Summary of Contents for Alpha Technologies SD08
- Page 1 SD08 Battery Fail Monitor Part # 018-546-B2 Effective: 07/2011 Your Power Solutions Partner member of The Group ™...
- Page 3 SD08 Battery Fail Monitor 018-546-B2 RevD The following documents and drawings are included in this manual: • Specification: 018-546-B1 • Outline drawing: 018-546-06 • Customer connection drawing: 018-546-08...
-
Page 5: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS This section contains important instructions that must be followed during the installation and maintenance of the equipment and batteries. Read all of the instructions before operating the equipment, and save this manual for future reference. 1. -
Page 7: Table Of Contents
ABLE OF ONTENTS ................................1 NTRODUCTION Scope of the Manual ............................. 1 Product Overview ............................1 Part Numbers and List Options ........................1 ..........................2 EATURES LARMS AND ONTROLS Module Indicators ............................2 Fail Alarm ..............................2 Reset Button ..............................2 Mid-Point Alarm Setting Control ........................ -
Page 8: Introduction
NOTE: To aid the user with installation, frequent reference is made to drawings located at the rear of this manual. Product Overview The SD08 Battery Fail Monitor module (see Figure 1) is designed to monitor the status of a single battery string. The method used is “battery midpoint voltage monitoring.” The SD08 connection to the battery string splits the battery string voltage in half at the midpoint. -
Page 9: Features, Alarms And Controls
(and the battery status is OK) then the alarm clearz. The SD08 module has a terminal block (plug in cable connector) for the Form C relay alarm contacts located on the rear of the module PCB. Both normally closed (NC) and normally open (NO) contacts are available. -
Page 10: Battery Mid-Point Voltage Contacts
A variety of mounting options for the SD08 module allow for adjustments and indicators to be visible from the front of the panel. 2.8.1 19" Rack Mount Up to 4 SD08 modules may be flush mounted in a 19" single R.U. panel. See Figure 2 and drawing 018-546-06, sheet 1. 2.8.2 23" Rack Mount Up to 5 SD08 modules may be flush mounted in a 23"... -
Page 11: Inspection
If the original container is unavailable, make sure the product is packed with at least three inches of shock-absorbing material to prevent shipping damage. NOTE: Alpha Technologies is not responsible for damage caused by the improper packaging of returned products. Check for Damage Prior to unpacking the product, note any damage to the shipping container. -
Page 12: Installation
The SD08, 19" or 23" unit, should be mounted to the rack using two #12 – 24 x 1/2" screws in each bracket. Philips-type screws and screwdriver should be used to eliminate the possibility of slippage and scratching of the unit’s exterior. -
Page 13: Wiring And Connections
Do not over tighten the terminal screws. This may result in damage to the input connectors. The Fail Alarm terminals are connected to relay contacts in the SD08 module and both normally open or normally closed contacts are provided. Latching is jumper selectable. -
Page 14: Module Installation And Removal
Battery sense leads should be bundled and routed through the rear of the module or rack per drawing 018-546- 08. Route through the side of the SD08 in the case of the stand-alone or wall mount unit. Insert each wire into the appropriate terminal on the termination block and secure the wires by tightening the terminal screw. -
Page 15: Initial Startup
1. Confirm that the battery sense leads and alarm cables are connected to the terminal of the correct polarity at the SD08 module. See TB (terminal block) in Figure 5. WARNING Check battery polarity. Failure to do so could damage the unit and or battery. -
Page 16: Operation
Fail Alarm Contacts The SD08 module has a terminal block (plug in cable connector) for the Form C relay alarm contacts located on the rear of the module PCB; both normally open and normally closed contacts are available. The Fail Alarm contacts will change state when the voltage difference between the two halves monitored exceeds the programmed value set by the front panel control. -
Page 17: Maintenance
Maintenance Although very little maintenance is required with Alpha systems, routine checks and adjustments are recommended to ensure optimum system performance. Qualified service personnel should do repairs. The following table lists a few maintenance procedures for this system. These procedures should be performed at least once a year. -
Page 18: Warranty And Service Information
Warranty Alpha Technologies Ltd. warrants all equipment manufactured by it to be free from defects in parts and labor, for a period of two years from the date of shipment from the factory. The warranty provides for repairing, replacing or issuing credit (at Alpha’s discretion) for any equipment manufactured by it and returned by the customer to the... -
Page 19: Acronyms And Definitions
Acronyms and Definitions American wire gauge Canadian Electrical Code Canadian Standards Association Direct current Electronic Industry Alliance Light emitting diode Normally closed National Electrical Code (USA) Normally open OSHA Occupational Safety & Health Administration Printed circuit board Random access memory Rack unit (1.75") Underwriters Laboratories 018-546-B2 Rev D... - Page 20 The above information is valid at the time of publication. Consult factory for up-to-date ordering information. Specifications are subject to change without notice. Alpha Technologies Ltd. 018-546-B1 Rev D Printed in Canada. © 2011 Alpha Technologies Ltd. ALPHA is a registered trademark of Alpha Technologies Ltd. All Rights Reserved.
- Page 21 REVISIONS DESCRIPTION DATE APPD 5('(6,*1(' 482.6 19.00 465.1 31.8 18.31 1.25 43.7 1.72 23.9 )52179,(: 6,'(9,(: /,67 /,67 %/$1.,1*3/$7(6'02'8/( 6'%$77(5<)$,/021,725 /,67 DESCRIPTION FINISHED HOLE LEGEND THESE DESIGNS AND SPECIFICATIONS ARE THE PROPERTY OF ARGUS TECHNOLOGIES AND SHALL NOT BE COPIED OR USED FOR MANUFACTURING WITHOUT ITS WRITTEN CONSENT.
- Page 22 REVISIONS DESCRIPTION DATE APPD 584.2 23.00 566.7 31.8 22.31 1.25 43.7 1.72 23.9 6,'(9,(: )52179,(: /,67 /,67 %/$1.,1*3/$7(6'02'8/( 6'%$77(5<)$,/021,725 /,67 DESCRIPTION FINISHED HOLE LEGEND THESE DESIGNS AND SPECIFICATIONS ARE THE PROPERTY OF ARGUS TECHNOLOGIES AND SHALL NOT BE COPIED OR USED FOR MANUFACTURING WITHOUT ITS WRITTEN CONSENT.
- Page 23 REVISIONS DESCRIPTION DATE APPD 112.5 4.43 38.1 1.50 40.9 1.61 )52179,(: 6,'(9,(: /,67 61.0 2.40 DESCRIPTION FINISHED HOLE LEGEND 29.2 1.15 THESE DESIGNS AND SPECIFICATIONS ARE THE PROPERTY OF ARGUS TECHNOLOGIES AND SHALL NOT BE COPIED OR USED FOR MANUFACTURING WITHOUT ITS WRITTEN CONSENT. '( ,*1 &$ ...
- Page 24 REVISIONS DESCRIPTION DATE APPD 5('(6,*1(' :,5(&211(&7,21 /,67 :,5(180%(5 :,5(180%(5 9%0,' :,5(180%(5 9%0,' :,5(180%(5 DESCRIPTION :,5(180%(5 1& FINISHED HOLE LEGEND :,5(180%(5 & $/$50 :,5(180%(5 THESE DESIGNS AND SPECIFICATIONS ARE THE PROPERTY OF ARGUS TECHNOLOGIES AND SHALL NOT BE COPIED OR USED FOR MANUFACTURING WITHOUT ITS WRITTEN CONSENT.
- Page 25 REVISIONS DESCRIPTION DATE APPD /,67 :,5(&211(&7,21 :,5(180%(5 9% 9%0,' :,5(180%(5 :,5(180%(5 9%0,' DESCRIPTION :,5(180%(5 FINISHED HOLE LEGEND 1& :,5(180%(5 $/$50 :,5(180%(5 & THESE DESIGNS AND SPECIFICATIONS ARE THE PROPERTY OF ARGUS TECHNOLOGIES AND SHALL NOT BE COPIED OR USED FOR MANUFACTURING WITHOUT ITS WRITTEN CONSENT. '( ,*1 &$ ...
- Page 26 REVISIONS DESCRIPTION DATE APPD 02817,1*+2/(6 :,5((;,7 6(&21':,5((;,7 :,5(180%(5 /,67 :,5(180%(5 :,5(&211(&7,21 :,5(180%(5 DESCRIPTION FINISHED HOLE LEGEND :,5(180%(5 9%0,' :,5(180%(5 9%0,' THESE DESIGNS AND SPECIFICATIONS ARE THE PROPERTY OF ARGUS TECHNOLOGIES AND SHALL NOT BE COPIED OR USED :,5(180%(5 FOR MANUFACTURING WITHOUT ITS WRITTEN CONSENT. &$ 0$7(5,$/ '( ,*1...
- Page 28 Fax: +370 5 210 5292 Fax: +852 2199 7988 Visit us at www.alpha.ca Due to continuing product development, Alpha Technologies reserves the right to change specifications without notice. Copyright © 2011 Alpha Technologies. All Rights Reserved. Alpha® is a registered trademark of Alpha Technologies.
