User guide Freiheit® Freedom walking frame 150kg Code: 1554 Contents Definitions Care and maintenance 11 Storage 11 Disposal Intended use Maintenance schedule Safety warnings Servicing 11 Environmental conditions List of components Product labels 11 Life time Instructions for use Troubleshooting 11 Limited warranty Attaching and using 10 Product specifications...
Page 2: Definitions
Intended use Definitions The Freiheit® Freedom XC walking frame with Symbols used in this user manual and their 310mm wheels is designed for persons with meanings. restricted mobility with a maximum body user WARNING! Failure to heed this warning weight of 150kg who require additional support may result in damage to the product or while walking.
Page 3: List Of Components
• This walking frame is not suitable for children WARNING! BEFORE USE make sure the handle height adjustment • Check regularly that the tyre pressure is correct knobs are tight and the folding lock • DO NOT exceed the weight limitation of the is firmly down.
Page 4: Instructions For Use
Instructions for use CAUTION! Beware of pinch points. Take care not to trap your hands, fingers or clothing when operating the folding lock and when unfolding/folding the walking frame. Setting up/unfolding the walking frame • Position the walking frame in front of you with the handles pointing towards you •...
Page 5 Braking To reduce speed while walking, pull both levers evenly and gently upwards. Always apply the same amount of power on both brake levers D. Brake adjustment Check that the brakes are correctly adjusted as follows: • The brake lever and the Bowden cable must not be loose (they must not have any play) •...
Page 6: Attaching And Using Accessories
Attaching and using accessories Mesh bag The bag is approved for transporting objects up to a maximum weight of 5kg. • To attach the bag, take hold of the two side loops and hang them over the two holding rods •...
Page 7: Maintenance Schedule
WARNING! Do not use high-pressure Disinfection cleaners, strong, corrosive chemicals or Please only use the following disinfectants; use of scouring agents for cleaning purposes. other chemicals might damage the walking frame: WARNING! Observe the use and • Aldehyde-free disinfectants based on alcohol processing instructions issued by (max.
Page 8: Servicing
Maintenance schedule: Monthly What to check Description 1. The wheels must not be damaged and must run quietly, in a straight line and Steering and running without wobbling wheels: mobility, function and damage 2. Please clean the wheel hub if it is dirty or if fluff has accumulated 1.
Page 9: Product Labels
Product labels Symbols on product: Unique Device Identifier Caution - note the safety information in the (01) UDI-DI user guide (10) Order number (21) Serial number Medical device Manufacturer/manufacturer’s trademark/ contact address CE labelling Maximum safe working load Date of manufacture TAiMA XC Air Total width of walking frame 850 mm -...
Page 10: Troubleshooting
Troubleshooting Issue Possible causes Solution The wheel bearings are defective or the Consult an authorised specialist wheel suspension is no longer correctly The front wheels retailer. attached. do not run in a straight line. Inflate the tires to the correct pressure The tires are under inflated.
Page 11: Product Specifications
Product specifications: Description Freiheit® XC Freedom Code 1554 Frame 150kg Safe working load 750mm Overall dimensions 670mm 850mm Folded width 270mm 610mm Seat dimensions 450mm min. 850mm Total height max. 950mm Handle height adjustment range 838mm - 940mm in 25mm increments Turning radius 950mm Material...
Page 12: Product Compliance
Product compliance Environmental conditions Complete test according Ambient operation EN ISO 11199-2 -10°C to +50°C walking frame norm temperature Biocompatibility of plastic 0°C to 45°C | 20% ISO 10993 Ambient storage parts to 75% relative conditions humidity Flammability textile parts EN 1021-2 Storage Life time...
