GFG - Grace Fixed Gateway
User Information
GFG Grace Fixed Gateway
Grace Fixed Gateway (GFG) is a wireless bridge that manages the data signaling between Grace
Lone Worker safety Pendants and the Grace Connected Safety
Cloud Monitoring Portal. GFG
®
®
contains a wireless signaling link to a Worker's safety Pendant such as WorkForce
, SuperCELL
,
®
and TPASS
and uses a customer-supplied Ethernet or Wi-Fi internet connection for data signaling
with the Cloud Monitoring Portal.
Advertisement
Related Manuals for Grace Industries Grace Fixed Gateway
Summary of Contents for Grace Industries Grace Fixed Gateway
- Page 1 GFG - Grace Fixed Gateway User Information GFG Grace Fixed Gateway Grace Fixed Gateway (GFG) is a wireless bridge that manages the data signaling between Grace Lone Worker safety Pendants and the Grace Connected Safety Cloud Monitoring Portal. GFG ®...
- Page 2 IMPORTANT: Please Read All User Information Before Use • Always test Grace Fixed Gateway (GFG) prior to use in accordance with the user information. • GFG requires an internet connection plus an active Grace Connected Safety account. Set up your account at www.GraceConnectedSafety.com •...
- Page 3 GFG Grace Fixed Gateway Specifications Model Enclosure Polycarbonate Resin, Flame Retardant, UV Stabilized Size 7.63 x 4.63 x 3.09 in. (193.8 x 117.6 x 78.5 mm) Weight 2.2 lb. (1kg) Mounting Options GFG is designed for desktop placement or wall-mount. Mounting holes on the base of the enclosure can be used to secure the GFG to a desktop or wall.
-
Page 4: Power Indicator
GFG Status LED Indicators 1. Grace Cloud Connect Network Status LED 2. Grace Radio Status LED 6. Sound On/Off Button 3. Network Status LED 4. Power Indicator 5. Alarm Indicator 1. Grace Cloud Connect Network Status LED ███ Solid Green GFG connected to Grace Cloud Connect Network ███... - Page 5 GFG Ethernet Connection IMPORTANT: DO NOT Power ON or activate any Pendant device before Powering ON and activating the GFG. Verify all Pendants are powered off. GFG is a stand-alone bridge device that connects a worker’s Pendant to the Grace Cloud Connect Monitoring and Alerting Portal by way of an internet connection from Ethernet or Wi-Fi.
- Page 6 GFG Wi-Fi Configuration via Online Portal 4. Once this scanning operation is complete, the Connection section of the Gateway status bar will change to a button labeled Setup Wifi. Click this button to open the Setup WiFi window. 5. Select the SSID of the network you wish to connect to from the available networks in the dropdown menu. 6.
- Page 7 GFG Wi-Fi Configuration via Flash Drive Config Tool 1. Connect the supplied GFG configuration USB drive into a Windows PC. 2. Run the GFG Configuration Tool by double-clicking Gfg_Config.exe, or select open. 3. Select Load Config. 4. Next, select the userconfig.ini file located on the USB drive with the GFG config tool.
- Page 8 GFG Wi-Fi Configuration (continued) 5. Enable Wi-Fi and set the SSID, Password, and Security Protocol of your Network. When finished, press “Save Changes”. Network SSID Network Password Note: The Wi-Fi and LAN MAC address of the GFG will be displayed here, this may be required to allow your GFG to connect to your network.
- Page 9 GFG Operating Instructions STEP 1: Grace Cloud Connect Portal Access: • Access the website link Grace Industries has provided (by email) to your Master Administrator. • Login using the provided credentials. • Continue with configuration and setup of Pendant Monitoring and Alerting.
- Page 10 Industries. Grace Industries will repair or replace, at their sole discretion, defective products free of charge. This warranty applies to products that Grace Industries deems defective in its sole discretion due to defects in material or workmanship under normal use and maintenance and where a defect was not caused by accident, misuse or abuse of the product and that no disassembly, repairs or parts replacement were made or attempted by other than Grace Industries’...
