1. Laser protection safety • The output wavelength of JPT portable handheld laser cleaning machine is 1064nm (invisible light), and the average output of the laser is The power exceeds 200W (peak power exceeds 20KW), which is a Class IV laser. It can not only treat the retina and The cornea causes irreversible damage and can also burn the skin.
Page 5
200W Portable Handheld Laser Cleaning Machine User Manual * Please do not disassemble this equipment without permission. All maintenance and upkeep can only be performed within the JPT company. Level work can be performed on-site by technical support personnel. If this device is disassembled without permission, it may cause damage.
Page 6
Machine Translated by Google 200W Portable Handheld Laser Cleaning Machine User Manual Table 1 Safety Label Label image Label Information Beware of laser tags (laser heads) Usage warning (on laser cover) Laser protection markings Figure 1 Laser protective glasses...
The focus position under the field lens meets the auxiliary focus needs in different scenes. The control system adopts the laser cleaning control card and program independently designed by JPT, which can control the laser parameters and scanning system at the same time.
200W Portable Handheld Laser Cleaning Machine User Manual The picture below is a physical picture of JPT’s 200W portable handheld laser cleaning machine (the specific appearance is subject to JPT’s actual shipment): Figure 2 Actual picture of CL2-200 portable handheld laser cleaning machine 1.2 Product characteristics...
Machine Translated by Google 200W Portable Handheld Laser Cleaning Machine User Manual 1.3 General characteristic parameters of laser Table 2 CL2 200W cleaning series laser parameter indicators model YDFLP-CL2-200-1-A YDFLP-CL2-200-5-A index <1.5 M² Output armored cable length m >200 Average output power W Maximum pulse energy mJ 1-3000 Frequency adjustable range kHz...
Page 11
Machine Translated by Google 200W Portable Handheld Laser Cleaning Machine User Manual Table 5 YDFLP-CL2-200 series laser power reduction frequency value (kHz) Reduction power frequency (kHz) Set pulse width Maximum frequency (kHz) (ns) YDFLP-CL2-200-1 YDFLP-CL2-200-5 1200 3000 2000 1000 *Above the reduced power frequency is the full power output range of the laser, and below the reduced power frequency is the reduced power output range of the laser. That is, when the power reduction frequency is below the laser, the output power will be reduced synchronously to protect the laser.
Page 12
Machine Translated by Google 200W Portable Handheld Laser Cleaning Machine User Manual 4-1 YDFLP-CL2-200-1-A output waveform curve diagram Figure 4-2 YDFLP-CL2-200-5-A output waveform curve...
Machine Translated by Google 200W Portable Handheld Laser Cleaning Machine User Manual *For detailed laser information, please refer to the description of JPT 200W Clean Pulse Fiber Laser YDFLP-CL2-200-1/5-A Book 1.4 General characteristic parameters of cleaning machine Table 4 Parameters and indicators of CL-200 cleaning machine...
Machine Translated by Google 200W Portable Handheld Laser Cleaning Machine User Manual 1.5 Overall dimensions of cleaning machine Figure 5 Dimensions of the outer box of the cleaning machine Figure 6 Dimensional diagram of cleaning gun head...
Machine Translated by Google 200W Portable Handheld Laser Cleaning Machine User Manual 1.6 Actual configuration list Please refer to the included checklist according to Table 5 Table 5 Handheld cleaning machine configuration list project quantity fiber-optic laser 1 set Laser protective glasses 163 focal length field lens 254 focal length field lens 1 item...
Machine Translated by Google 200W Portable Handheld Laser Cleaning Machine User Manual Copper alloy surface patina cleaning Cleaning of oxides and pollutants on the surface of steel pipes Rail rust removal 2. Instructions 2.1 Equipment operation steps (1) Open the case, take out the power cord, plug one end into the power interface located next to the cooling duct on the top of the case, and plug the other end into Connect to 100-240V AC power supply.
Machine Translated by Google 200W Portable Handheld Laser Cleaning Machine User Manual Can produce laser) 2.2 Micro operation instructions 2.2.1 Brief description of micro-management Micro-operation has many functions such as marking parameter settings, drawing graphics settings, alarm monitoring, status monitoring, etc. 6 in total Interface: current parameters, graphic settings, cleaning parameters, status prompts, alarm monitoring, and function selection.
Page 19
Machine Translated by Google 200W Portable Handheld Laser Cleaning Machine User Manual (3) Cleaning parameters: As shown in Figure 11, the interface includes laser power, laser frequency, pulse width, light on delay, off Parameters such as light delay, end delay, corner delay and jump delay, when sliding the pulley to select the corresponding parameter, press the pulley Press the confirm button to jump to the parameter setting interface.
Page 20
Machine Translated by Google 200W Portable Handheld Laser Cleaning Machine User Manual (4) Graphic settings: This interface can set whether the marking graphic is a straight line, a rectangle, a circle, a sine or a double chord, according to Depending on the selected graphics, different parameters will appear to provide settings. In this interface, select "Graphics Settings" labeled ÿ to confirm the recovery. Return to the current parameter interface in Figure 12.
Page 21
Machine Translated by Google 200W Portable Handheld Laser Cleaning Machine User Manual Figure 13 Rectangle Figure 14 Filling parameters Ranges The length of the F163:0~110ÿF254:0~175ÿ Parameter length functional rectangle F330:0~200 width F163:0~110ÿF254:0~175ÿ width of rectangle F330:0~200 Contour enable Select whether to outline the graphic. fill enable Select whether to fill the entire graphic.
Page 22
Machine Translated by Google 200W Portable Handheld Laser Cleaning Machine User Manual Figure 16 Sine and double sine Ranges Function: F163:0~110ÿF254:0~175ÿ Total length of sine and double chord Parameter length F330:0~200 The distance from the highest point of sine and double sine to the X-axis F163:0~110, F254:0~175, Amplitude F330:0~200 1~100...
Page 23
Machine Translated by Google 200W Portable Handheld Laser Cleaning Machine User Manual trajectory. The graph is shown in Figure 23.1. Figure 18.1 Archimedean spiral Figure 18.2 Parameters of Archimedes spiral Ranges The length from Parameter F163:0~11ÿF254:0~17.5ÿ polar diameter the starting point to the center point of the functional action spiral F330:0~20 F163:0~11ÿF254:0~17.5ÿ...
Page 24
Machine Translated by Google 200W Portable Handheld Laser Cleaning Machine User Manual length F163:0~11ÿF254:0~17.5ÿ The length of the Lissajous figure F330:0~20 width F163:0~11ÿF254:0~17.5ÿ Lissajous figure width F330:0~20 The movement methods of different filling methods are as follows: Optimize two-way Two-way unidirectional (5) Status prompt: This interface can monitor the laser frequency, power, pulse width, PA, MO, RED, optical Road temperature, TEC temperature status, slide up or down on the alarm monitoring interface to enter the interface, as shown in Figure 20.
Page 25
Machine Translated by Google 200W Portable Handheld Laser Cleaning Machine User Manual (7) Matching of micro operation and control card: The cleaning control card and micro operation settings are controlled one-to-one. If the micro operation and main control card are controlled by One party needs to replace a new object, and the two wireless modules cannot match.
Page 26
Machine Translated by Google 200W Portable Handheld Laser Cleaning Machine User Manual Can. The default password for power on is 6 zeros. 2.2.3 Introduction to other micro-management functions (1) Data storage There are 12 groups of templates that can be saved on the micro operation. When entering each group of templates, all parameter values will be read out and automatically adjusted. The laser is set according to the corresponding parameters, and the parameter values set in each group of templates will be automatically saved.
Page 27
Figure 26 Schematic diagram of hand-held head angle 2. Use JPT cleaning card with offset marking function. As shown in Figure 27, adjust the marking position. The default marking position is in the vibrating position. The edge of the mirror processing position can effectively prevent high reflection from damaging the laser and lens. The retraction distance can modify the offset position.
The laser is faulty and needs to be returned to the factory for repair. 6 other alarms *Except for the above, if you have any questions or malfunctions while using the cleaning machine, you can contact JPT need help 4. Repair and service...
4.1 General warranty After all products manufactured according to the order or specifications are shipped, JPT will not be responsible for any defects in materials and technology during the contract warranty period. Defective products are warranted and guaranteed to conform to specifications under normal use. Jept has the right to selectively defend During the repair period, any product with material or technical problems will be repaired or replaced, and the failure is caused by materials or production processes.
