Summary of Contents for Alderon Industries Power Post PRPT-00001
- Page 1 Power Post ™ Pump Connection Center USER GUIDE MODEL NUMBER: PRPT-00001...
-
Page 2: Table Of Contents
Power Post™ - USER GUIDE Contents Introduction ................................. 3 Safety Guidelines ..............................3 Product Included with Alarm ..........................4 Features ................................. 5 Installation .................................. 6 Installing Post ..............................6, 7 Wiring ..................................7, 8 Testing the Alarm ..............................9 General Operation ..............................10 Septic Tank Monitoring ............................ -
Page 3: Introduction
4. DO NOT use this product with or near flammable liquids. 5. DO NOT install this product in locations classified as hazardous or in explosive atmospheres as defined by any applicable electrical safety code. Alderon Industries™ - Leading Edge Control Products | 3... -
Page 4: Product Included With Alarm
Power Post™ for liquid level monitoring. (5) Pump Float Switch The pump float switch is used to control the pump directly. When actuated the pump float switch will pass power to the pump. 4 | Alderon Industries™ - Leading Edge Control Products... -
Page 5: Features
(14) Post - Provides wire routing access to the alarm and protection (7) Sensor Input - One set of sensor terminals are included for the from water intrusion. high level alarm float switch connection which activates the alarm. Alderon Industries™ - Leading Edge Control Products | 5... -
Page 6: Installation
Take the 3-hole rubber grommet (#4) which has slits next to the holes and insert cables, then insert the rubber grommet into the conduit. 5. Place the PVC coupler over the end of the conduit. 6 | Alderon Industries™ - Leading Edge Control Products... -
Page 7: Step 3: Remove Bottom Cover
3) The last pair of terminals (1 and 2) are for the auxiliary contacts. This connection can be used on most digital peripheral alarm monitors or extensions. 4) NEVER leave ground wire(s) exposed, use provided Wago connector for wire termination. Alderon Industries™ - Leading Edge Control Products | 7... - Page 8 STEP 4: BACKFILL Once all steps of the installation and wiring are complete, take the dirt/soil removed and backfill the area you dug for the post and riser. Backfill Area Backfill Area 8 | Alderon Industries™ - Leading Edge Control Products...
-
Page 9: Testing The Alarm
The silence condition will reset when the alarm float switch is deactivated. STEP 4: TEST WEEKLY To ensure the product is functioning properly, test once a week. Alderon Industries™ - Leading Edge Control Products | 9... -
Page 10: General Operation
Power Post™ auxiliary contacts. When the Power Post™ is in an alarm condition, the Versa’larm™ is as well. Power Post™ House to Septic Alarm Septic to Drain Field Float Pump Switch 10 | Alderon Industries™ - Leading Edge Control Products... -
Page 11: Alarm Auxiliary With Auto Dialer
If the alarm is in silence mode for longer than 24 hours, the alarm will reactivate. Power Post™ Auto Dialer House to Septic Septic to Drain Field Alarm Float Pump Switch Alderon Industries™ - Leading Edge Control Products | 11... -
Page 12: Alarm Auxiliary With Versa'larm™ Indoor Alarm And Auto Dialer
The secondary power supply in the Versa’larm™ is used to power the auto dialer. Auto Dialer Power Post™ Versa’larm™ Indoor Alarm House to Septic Septic to Drain Field Alarm Float Pump Switch 12 | Alderon Industries™ - Leading Edge Control Products... -
Page 13: Troubleshooting
The auxiliary contacts are not activating If the alarm is not activated, then the Test the alarm and the auxiliary contacts auxiliary contacts should also be off should work while the alarm is activated Alderon Industries™ - Leading Edge Control Products | 13... -
Page 14: Specifications
Caution: changes / modifi- cations not approved by Alderon Industries could void the user’s authority to operate the equipment. 14 | Alderon Industries™ - Leading Edge Control Products... -
Page 15: Warranty Information
Three-Year Limited Warranty - Standard Products LIMITED WARRANTY: Subject to the conditions of this Three-Year Limited Warranty, Alderon Industries, LLC (“Alderon”) war- rants to the original user or consumer of an Alderon product (the “Product”) that, for a period of three (3) years from the date of manufacture, the Product will be free from defects in materials and workmanship under normal use and service, and provided the Product is installed, operated and maintained in accordance with instructions supplied by Alderon. -
Page 16: Company Information
UG00007_Rev01_PRPT-00001_Power Post | May 8, 2018 10:47 AM Company Location: 151 16th Street South, Hawley, MN 56549 Mailing Address: PO Box 827, Hawley, MN 56549 Main Office Phone: 218.483.3034 Website: alderonind.com General Inquiry Email: info@alderonind.com Submit New Orders: orders@alderonind.com...
