Summary of Contents for Lees B-EYE K10
- Page 1 B EYE K10 USER MANUAL KEEP THIS USER MANUAL FOR FUTURE NEEDS...
-
Page 3: General Guidelines
Thank you for your patronage! We are confident that our excellent products and service can satisfy you. For your own safety, please read this user manual carefully before installing the device. In order to install, operate, and maintain the lighting safety correctly. We suggest that the installation and operation should be done by the verified technician and follow the instruction strictly. -
Page 4: Safety Instructions
turned in the quick lock holes correctly. Operate the device only after having familiarized with its functions. Do not permit operation by persons not qualified for operating the device. Most damages are the result of unprofessional operation. Please use the original packaging if the device is to be transported. For safety reasons, please be aware that all modifications on the device are forbidden. -
Page 5: Cleaning And Maintenance
CAUTION! Never touch the device during operation! The housing may heat up! CAUTION! Never look directly into the light source, As sensitive persons may suffer an epileptic shock. Please be aware that damages caused by manual modifications to be the device are not subject to warranty. -
Page 6: Technical Parameters
TECHNICAL PARAMETERS Power supply AC110-240V 50/60 Hz Power consumption: 480W Light source 19*15W RGBW 4 in1 Tyshine LEDs Individual LED control Average life: 50,000 hrs Color temperature：2500K-8000K Effect Zoom angle: 4-60°; 14000lux@5m@Min angle Wash/Beam/Graphic/Effects function Front lens can rotated infinity With“vortex”and “kaleidoscope”... - Page 7 Fixture Size Photometrics...
-
Page 8: Mounting And Installation
MOUNTING AND INSTALLATION Cautions: For added protection mount the fixtures in areas outside walking paths, seating areas, or in areas were the fixture might be reached by unauthorized personnel. Before mounting the fixture to any surface, make sure that the installation area can hold a minimum point load of 10 times the device’s weight. -
Page 9: Dmx-512 Control Connections
DMX-512 CONTROL CONNECTIONS Connect the provided XLR cable to the female 3-pin XLR output of your controller and the other side to the male 3-pin XLR input of the moving head. You can chain multiple Moving heads be connected together through serial linking. The cable needed should be two core, screened cable with XLR input and output connectors. -
Page 10: Functions Of Buttons
FUNCTIONS OF BUTTONS The function of Reversal of the display is activated automatically when the fixture reversed Confirms the displayed value, or activates the displayed function, or enters the successive menu. Decreases the value displayed (with auto-repetitions) or passes to the next item in the menu. -
Page 11: Menu Function
MENU FUNCTION... - Page 12 LED Drive Board Main Board...
-
Page 13: Channel List
CHANNEL LIST... - Page 17 SHAPE MODE DESCRIPTION CONCEPTS: FOREGROUND AND BACKGROUND The powerful shapes engine embedded in the LiteLEES Big-EYE L10 ROTATION and L10 EASY allows the user to set all the possible parameters relating to the pixels of the light in an organic way, with a distinction between the pixels affected by a selected "image"...
- Page 18 ‘...
-
Page 19: Packing Contents
PACKING CONTENTS REMARK The product has perfect performance and intergrity packing. All users should be strictly comply with the warning and operating instructions as stated. Or we aren’t in charge of any result by misusing. Any damage resulting by misuse is not within the Company’s warranty. Any fault or problem caused by neglecting the manual is also not in the charge of dealers.
