AMT AMF 60 User Manual

Fingerprint attendance and access control terminal
Hide thumbs
1
2
3
4
5
6
7

Advertisement

Table of Contents

AMT Fingerprint Attendance
and Access
Control Terminal
User Manual
AMF 60
* Attention
1．Please cut down the power when install the machine.
2．Please do not install the terminal in direct sunlight or damp environment.
3．Please use 12V/3A or 12V/5A professional access power supply to power on the
machine.
4．When the static electricity is serious, please link GND first, and then connect
other wires to prevent the static electricity to damage the machine.
5．Please read the terminal wiring diagram carefully, and follow it to link the wires
6．USB flash disk need to use 8G or 16G FAT32 format one, and please format it
before use.
1
www.amts.pk

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AMF 60 and is the answer not in the manual?

Questions and answers

Summary of Contents for AMT AMF 60

  • Page 1 AMT Fingerprint Attendance and Access Control Terminal User Manual AMF 60 * Attention 1．Please cut down the power when install the machine. 2．Please do not install the terminal in direct sunlight or damp environment. 3．Please use 12V/3A or 12V/5A professional access power supply to power on the machine.

  • Page 2: Appearance Introduction

    1. Appearance Introduction Front Back Side Bottom www.amts.pk...

  • Page 3: Wiring Diagram

    2. Wiring Diagram Remark：If you want to link this terminal with access controller, please power on the machine independently. The TCP/IP function is optional function, if you want to use, please tell the supplier when make order, can not add on client side. 3.
  • Page 4 Delete, can use T9 input method. Remark：Add administrator: In Authority option to choose “Admin” (After set administrator only Admin. can enter the menu, please register admins’ finger and password and please remember the ID and password.) 2.Delete user Register>2. Delete. Input the ID for you want to delete, then choose delete. 3.Download Data Register>Insert USB flask disk to machine>3.

  • Page 5: Access Control Setting

    6. Set time Press MENU>Advanced>4.SetTime>1. Custom, then can set date and time 7. Access control setting Press MENU>Advanced >5. LockCtrl 1．Time Setting：Set the time period for user to open the door. We can according to all the user’s access rule to set the in and out time period.

  • Page 6: Attendance Rule

    9. Attendance Rule Press MENU>Advanced>1. Att.Rule 1． Company： Set user’s company name, can use T9 input method. 2． Set Dept：Edit department, totally can set 16 department. 3． Shift Schedule：Set the check in and out time for each department, totally can set 24 shifts, each shift can set 6 attendance time, if no need to take attendance please set “00：00”.
  • Page 7 1． Count：Set the bell time, if set 0 and No means don’t use bell. 2． Time：Set bell time for each day, Max. can set 8 different bell time. For example: we set Count 3 and time 12:00, means every day when 12:00 bell will ring 3 times. 11.
