ITRON BirdCAM User Manual

Smart bird feeder ai camera

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

Smart Bird Feeder

AI Camera

USER MANUAL

Table of Contents

Need help?

Do you have a question about the BirdCAM and is the answer not in the manual?

Questions and answers

Summary of Contents for ITRON BirdCAM

Page 1 Smart Bird Feeder AI Camera USER MANUAL...
Page 3: Table Of Contents
Content Packing List Product Appearance Bird Feeder Parts Name Quick Start Set Up the Camera Install Bird Feeder Share the Camera Charge the Camera Indicator Light Status Product Speciﬁcation Firmware Upgrade FCC Warning Content iTron Bird Feeder Camera...
Page 4: Package Includes
Package Includes Feeder Bird Camera Material Tray Antenna Bird Feeder Bracket Fixed Strap Fittings Bag 01 Solar Panel Fitting Bag 02 Page 01 iTron Bird Feeder Camera...
Page 5: Product Appearance
Product Appearance Lens Indicator Light Spotlight Human Body Infrared Sensor Speaker Bracket Screw Hole Power Cord for Rear Shell Charging Fastening Screws Antenna Hole Micro-SD Card Slot Power Button Power Input Reboot Hole Page 02 iTron Bird Feeder Camera...
Page 6: Bird Feeder Parts Name
Bird Feeder Parts Name Solar Panel Bird Camera Bird Feeding Area Bird Stand Antenna Power Cord for Charging Bird Feeder Bracket Page 03 iTron Bird Feeder Camera...
Page 7: Quick Start
Android and iOS App. For your best experience, please scan the QR code below APP Licence with your mobile phone, install the app, and 120719 follow the instruction to complete the user registration. SCAN ME Page 04 iTron Bird Feeder Camera...
Page 8 02. Add the Device Sign in to the App, connect to Wi-Fi and add the device according to the prompts (please bring the device close to the router when conﬁguring). Page 05 iTron Bird Feeder Camera...
Page 9: Set Up The Camera
Set-up the Camera Click the "Add Camera Now" in the App and enter the Wi-Fi network name and password that you want the camera to connect. Page 06 iTron Bird Feeder Camera...
Page 10 Wi-Fi with stronger wall penetration capability and does not support Wi-Fi for enterprise-level authentication currently. Please ensure that the entered Wi-Fi meets the requirements. After completion, click "Continue" to generate the QR code for pairing the camera. Page 07 iTron Bird Feeder Camera...
Page 11 Power Button Take the lens of the camera facing the QR code generated on iTronCAM about 20 cm (7 inches) until you hear a "Ding" sound. About 7 inches (20cm) Page 08 iTron Bird Feeder Camera...
Page 12 After a while, the camera will give out a prompt sound of a successful connection. At this moment, please set the name for the device on the App and select the location you want to place the device. Click "Continue" to complete the pairing. Page 09 iTron Bird Feeder Camera...
Page 13 Please ensure that the network connection is normal, and try to temporarily turn off the ﬁrewall to connect again. Page 10 iTron Bird Feeder Camera...
Page 14: Install Bird Feeder
Wi-Fi network. Adjust the angle of the camera to cover as much of the bird-watching stand as possible. Recommended Height About 6 Feet Page 11 iTron Bird Feeder Camera...
Page 15 B) Install the tray: Clamp the material tray to the bottom of the main body of the equipment, put in 3 screws and tighten it with a cross screwdriver. Page 12 iTron Bird Feeder Camera...
Page 16 Screw the expansion nut into the holes on the wall, and then connect the bracket to the expansion nut with screws to complete the ﬁxing. Page 13 iTron Bird Feeder Camera...
Page 17 01. Fix the bracket on the wall. 02. Install the solar panel on the bracket and lock it with a nut. 03. Adjust the angle of the solar panel so that it can receive the most sunlight. Page 14 iTron Bird Feeder Camera...
Page 18: Share The Camera
Other members can only view the live or playbacks of the device. 01) Find the camera you want to share on the App homepage or camera setting page. Click the share button and enter the sharing page. Page 15 iTron Bird Feeder Camera...
Page 19 02) Click "Invite", and a QR code will be generated for sharing. 03) For the members you need to share, ﬁnd "Add Friend's Camera" on the "User" page to enter the scanning page. Page 16 iTron Bird Feeder Camera...
Page 20: Charge The Camera
During charging, the camera's indicator light is solid yellow, and when the camera is fully charged, the indicator light will turn into solid green. It will take 14 hours to fully charge the camera. Page 17 iTron Bird Feeder Camera...
Page 21: Indicator Light Status
Field of View (H145°; V85°; D185°) Image Resolution Max. 1920x1080 Pixels Video Bit Rate Adaptive Storage Media Cloud Storage, Micro SD Card Battery Capacity 5000 mAh Adapter Requirement DV 5V+-5% / 1.5A Size 220mm x 220mm x 275mm Page 18 iTron Bird Feeder Camera...
Page 22: Firmware Update
(2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modiﬁcations not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Page 19 iTron Bird Feeder Camera...
Page 23 To maintain compliance with FCC’ s RF Exposure guidelines, this equipment should be installed and operated with minimum distance between 20cm the radiator your body: Use only the supplied antenna. Page 20 iTron Bird Feeder Camera...
Page 24: Faq
A: Please use a 2.4GHz wireless network. The device does not support the 5GHz wireless network. Meanwhile, please set the Wi-Fi authentication method to WPA2-PSK or other lower level of security method. A password is required. Page 21 iTron Bird Feeder Camera...
Page 25 A: Long press the power bottom for 3 seconds to restart it. If there is no response, you can remove the rubber plug at the button of the camera. Press the reboot hole with a pointed object to restart the camera. Page 21 iTron Bird Feeder Camera...
