PRODUCT OVERVIEW
Monitrol is a turn-key fluid control system including a globe
style control valve, a variety of BUILT IN SENSORS FOR FLOW,
PRESSURE AND TEMPERATURE, a High Precision Electric
Actuator, along with control logic and an easy to use TOUCH
SCREEN INTERFACE. Monitrol can manage up to three variables
(sensors), simultaneously with its control logic. FLEXIBILITY allows
the control logic in Monitrol to be bypassed if that is desired. A
Building Management System can still maintain all control and
just make use of the sensor information if that is desired. A full
range of I/O signals, feedback and communications including
modbus, ethernet & wifi are available.
FLOW REGULATOR
There are two distinctly different versions with differing
technologies. One serves as a very accurate flow metering flow
control valve. The other provides reasonably accurate information
about flow to a Building Management System (BMS) for monitoring
load control decision making.
MAG-FLOW VALVE - This version of the product has a Magnetic
Flow Meter and flow straightening tube as integral parts of the
Monitrol assembly. Flow control accuracy is specified at ±0.5%.
SIZES 2 - 12 INCH

TABLE OF CONTENTS

Overview .................................................. Cover
Valve Identification ........................................ 2
Configurations ............................................. 2-3
Globe Style Body ............................................ 4
Quick Selection ............................................... 4
Valve Body Specifications ............................ 6
Actuator Specifications ................................ 7
Actuator Instructions ................................ 7-9
Installation Guidelines ......................... 10-11
Wiring Diagram ...................................... 12-13
Dimensions .............................................. 14-22
Commissioning Guidelines ................ 23-25
Water Quality .................................................26
Parts Kits ................................................... 26-29
Drawings................................................... 30-38
Flowmeter ................................................ 39-41
Control Panel Operations ............ 42, 48-51
Control Configurations ........................ 42-47
Monitrol Torque Table .................................55
VARI-ORIFICE DP VALVE - This version of the product uses a lower
cost method of Flow Calculation with differential pressure and the
know Cv of the valve and specific gravity of the controlled fluid to
calculate flow. Flow control accuracy is specified at ±1.6%.
TEMPERATURE REGULATOR
With the inclusive remote temperature sensor, you can control
the temperature of a secondary flow stream with the Monitrol
installed on the primary flow stream. An example might be with
the Monitrol connected to a heat exchanger where it is desired to
maintain a constant outlet temperature.
PRESSURE REGULATOR
With a built in Pressure sensor, you can control the up-stream
pressure of the flow stream (Back-Pressure Regulator), or down-
stream pressure of the flow stream (traditional PRV).
Each valve has two pressure taps upstream or down stream for
this function. Incredibly accurate pressure control with a full range
of set points under all load conditions is the result.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MON FM IOM and is the answer not in the manual?

Questions and answers

Summary of Contents for Monitrol MON FM IOM

  • Page 1: Table Of Contents

    (sensors), simultaneously with its control logic. FLEXIBILITY allows TEMPERATURE REGULATOR the control logic in Monitrol to be bypassed if that is desired. A With the inclusive remote temperature sensor, you can control Building Management System can still maintain all control and the temperature of a secondary flow stream with the Monitrol just make use of the sensor information if that is desired.

  • Page 2: Valve Identification

    Examples of the current factory nameplates and other product lines or older valves may be different, contact the flow arrow plate used on Monitrol control valves are shown here. factory for details. The accompanying table identifies the information present and...
  • Page 3 Remote Sensors result in reduced MAX Cv for stroke ONLY length. E024 & E025 Actuators are excluded for valves 4” and larger. ACTUATOR NAMEPLATE FLOW ARROW PLATE 2-WAY FLOW 3” VBA NAMEPLATE INDUSTRIAL VBA 3” Monitrol MON_FM_IOM_NoRev_0514...

  • Page 4: Globe Style Body

    5.0” 125 mm 38.1 53.9 control valve element of the 6.0 R2 150 mm 38.8 54.9 Monitrol assembly. 6.0 R 150 mm 44.4 62.8 2-The Above Figures are based on 6.0” 150 mm 1138 50.8 71.8 water (SG = 1).
  • Page 5 INFORMATION PRESENT ON MONITROL CONTROL VALVES MON-XX-29 MON-XX-58 Model Number & Serial Number Information Location Notes Symbol(s) Model • On Actuator Nameplate attached to actuator. Model number On actuator (Configuration) Serial number Serial On actuator • On Actuator Nameplate attached to actuator.

  • Page 6: Valve Body Specifications

    Stem Down Stem Up Upper Port Common Port Upper Port Common Port Stem Down Stem Up Flow Flow Upper Port Lower Port Upper Port Lower Port VALVE BODY SPECIFICATIONS Flow Flow Lower Port Lower Port Flow The upper port closes The upper port opens Common Port Common Port...

  • Page 7: Actuator Specifications

    Factory Aligned, Vertical Above Centerline of Control Valve. TR5000-X ACTUATOR INSTRUCTIONS Page Set-up & Wiring....10-11 MONITROL ON MONITROL ON (5, 6, 8, 10, 12 in; DN 125, 150, 200, 250, 300) (2-1/2, 3, 4 in; DN 65, 80, 100) 2900...

  • Page 8: On/Off Switch

    The PCB has an aperture potentiometer. DO NOT adjust the aperture potentiometer. The aperture potentiometer is factory set to 100. If the aperture potentiometer is adjusted to less than 100, the valve will not function properly as a Monitrol. 2600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com...
  • Page 9 3) Terminal 5,6 (AL): Fault SPDT input terminal (NO) When a fault occurs, this terminal will close. Faults include: The actuator cannot complete the self- stoking function. The actuator cannot move the stem to the correct position for the input signal. NOTES: 1. Contact Capacity of SPDT:1A (125VAC/30VDC) 2. Contact Capacity external connection SPDT: more than 50mA /30VDC Monitrol MON_FM_IOM_NoRev_0514...

  • Page 10: Installation Guidelines

    Android based Proprietary 5” tablet. It features 2 1/2” 30” 10” Monitrol, due to the use of a flow stabilizer and optimized digital filtering, the effect of turbu- 8.0” 20” 12” four conduits. The first conduit should be used for the external 110/ 3.0”...

  • Page 11: Control Panel Installation

    CABLE ROUTING The monitrol control panel comes with four pre-installed Preliminary - DEC 2012 highquality NEMA 4x glands. Gland #1- this gland is intended to route the power cables from the main power supply.

  • Page 12: Wiring Diagram

    MONITROL FLOW METERING CONTROL VALVE WIRING CONNECTIONS WIRING DIAGRAM ON-SITE CONNECTIONS The Wiring and cabling from the Control Panel to the Control Valve assembly is not included WIRING: Signal Wire is to be Alpha Wire Cable #25481 BK199, 2-wire twisted pair, 22 AWG, 7 strands 30 AWG, copper, tinned, foil shielded, polyurethane jacket - OR equivalent.
  • Page 13 WIRING DIAGRAM VIEW OF Flow Meter Wiring Terminations Monitrol MON_FM_IOM_NoRev_0514...

  • Page 14: Dimensions

    DIMENSIONS MON-FM MODELS 2”-4” (50mm-100mm) 2600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com...
  • Page 15 DIMENSIONS MON-FM MODELS 5”-8” (125mm-200mm) Monitrol MON_FM_IOM_NoRev_0514...
  • Page 16 DIMENSIONS MON-FM MODELS 10”-12” (255mm-300mm) 2600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com...
  • Page 17 DIMENSIONS MON-RG MODELS 2.5”-4” (65mm-100mm) Monitrol MON_FM_IOM_NoRev_0514...
  • Page 18 DIMENSIONS MON-RG MODELS 5”-8” (125mm-200mm) 2600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com...
  • Page 19 DIMENSIONS MON-RG MODELS 10”-12” (255mm-300mm) Monitrol MON_FM_IOM_NoRev_0514...
  • Page 20 DIMENSIONS MON-DP MODELS 2.5”-4” (65mm-100mm) 2600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com...
  • Page 21 DIMENSIONS MON-DP MODELS 5”-8” (125mm-200mm) Monitrol MON_FM_IOM_NoRev_0514...
  • Page 22 DIMENSIONS MON-DP MODELS 10”-12” (255mm-300mm) 2600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com...

  • Page 23: Operation

    8 in, DN200 Full, 1SR, 2SR its standby position. 10 in, DN250 Full, 1SR, 2SR 1-1/2 12 in, DN300 Full, 1SR, 2SR Note: 1SR = 1 Size Reduced, 2SR = 2 Sizes Reduced • Place valve in operation. Monitrol MON_FM_IOM_NoRev_0514...
  • Page 24 TRAVEL INDICATION Travel Indicator Travel Scale Travel Indicator Travel Indicator Travel Scale Travel Indicator 2600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com...

  • Page 25: Maintenance

    MAINTENANCE MON-XX-58 MON-XX-29 Monitrol Valves for the most part maintenance free when prop- deposits, dirt, dust, and scratches or the packing parts may be erly selected and installed. Rebuilding of these valves should damaged resulting in a packing leak. Control valve hunting will not be necessary under normal operating conditions.

  • Page 26: Water Quality

    WATER QUALITY RECOMMENDED PARAMETERS Water Quality Water Quality Recommended Parameters Recommended Parameters CAUTION Chilled Water, Closed Loops, and Hot Water Systems up to 212°F (100° C). Chilled Water, Closed Loops, and Hot Water Systems up to 212°F (100° C). < <...
  • Page 27 FOR PACKING TYPE L LIP PACKING ALL SIZES EXCEPT 8 IN, DN200 SEE DWG C3769956 Item Item Description Description BONNET BEARING BONNET FOR PACKING TYPE L LIP PACKING ALL SIZES EXCEPT 8 IN, DN200 SEE DWG C3769956 Item Description Item Description BONNET BEARING BONNET Monitrol MON_FM_IOM_NoRev_0514...
  • Page 28 PARTS KITS MON-XX-58 REPACK KIT FOR MON-XX-58 MODELS WITH PACKING TYPE T V-RING SEE DWG C3761331 Item Description Item Description PACKING NUT PACKING SPRING STEM WIPER PACKING BOX RING PACKING RETAINER WIPER RETAINER SLEEVE BEARING TUBE STEM LUBE V-RING PACKING SET TUBE COPPER ANTI SEIZE COMPOUND PACKING WASHER MON-XX-58...
  • Page 29 SEAT RING MON-XX-58 ADDITIONAL BONNET SUBASSEMBLY PARTS IN REBUILD/REPACK KIT FOR PACKING TYPE T V-RING SEE DWG C3761331 Item Description Item Description FLANGED BEARING FOR PACKING TYPE L LIP SEE DWG C3761337 Item Description Item Description FLANGED BEARING Monitrol MON_FM_IOM_NoRev_0514...

  • Page 30: Drawings

    C3761331 V-RING PACKING for the MON-XX-58 2600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com...
  • Page 31 C3761357 NLP PACKING for the MON-XX-58 Monitrol MON_FM_IOM_NoRev_0514...
  • Page 32 C3769950 TEFLON V-RING PACKING FOR MON-XX-29 2600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com...
  • Page 33 C3769956 NLP PACKING FOR MON-XX-29 Monitrol MON_FM_IOM_NoRev_0514...
  • Page 34 D3241336 2600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com...
  • Page 35 D3241334 Monitrol MON_FM_IOM_NoRev_0514...

  • Page 36: Valve Body Assembly

    D3241556 VALVE BODY ASSEMBLY 5 & 6” (DN 125 & 150) for Type 23 2600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com...
  • Page 37 D3201950 VALVE BODY ASSEMBLY 10” (DN 250) for Type 22 Monitrol MON_FM_IOM_NoRev_0514...
  • Page 38 D3201950 2600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com...

  • Page 39: Structure And Operation Principle

    -25 to 65 (-13 to 149 Liner: Relative Humidity: ≤85% Ambient Temperature: -30 to 60 (-22 to 140 Analog Output Effects: ±0.1% of rate ±0.01mA Current Output: 4 to 20mA Supply Power: 20 to 36VDC Fig. 2: Analog Output Effects Power: S<10W/AC, S<7.5W/DC Monitrol MON_FM_IOM_NoRev_0514...
  • Page 40 FLOW METER FLOW RANGES AND METER SIZES MIN. FLOW RANGE MAX. FLOW RANGE Table. 1: Flow METER SIZE Ranges and FLOW VELOCITY FLOW VELOCITY Meter Size 0 to 0.5 m/s 0 to 1.64 ft/s 0 to 10 m/s 0 to 32.81 ft/s Inch l/min, m3/h l/min, m3/h...

  • Page 41: Control Panel Operations

    Configuration of the application can be accessed by pressing the settings button in the top right corner, which is password Monitrol MON_FM_IOM_NoRev_0514...

  • Page 42: Control Configurations

    INITIAL COMMISSIONING / START UP: Before isolation valves are opened in line with the Monitrol and after electrical connections are made, power can be applied to the control box. After the control panel initializes to the home screen, set the MANUAL MODE into the ON position.
  • Page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onitrol MON_FM_IOM_NoRev_0514 X">"-'N$%2&,1 H,]$,1'%2(0,...
  • Page 44 @7'=,?-':0,**"1,';'<&&(I?')?,*'-(',$-,*'?"#$%&'0%&),' -./0123-612.0/ /%I'!B%$ H,]$,1'%2(0, >%$)%&&3 -./0123-612.0/ N$#"$#,,*"$#'O$"-'!B%$ H,]$,1'%2(0, /%I'!B%$ H,]$,1'%2(0, CONTROL CONFIGURATION -./0123#12.781950 N$#"$#,,*"$#'O$"-'!B%$ H,]$,1'%2(0, !B%$':S?,- H,]$,1'%2(0, -./0123#12.781950 !B%$'U%"$ H,]$,1'%2(0, !B%$':S?,- H,]$,1'%2(0, -./0123&.2:81950 !B%$'U%"$ H,]$,1'%2(0, !"C /,?(&)C($'V"&-,* -);<*='-$*>3&<<@D+#E3-'(%+A H,]$,1'%2(0, -./0123&.2:81950 !,$?"C0"-3'V"&-,* H,]$,1'%2(0, -./0123'045 /,?(&)C($'V"&-,* H,]$,1'%2(0, -./0123A.B.:1950 !,&,+-,1'!"#$%& =J,'V,,12%+['#"0,$'-('!)B,*0"?(*3'!3?-,>7'=J,'%0%"&%2&,' !,$?"C0"-3'V"&-,* H,]$,1'%2(0, X">"-'N$%2&,1 H,]$,1'%2(0, (BC($?'%*,5...
  • Page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onitrol MON_FM_IOM_NoRev_0514 /%I'!B%$ N$#"$#,,*"$#'O$"-'!B%$ H,]$,1'%2(0, H,]$,1'%2(0,...
  • Page 46 /,?(&)C($'V"&-,* H,]$,1'%2(0, 67'89:'!"#$%&8';'<$%&(#),'?"#$%&'*,+,"0,1'.*(>'%+-)%-(* !,$?"C0"-3'V"&-,* H,]$,1'%2(0, @7'8=,?-':0,**"1,8';'A%$)%&&3',$-,*,1'+(>>%$1'.*(>' -./0123A.B.:1950 <$1*("1'<BB&"+%C($'D)?,'($&3'".'*,E)"*,1F CONTROL CONFIGURATION X">"-'N$%2&,1 H,]$,1'%2(0, !"#$%&'G%&), 9.'!"#$%&'!()*+,'"?5 67'9:'!"#$%&';'H"?B&%3?'?"#$%&'*,+,"0,1'"$'"$B)-'B(*- @7'=,?-':0,**"1,';'<&&(I?')?,*'-(',$-,*'?"#$%&'0%&),' P"C +#,)+,$*3&<<@D+#E3-'(%+A >%$)%&&3 -./0123'045 -./0123-612.0/ !"#$%&'!()*+, !,&,+-'?()*+,'(.'!"#$%&'*,+,"0,1'.*(>'%+-)%-(* /%I'!B%$ H,]$,1'%2(0, 67'89:'!"#$%&8';'<$%&(#),'?"#$%&'*,+,"0,1'.*(>'%+-)%-(* N$#"$#,,*"$#'O$"-'!B%$ H,]$,1'%2(0, -./0123#12.781950 @7'8=,?-':0,**"1,8';'A%$)%&&3',$-,*,1'+(>>%$1'.*(>' <$1*("1'<BB&"+%C($'D)?,'($&3'".'*,E)"*,1F !B%$':S?,- H,]$,1'%2(0, !"#$%&'G%&), 9.'!"#$%&'!()*+,'"?5 !B%$'U%"$ H,]$,1'%2(0, 67'9:'!"#$%&';'H"?B&%3?'?"#$%&'*,+,"0,1'"$'"$B)-'B(*- -./0123&.2:81950 /,?(&)C($'V"&-,* H,]$,1'%2(0, @7'=,?-':0,**"1,';'<&&(I?')?,*'-(',$-,*'?"#$%&'0%&),' !,$?"C0"-3'V"&-,*...
  • Page 47 67'9:'!"#$%&';'H"?B&%3?'?"#$%&'*,+,"0,1'"$'"$B)-'B(*- @7'=,?-':0,**"1,';'<&&(I?')?,*'-(',$-,*'?"#$%&'0%&),' >%$)%&&3 -./0123-612.0/ /%I'!B%$ H,]$,1'%2(0, N$#"$#,,*"$#'O$"-'!B%$ H,]$,1'%2(0, -./0123#12.781950 !B%$':S?,- H,]$,1'%2(0, !B%$'U%"$ H,]$,1'%2(0, -./0123&.2:81950 /,?(&)C($'V"&-,* H,]$,1'%2(0, !,$?"C0"-3'V"&-,* H,]$,1'%2(0, ->-,<?3-<,,'%(- c%+[)B'4($]#)*%C($ c%+[)B'-('!H'4%*17'W&,%?,'>()$-'!H'+%*1'+(**,+-&3' 2,.(*,'B*(+,??"$#'2%+[)B7 /,?-(*,'4($]#)*%C($ /,?-(*,'+($]#'.*(>'!H'+%*17 H,0"+,'A%$%#,>,$- <++,??'<$1*("1':!7'W%??I(*1'W*(-,+-,17 X(+%&'9W N-J,*$,-'!-%C+'9W'%11*,??7 <H<A'9W 9W'%11*,??'(.'-J,'<H<A'9:'2(%*17'4J%$#,'"$'9W'>%3' +%)?,'&(??'(.'.)$+C($%&"-37 4%&"2*%C($'A(1, /,>(0,?'$,,1'-(',$-,*'B%??I(*1',0,*3C>,'3()'$,,1'-(' +($]#)*,7'=)*$'(S'%h,*']$"?"$#'+($]#)*%C($7 c*"#J-$,?? <1b)?-?'-J,'2*"#J-$,??'(.'-J,'?+*,,$7 O?"$#'-J,'?,,[2%*'-J,'2*"#J-$,??'(.'-J,'?+*,,$'+%$'2,' %1b)?-,17 Monitrol MON_FM_IOM_NoRev_0514...
  • Page 48 CONTROL PANEL OPERATIONS Specific Gravity The Specific Gravity affects the flow calculation while using Pressure * APPLICATION NOTE ON SG Sensors. Default Value is 1. Control Displays the Operation Strategy - Valve Position Variable Signal Source Select Source of Signal Received by Controller 1.
  • Page 49 Signal Range (eg:- 4mA is 0% open, 12mA is 50% open) Default values used are EUMin = 0% and EUMax = 100%. Span Offset Defined above Span Gain Defined above Limit Enabled Defined above Preliminary - DEC 2012 Monitrol MON_FM_IOM_NoRev_0514...
  • Page 50 CONTROL PANEL OPERATIONS Signal Source Select Source of Signal Received from Actuator 1. IO Signal - Analog Signal connected to Terminals 2. Override - Manually entered command from Android Application (use only if required) Signal Value Displays signal received if Signal Source is IO Signal. If source is Overriden, you can enter value here Manually.

  • Page 51: General Safety Information

    Follow all operating instructions. Before performing any maintenance, make sure all electrical Do not attempt to service the Monitrol Control Panels unless lines to the system are shut off and /or disconnected. you have been trained or authorized to attempt repairs. For service contact Warren Controls.

  • Page 52: Actuator Removal & Installation

    ACTUATOR REMOVAL & INSTALLATION MONITROL ON 2900 2600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com...
  • Page 53 ACTUATOR REMOVAL & INSTALLATION MONITROL ON 2 INCH, DN 50 5800 Monitrol MON_FM_IOM_NoRev_0514...
  • Page 54 ACTUATOR REMOVAL & INSTALLATION MONITROL ON 2-1/2, 3 & 4 INCH, DN 65, 80 & 100 5800 2600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com...

  • Page 55: Monitrol Torque Table

    NOTES BONNET/TOP COVER CAPSCREW TORQUES SIZE TORQUE Inches DN (mm) ld-Ft Table: Monitrol Torque Monitrol MON_FM_IOM_NoRev_0514...

  • Page 56: Mon_Fm_Iom_Norev_0514

    MON_FM_IOM_NoRev_0514 2600 EMRICK BLVD • BETHLEHEM, PA 18020 • USA •800-922-0085 • WWW.WARRENCONTROLS.COM DEPENDABLE, RUGGED, PRECISION CONTROL VALVES AND ACCESSORIES...
