- Page 1 Protege Wireless Lock Range Mortise Lock Handing Change Guide...
- Page 2 The specifications and descriptions of products and services contained in this document were correct at the time of printing. Integrated Control Technology Limited reserves the right to change specifications or withdraw products without notice. No part of this document may be reproduced, photocopied, or transmitted in any form or by any means (electronic or mechanical), for any purpose, without the express written permission of Integrated Control Technology Limited.
-
Page 3: Table Of Contents
Contents Introduction Handing Guide Mortise Lock Parts Guide Mortise Lock Handing Change Remove the Mortise Case Cover Plate Update the REX Switch Configuration Interchange the Locking Levers Update the Latchbolt Configuration Replace the Mortise Case Cover Plate Protege Mortise Lock Handing Change Guide... -
Page 4: Introduction
When you order Protege mortise locks, you must specify the handing based on the doors they will be installed in. ICT strongly recommends selecting the correct handing when you order the locks and restocking if you do not have the correct locks to complete a project. -
Page 5: Mortise Lock Parts Guide
Mortise Lock Parts Guide The following image identifies the key components involved in the mortise lock handing change. Protege Mortise Lock Handing Change Guide... -
Page 6: Mortise Lock Handing Change
Mortise Lock Handing Change A number of lock components are installed in specific positions for each handing configuration and must all be updated correctly for the lock to operate in the new handing configuration. To change the handing of a mortise lock the following steps need to be performed: Remove the mortise case cover plate. -
Page 7: Update The Rex Switch Configuration
Update the REX Switch Configuration Loosen the two screws that are securing the REX switch. Swap the REX switch and spacer. LH/LHR: The switch needs to be at the bottom, with the spacer at the top. RH/RHR: The spacer needs to be at the bottom, with the switch at the top. Secure the REX switch in place, ensuring that the REX trigger is facing the retractor hub. -
Page 8: Interchange The Locking Levers
Interchange the Locking Levers The locking lever on the locked (entry) side of the door must be engaged on the motor assembly drive block. LH/LHR RH/RHR Remove the stopworks screw located in the lower front corner of the mortise case. Remove the upper locking lever. Carefully raise the motor assembly just enough to rotate the lower locking lever into position. -
Page 9: Update The Latchbolt Configuration
Update the Latchbolt Configuration Remove the latchbolt head screw. Flip the latchbolt head to the required orientation. For LH and RHR the beveled side of the latchbolt head should be facing upwards. For RH and LHR the beveled side of the latchbolt head should be facing downwards. LH and RHR RH and LHR The beveled edge needs to be on the side where the door closes against the jamb (see the... - Page 10 In accordance with the ICT policy of enhanced development, design and specifications are subject to change without notice.
