the slip clutch.
