Version

V1.0

V1.1

EMS-01D

user manual

Descriptive

First Edition

1. Add Ethernet port wiring

the

system

wiring

diagram.

2. Add network firewall

whitelist

Customer Focused, Quality

Data

2023-09-26

2023-10-11

客户为本·匠心为质

Table of Contents

Need help?

Do you have a question about the EMS-01D and is the answer not in the manual?

Questions and answers

Summary of Contents for KStar EMS-01D

Page 1 客户为本·匠心为质 Customer Focused, Quality EMS-01D user manual Version Descriptive Data V1.0 First Edition 2023-09-26 V1.1 1. Add Ethernet port wiring 2023-10-11 system wiring diagram. 2. Add network firewall whitelist...
Page 2: Table Of Contents
客户为本·匠心为质 Customer Focused, Quality CATALOGS 1 About this manual ......................1 1.1 Introduction ......................1 1.2 For Readers ......................1 1.3 Manual Usage .......................1 1.4 Symbol Use ......................1 2 Safety notice ........................2 3 Product description ......................3 3.1 Outlook .........................3 3.2 System framework ....................3 3.3 Function Description ....................
Page 3 客户为本·匠心为质 Customer Focused, Quality...
Page 4: About This Manual
1 About this manual 1.1 Introduction The purpose of this manual is to provide readers with detailed product information and maintenance instructions for industrial and commercial energy storage communication box controllers. 1.2 For Readers This document is intended for users who perform routine operations on the energy management controller of the energy storage communication box.
Page 5: Safety Notice
Please pay attention to the hazard warning marks on the body, which include： Identifier Identifier explain This symbol indicates that the body contains high pressure, and touching it may result in the risk of electric shock. This symbol indicates that the temperature here is higher than the acceptable range of human body.
Page 6: Product Description
Energy storage communication box controller and other property belonging to the  operator or third parties 3 Product description 3.1 Outlook 3.2 System framework...
Page 7: Function Description
3.3 Function Description Note: EMS is independent of each other, when one of the batteries or other factors can not be charged and discharged, it does not affect the work of other energy storage system units;Priority PV charging and discharging during charging and discharging. Anti-reflux function: When the battery is full and have PV, the energy storage system feeds the maximum power to the grid.
Page 8 the mains charging setting is enabled). In spontaneous self-use mode, the following functions can be superimposed: 1. Mains charging When mains charging is enabled: When the set time is reached, the mains is used to charge the battery. 2. Grid-connected power control When Export Power Control is enabled: When the PV power is greater than the load and charge power, the excess power is fed back to the grid, at most the grid-connected power setting value.When the set value is 0, no excess PV power is allowed to feed back to the grid.
Page 9: External Communication Interface
3.3.4 Peak cutting and valley filling In peak cutting and valley filling mode, charging or discharging from the mains according to the power of the grid, PV energy provides the load first, and then charges the battery. 1. Valley charging When the load power is less than the valley power, use the mains power to charge the battery.The power taken from the grid is greater than or equal to the valley value power.
Page 10: System Setting
3.6 System setting 1. Change the EMS IP address on the BC100DE ： The EMS factory default IP address (192.168.137.150) is changed to a different IP address for each EMS and then connected to the switch in the energy storage communication box (example:192.168.137.150, 192.168.137.151, 192.168.137.152, 192.168.137.153, 192.168.137.154, etc., a maximum of 20)；...
Page 11 Note: The subnet mask (default 255.255.255.0), gateway (default 192.168.137.1), DNS_1 (default 192.168.137.1), DNS_2 (default 192.168.137.1) do not need to be changed, use the default Settings. 2. Log in to the system： Connect the PC directly to the EMS01D through a network cable.
Page 12 Set the IP address of the computer to 192.168.2.201 Open the computer Settings, click "Ethernet" ->” Changing Adapter Options”; Select a network port,，for example“Ethernet 2“，tap” Ethernet 2”->” properties” tap “ Internet protocol version 4 （ TCP/IPv4 ） “ ->” Use the following IP address”->Enter the IP information in the figure->”confirm“->”...
Page 13 Access with your computer browser ： 192.168.2.100 ， User name ： admin ， Password：123456。 Password change; In“Parameter Setting”-> “Configuration”->“Change Username And Password”example change the user name and password; Configure the capacity： In“Parameter Setting”-> “Configuration”->” EMS IP Settings” Add EMS number and IP address...
Page 14 of the EMS。 Electric meter Settings： 1. The meter is connected to the terminal of RS4851 in the wiring terminal of the energy storage communication box cabinet (refer to 3.3 System Wiring), baud rate :19200, address :1, no check, 1 stop bit.Baud rate, address setting mode，see《YDS60-80 Smart Power Sensor.pdf》-3.2-3.3 2.
Page 15 energy storage communication box for external communication (web page, IEC-104, ModbusTcp). In“Parameter Setting”-> “Configuration”-> “Networking Settings “Modify the server type and Internet access mode of the energy storage communication box. Select "Server 1" for Chinese users and "Server 2" for users from other countries.； There are "Ethernet", "4G", "WIF"...
Page 16 In “ Parameter Setting ” ->” Operation Stratergy” Set the running mode of the energy storage system.(For details about the running mode, see 3.4 Function Description.); 7，Other settings Time: Enter the time according to the local time. Power grid standard: Select a power grid standard based on the local power grid type.
Page 17: Data Display
3.7 Data display 3.7.1 Home page The home page of the controller screen of the energy storage communication box visually displays PV, INV, power grid, charge and discharge amount and other data, as shown in the following figure： 3.7.2 Language settings You can select the Settings in the top right corner, available options are: English, Chinese, as shown below：...
Page 18 below： 3.7.3.2 BAT Running information Click "BMS" to select the real-time data of BMS under each EMS, as shown in the figure below： 3.7.3.3 Meter Information Click "electricity meter", you can view the real-time data of the electricity meter, as shown below：...
Page 19: System Settings
3.7.4 System Settings 3.7.4.1 Basic Settings click“Configuration”， to view the basic information and Settings of the system， IP information: Internal IP information of the energy storage communication box connected to the EMS network (no need to change); Networking Settings: Type of EMS system uploaded to domestic server or foreign server; Access the Internet with Ethernet, 4G, wifi or DHCP.
Page 20: Trial Run
3.7.4.2 Controlling Information Operation mode Settings: manual mode, self-use, time-sharing control, peak cutting and valley filling, battery backup. According to the use requirements, you can set it on this page, as shown in the following figure： 4 Trial Run Check before running： All cables are intact, properly insulated, and properly sized ...
Page 21: Apply Case Configuration
5 Apply case configuration The operating modes of the system include: self-use, time-sharing power, peak cutting and valley filling, and battery backup 5.1 Self-use 1. Enter the control interface, select Running mode setting, and select Spontaneous self-use; 2. Enable the charging time, and enter the charging period and power: 00:00-07:00, -50; 3.
Page 22: Cut Peaks And Fill Valleys
5.3 Cut peaks and fill valleys 1. Enter the control interface, select operation mode setting, and select peak trimming and valley filling; 2. Valley power, and input value 10; 3. Peak power, and input value 50; 4. At this time, the system will run in peak cutting and valley filling mode. 5.4 Battery Backup 1.
Page 23: Routine Maintenance
4. In this case, the system works in battery backup mode. 6 Routine Maintenance General safety rules: Only qualified and authorized personnel are allowed to maintain the energy storage  communication box controller. Do not leave metal parts such as screws and washers in the controller of the energy storage ...
