- Page 1 User Guide Yoga Pro 9i (16″, 9)
- Page 2 • Setup Guide First Edition (January 2024) © Copyright Lenovo 2024. LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-...
-
Page 3: Table Of Contents
The Copilot key ... . . Call Lenovo ....Touch operations supported by Windows . . . - Page 4 Appendix A. Function descriptions Appendix B. Notices and for Lenovo hotkeys ..35 trademarks ....37 User Guide...
-
Page 5: About This Guide
About this guide • This guide applies to Lenovo product model(s) listed below. Illustrations in this guide may look slightly different from your product model. Model name Machine type (MT) 83DN – Yoga Pro 9 16IMH9 – Yoga Pro 9 16IMH9 D1 •... - Page 6 User Guide...
-
Page 7: Chapter 1. Meet Your Computer
The infrared LED generates and emits near-infrared waves that are received and used by a camera (or a dedicated infrared camera) for facial recognition. Infrared camera The infrared camera receives near-infrared waves emitted by an infrared LED and reflected by a human face. It is used for facial recognition. © Copyright Lenovo 2024... -
Page 8: Camera
Camera The built-in camera captures visible light and converts it to digital signals. It is used for video recordings and video conferencing. Camera light The camera light indicates whether the camera is activated. Table 1. Camera light status and description Camera light status Description The camera is activated. -
Page 9: Top View
Top view Figure 2. top view Description Antennas (cannot be seen from the outside) Speakers Touchpad Keyboard Microphones Antennas The antennas transmit and receive radio waves to allow data to be transferred between your PC and a Wi-Fi network device or a Bluetooth device. Note: The antennas are hidden inside the PC. -
Page 10: Microphones
Related topics “Hotkeys” on page 15 “The FnLock switch” on page 15 Appendix A “Function descriptions for Lenovo hotkeys” on page 35 Microphones The microphones are the PC's built-in sound input devices. They capture your voice and ambient sound and convert them into digital form. -
Page 11: Left View
Left view Figure 3. left-side view Description Power connector Charging light ™ HDMI connector ® Multi-purpose USB Type-C connector Combo audio jack Power connector Check the plug type of the included ac power adapter to determine which power connector to use to supply power to your PC. -
Page 12: Hdmi Connector
HDMI connector The HDMI connector is used to connect an external display device, such as a television, a projector, or a monitor. Multi-purpose USB Type-C connector Check the plug type of the included ac power adapter to determine which power connector to use to supply power to your PC. -
Page 13: Right View
Right view Figure 4. right-side view Description Camera switch SD card slot USB Standard-A connector Power light Power button Camera switch This toggle switch is used to enable or disable the built-in camera. Note: This switch is designed for privacy protection. If you don't need to use the camera, slide the switch to the off position to prevent any apps from using the camera. -
Page 14: Power Light
The always-on function can be turned on and off in: • The PC's firmware setup utility, or • Lenovo Vantage or Lenovo PC Manager Power light The power light indicates the current power state of the PC: whether it is powered on, powered off, in sleep mode, or in hibernation mode. -
Page 15: Bottom View
Bottom view Figure 5. bottom view Description Air vents (intake) Novo button hole Speakers Air vents (intake) The air vents allow air to be sucked inside of the PC to cool the internal components. Important: When the PC is operating, do not place it on a bed, sofa, carpet, or other flexible surfaces. Otherwise, the air vents will be blocked and the PC may overheat, reducing performance or causing the PC to be unresponsive or even shut down. -
Page 16: Specifications
100 V ac–240 V ac, 50 Hz–60 Hz Maximum output voltage 20 V Maximum output current Maximum power 100 W Option 2 Connector Lenovo rectangular power connector Input 100 V ac–240 V ac, 50 Hz–60 Hz 20 V Output voltage Maximum output current 8.5 A Maximum power 170 W Note: Only one of the ac power adapters listed above is supplied with your PC. - Page 17 Memory Type LPDDR5X Installation On board Number of DIMM slots Mass storage device Type Solid-state drive (SSD) Slot type M.2 (2280) Number of slots Interface PCIe Gen4 Display Screen size (diagonal) 16 inches Resolution • 3200 × 2000, or • 2560 × 1600 Supported refresh rates •...
-
Page 18: Statement On Usb Transfer Rate
Multi-purpose USB Type-C • Maximum output power: 5 V, 3 A connector 2 • Maximum input power: 20 V, 7 A • Supported signaling protocols: – USB 2.0 480Mbps – SuperSpeed USB 5Gbps – SuperSpeed USB 10Gbps – SuperSpeed USB 20Gbps (USB 3.2 Gen 2 × 2) –... -
Page 19: Operating Environment
USB device Data rate (Gbit/s) USB4 20Gbps USB4 40Gbps Operating environment Maximum altitude (without pressurization) 3048 m (10 000 ft) Temperature • At altitudes up to 2438 m (8000 ft) – Operating: 5°C to 35°C (41°F to 95°F) – Storage: 5°C to 43°C (41°F to 109°F) •... - Page 20 User Guide...
-
Page 21: Chapter 2. Explore Your Computer
Interact with your computer Hotkeys Look at the top row of the keyboard of your Lenovo computer and you’ll find keys with printed icons. These keys are called hotkeys and they provide shortcuts to functions that you’ll use frequently. The function that each hotkey provides is denoted by the icon printed on the key. -
Page 22: The Copilot Key
Appendix A “Function descriptions for Lenovo hotkeys” on page 35 The Copilot key The era of AI has arrived, and many Lenovo PCs now include a Copilot key on the keyboard. It is located either in the bottom or the top row of the keyboard and is marked with For Windows PCs with Copilot in Windows available and enabled, pressing the Copilot key opens Copilot in Windows. -
Page 23: Touch Operations Supported By Windows
Related topics “I pressed the Copilot key on my keyboard, but neither Copilot in Windows nor Windows Search opened. What could be the potential cause?” on page 29 Touch operations supported by Windows For computers with a touch-enabled screen, you can touch the screen directly with your fingers and interact with your computer in a more natural way. -
Page 24: The Novo Button Menu
Step 1. Turn off the PC but do not close the LCD screen. Note: Flip to Start is enabled by default on many Lenovo PCs. When the PC is turned off, opening the LCD screen will turn it on. Step 2. -
Page 25: Eye Care Mode
Note: Depending on the geographical location where your PC is purchased, either Lenovo Vantage or Lenovo PC Manager may have been pre-installed on your PC. Features and configuration details are subject to change through online updates. Features may vary depending on the model and may not be available on all product models. -
Page 26: Super Resolution
It works especially well in cases where the source video has a poor resolution. For most players, Super Resolution can be enabled or disabled in Lenovo Vantage or Lenovo PC Manager, but for some specific players, you might need to enable this feature manually. -
Page 27: Manage Power
You can charge the battery any time you want. The battery packs of Lenovo computers support multiple charging modes that are suitable for different power usage habits. You can switch the battery’s active charging mode in Lenovo Vantage or Lenovo PC Manager. -
Page 28: Set Power Button Behavior
If the battery pack of your computer supports overnight charge optimization, it can be enabled in Lenovo Vantage or Lenovo PC Manager. -
Page 29: System Operation Modes
You can switch the operation mode in the pre-installed app Lenovo Vantage or Lenovo PC Manager. As a shortcut, you can also use the key combination Fn + Q. Three modes are usually available for most Lenovo computers. The following table lists the operation modes and the recommended conditions for each mode. -
Page 30: What Is Uefi/Bios Setup Utility
Change the setting to Disabled or Enabled. Step 4. Select Exit ➙ Exit Saving Changes. Enable or disable always-on For some Lenovo computers with always-on connectors, the always-on function can be enabled or disabled in the UEFI/BIOS setup utility. Step 1. Open the UEFI/BIOS setup utility. -
Page 31: Set Passwords In Uefi/Bios Setup Utility
Attention: If you forget the administrator password, a Lenovo authorized service personnel cannot reset your password. You must take your computer to a Lenovo authorized service personnel to have the system board replaced. Proof of purchase is required and a fee will be charged for parts and service. -
Page 32: Set User Password
Lenovo authorized service personnel cannot reset your password or recover data from the hard disk. You must take your computer to a Lenovo authorized service personnel to have the hard disk drive replaced. Proof of purchase is required and a fee will be charged for parts and service. -
Page 33: Change Or Remove Hard Disk Password
Note: The master and user hard disk passwords must be set at the same time. Step 4. Select Exit ➙ Exit Saving Changes. If the hard disk password is set, you must provide the correct password to start the operating system. Change or remove hard disk password Step 1. - Page 34 User Guide...
-
Page 35: Chapter 3. Help And Support
Why does my computer start automatically when I open the lid Your computer may have Flip to Start enabled. Many Lenovo notebook computers include a sensor that can detect the angle at which the lid is opened. When you open the lid, the sensor can detect this behavior. If Flip to Start is enabled, the computer will respond by starting up automatically. -
Page 36: Self-Help Resources
3. Click Diagnostics ➙ Operating System Diagnostics and then follow the on-screen instructions. Use Lenovo Vantage or Lenovo PC Manager to: • Download and install the latest drivers and firmware. • Configure hardware settings Use Windows Search. • Diagnose computer hardware problems. -
Page 37: What Is A Cru
If you intend to install a CRU, Lenovo will ship the CRU to you. You might be required to return the defective part that is replaced by the CRU. When return is required: (1) return instructions, a prepaid shipping label, and a container will be included with the replacement CRU;... -
Page 38: Call Lenovo
Call Lenovo If you have tried to correct the problem yourself and still need help, you can call Lenovo Customer Support Center. Before you contact Lenovo Record product information and problem details before you contact Lenovo. -
Page 39: Purchase Additional Services
For the terms and conditions of the Lenovo Limited Warranty that apply to your Lenovo hardware product, see “Warranty information” in the Safety and Warranty Guide that comes with your computer. Purchase additional services During and after the warranty period, you can purchase additional services from Lenovo at https://pcsupport.lenovo.com/warrantyupgrade... - Page 40 User Guide...
-
Page 41: Appendix A. Function Descriptions For Lenovo Hotkeys
Appendix A. Function descriptions for Lenovo hotkeys Hotkey functions are denoted by the icons printed on the keys. The following table describes the functions for all Lenovo hotkeys. The keyboard of your Lenovo computer should only support a subset of the listed hotkeys. - Page 42 Table 7. Hotkey icons and denoted functions (continued) Hotkey icon Function description Plays the next audio or video in the playlist. Switches the computer’s active operation mode. Blurs the background for videoconferencing. Switches the computer’s active audio mode. Turns on/off night light mode. (Windows operating systems) Note: Hotkey functions may change if the associated app or the Windows operating system is updated.
-
Page 43: Appendix B. Notices And Trademarks
Lenovo representative for information on the products and services currently available in your area. Any reference to a Lenovo product, program, or service is not intended to state or imply that only that Lenovo product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any Lenovo intellectual property right may be used instead. - Page 44 Actual results may vary. Users of this document should verify the applicable data for their specific environment. This document is copyrighted by Lenovo and is not covered by any open source license, including any Linux agreement(s) which may accompany software included with this product. Lenovo may update this document at any time without notice.
